Lynx Technik AG yellobrik OTX 1910 L-Band Fiber Optic Transmitter, 10km

SKU: LTOTX1910 MFR: OTX1910
Earn VIP Reward Points

Key Features

  • Achieve long range wireless video transmission up to 10km with this L-Band transmitter.
  • Enjoy stable signal broadcast equipment for reliable video and audio transmission.
  • This durable build fiber optic transmitter supports extended L-Band frequencies (700-2300MHz).
  • Experience low latency video with virtually no delay using this wireless transmitter.
  • Easy setup broadcast transmitter: Simply connect and start transmitting high-quality video.
  • High resolution wireless video: Maintain pristine quality in your live streaming setup.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$89.99

3 Year

$109.99

4 Year

$139.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Lynx Technik AG OTX 1910 Specifications

  • RF Input

    Connector: 1x 75Ohms F-Type
    Frequency Range L-Band: 950MHz - 2150MHz
    Frequency Range Ext. L-Band: 700MHz - 2300MHz
    Return Loss: >14dB
    Input Power Range: -10dBm to -65dBm

  • LNB Power

    Voltage: (13V/18V) DC, On/Off
    Current max: 450mA
    Protection: Short Circuit
    LO Control: 22kHz / 0kHz

  • RF Output

    Connector: 1x 75Ohms F-Type
    Frequency Range: 700MHz - 2300MHz
    Return Loss: >14dB
    Flatness L-Band: +/- 1.5dB
    Flatness Ext. L-Band: +/- 2.0dB
    Output Level: Within +/- 2.0dB of input signal

  • Fiber output

    Connector: 1x LC/PC singlemode
    Wavelength: 1310nm
    Optical Power: 1dBm (+/- 1dBm)

  • Power

    +12VDC at 3.5W nominal - ( supports 9 - 14V input range)

  • Ambient Temperature

    5 to 40 deg. C / 41 to 104 deg. F, 90% Humidity (non condensing)

  • Dimensions

    137 x 42 x 22mm / 5.39 x 1.65 x 0.87" including connectors

  • Weight

    125g / 4.41oz

About Lynx Technik AG OTX 1910

Experience the power and efficiency of the yellobrik OTX 1910 L-Band Fiber Optic Transmitter, a top-tier solution for transmitting analog RF L-Band signals over extended distances. Designed to support RF signals within the broad L-Band range of 700MHz to 2300MHz, this module ensures high-quality, uninterrupted signal transmission.

The OTX 1910 is equipped with an integrated dip switch, providing a user-friendly interface for configuration. This feature enables the LNB power to be activated and toggled between 13V or 18V, allowing users to select either horizontal or vertical polarization with ease.

Adding to its versatility, the OTX 1910 also houses an internal 22kHz tone generator. This can be conveniently switched on and off to select the high or low frequency range, offering more control over your signal transmission.

When used in conjunction with the yellobrik ORX 1900 fiber optic receiver for RF signals, the OTX 1910 forms part of a cost-effective optical RF transmitter/receiver system. This powerful pairing facilitates reliable signal transmission for distances up to 10km.

In summary, the yellobrik OTX 1910 L-Band Fiber Optic Transmitter is a robust, efficient, and user-friendly solution for long-distance RF signal transmission. Its broad L-Band range, easy configuration, and compatibility with the ORX 1900 receiver make it an invaluable asset for any professional requiring reliable, high-quality signal transmission.

Lynx Technik AG OTX 1910 Features

  • Input frequency 700MHz - 2300MHz
  • L-Band output
  • LNB power selectable 13V/18V
  • 22kHz on/off for LNB local oscillator control
  • Simplex LC/PC singlemode optical connection
  • Up to 10km (6.2 miles)

Key Features

  • Achieve long range wireless video transmission up to 10km with this L-Band transmitter.
  • Enjoy stable signal broadcast equipment for reliable video and audio transmission.
  • This durable build fiber optic transmitter supports extended L-Band frequencies (700-2300MHz).
  • Experience low latency video with virtually no delay using this wireless transmitter.
  • Easy setup broadcast transmitter: Simply connect and start transmitting high-quality video.
  • High resolution wireless video: Maintain pristine quality in your live streaming setup.

What's in the box:

  • Lynx Technik AG yellobrik OTX 1910 L-Band Fiber Optic Transmitter
  • 12V DC Power Supply
  • Plastic Transport Case
  • Lynx Technik AG 3 Year Warranty
