Lynx Technik AG yellobrik OTR 1810 3Gbit Fiber Optic/SDI Transceiver, 10km Maximum Distance, Multimode LC Connection

SKU: LTOTR1810MM MFR: OTR1810MM
Earn VIP Reward Points

Key Features

  • Achieve reliable video transmission with this 3Gbit Fiber Optic/SDI Transceiver.
  • Extend your broadcast capabilities up to 300m using robust fiber optic technology.
  • Enjoy stable connections for professional video with multi-rate reclocking up to 3Gbit/s.
  • This compact SDI transceiver supports multiple standards, from 270Mbit/s to 3Gbit/s.
  • Easily integrate this yellobrik transceiver with automatic cable EQ for optimal performance.
  • Ensure high-quality video signals with low latency using this reliable video transmitter.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$69.99

3 Year

$94.99

4 Year

$119.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Lynx Technik AG OTR 1810 Specifications

  • SDI Video

    1x SDI video input
    1x SDI Video output
    75Ohms BNC connectors
    SMPTE 424M, SMPTE 292M, SMPTE 259M, DVB-ASI
    Multi-standard operation from 270Mbit/s to 3Gbit/s
    Multi-rate reclocking
    270Mbit/s - 1.48Gbit/s - 3Gbit/s
    Return Loss: > 15dB to 1.5GHz and > 10dB up to 3GHz
    Automatic cable EQ (Belden 1694A cable) 250m at 270Mbit/s, 140m at 1.5Gbit/s, 80m at 3Gbit/s

  • Fiber Optic

    1x Fiber optic input
    1x Fiber optic output
    Duplex using LC Connections
    SMPTE 297M - 2006
    Transmitter: 850nm (-5dBm)
    Receiver: 750nm to 880nm (0dBm to -15dBm)
    Maximum distance 300m / 984.24' at 3Gbit/s
    TX active LED, and RX active on side of module

  • Power

    +12VDC at 2.6W nominal - ( supports 7 - 16VDC input range )

  • Ambient Temperature

    5 to 40 deg. C / 41 to 104 deg. F, 90% Humidity (non condensing)

  • Dimensions

    140 x 42 x 22mm / 5.51 x 1.65 x 0.87" including connectors

  • Weight

    125g / 4.41oz

About Lynx Technik AG OTR 1810

After extensive research and development, Lynx Technik AG presents the yellobrik OTR 1810 3Gbit Fiber Optic/SDI Transceiver, a durable and high-quality device designed to overcome the challenges of distributing uncompressed, broadcast-quality video signals over long distances. This innovative transceiver combines a transmitter and receiver into one self-contained package, offering a cost-effective and reliable solution for professional broadcasting needs.

The OTR 1810 is engineered to handle any SDI signal up to 1080p60 (3Gbit/s), preserving the full uncompressed quality of your audio and video transmissions. With a maximum distance of 10km, it's ideal for long-range transmissions, ensuring your signals reach their destination without compromise.

This advanced transceiver features an independent transmitter and receiver channel, providing a versatile solution for a variety of broadcasting scenarios. It's equipped with an auto-detect and re-clock function for any 270Mbit / 1.5Gbit and 3Gbit SDI source prior to conversion, ensuring optimal performance and signal integrity.

Designed for a multimode LC connection, the OTR 1810 is fully compatible with 3Gbit Level A and Level B formats. This compatibility, combined with its robust construction and innovative features, makes the yellobrik OTR 1810 3Gbit Fiber Optic/SDI Transceiver a standout choice for professionals in the broadcasting and video production industries.

Lynx Technik AG OTR 1810 Features

  • SDI Fiber receiver and transmitter in single package
  • Supports SDI video up to 3Gbit/s (1080p60)
  • 3Gbit Level A and Level B support (all formats)
  • Auto reclocking 270Mbit / 1.5Gbit / 2.97Gbit
  • Error free optical connections
  • Singlemode and Multimode versions
  • Up to 10km (6.2 miles) at 3Gbit/s (singlemode)
  • Up to 300m / 984.24' at 3Gbit/s (multimode)
  • Duplex LC optical connection
  • Supports hot swapping and hot plugging

Product Documents

User Manual

Key Features

  • Achieve reliable video transmission with this 3Gbit Fiber Optic/SDI Transceiver.
  • Extend your broadcast capabilities up to 300m using robust fiber optic technology.
  • Enjoy stable connections for professional video with multi-rate reclocking up to 3Gbit/s.
  • This compact SDI transceiver supports multiple standards, from 270Mbit/s to 3Gbit/s.
  • Easily integrate this yellobrik transceiver with automatic cable EQ for optimal performance.
  • Ensure high-quality video signals with low latency using this reliable video transmitter.

What's in the box:

  • Lynx Technik AG yellobrik OTR 1810 3Gbit Fiber Optic/SDI Transceiver
  • AC Power Supply
  • Transport Case
  • Lynx Technik AG 3 Year Warranty
