Lynx Technik AG SPG 1708 HDTV / SDTV Analog Sync Pulse Generator with Genlock

SKU: LTSPG1708 MFR: SPG 1708
Earn VIP Reward Points

Key Features

  • Achieve impeccable audio sync with this HDTV/SDTV analog sync pulse generator.
  • Genlock feature ensures seamless integration with your existing video equipment.
  • Enjoy versatile format support, including 1080i/p and 720p HD sync standards.
  • Generate reliable bi-level SD sync outputs for NTSC, PAL, and PAL M/N formats.
  • Utilize the word clock or DARS outputs for precise 48kHz audio synchronization.
  • Easily upgrade firmware via USB for continued compatibility and performance.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

Qty
1

Protect your gear with Adorama Protect.* Learn more

2 Year

$174.99

3 Year

$224.99

4 Year

$299.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Shopper : Why Did You Choose This?ADAM R : He told me to

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Lynx Technik AG SPG 1708 Specifications

  • HD Sync

    3x Tri-level Sync outputs
    1080i 50Hz / 59.94Hz / 60Hz
    1080p 23.98Hz / 24Hz / 25Hz / 29.97Hz / 30Hz / 50Hz / 59.94Hz / 60Hz
    720p 23.98Hz / 24Hz / 25Hz / 29.97Hz / 30Hz / 50Hz / 59.94Hz / 60Hz
    1080psf 23.98Hz / 24Hz
    SMPTE 274M, SMPTE 296M
    Selectable via integrated 16 position rotary switch
    Return Loss: >40dB up to 5MHz
    SNR > 75dB

  • SD Sync

    3x Bi-level Sync outputs
    NTSC, PAL, PAL M/N
    SMPTE 170M, ITU-R BT 470.6
    Selectable: 75% color bars / black burst / sync only
    NTSC 7.5 IRE pedestal ON/OFF
    Adjustable burst phase in 8 increments
    Return Loss: >40dB up to 5MHz
    SNR > 75dB

  • Ref Input

    Bi-level or tri-level analog sync
    Cross lock compatible to 525 and 625 SD sync and all HD sync standards
    SMPTE 274M, SMPTE 296M

  • Audio Sync

    48kHz Word Clock or DARS
    48kHz Word Clock: 0 - 5.0V
    DARS: SMPTE 276M unbalanced AES (24-bits) - Grade 2

  • Accuracy

    2 ppm

  • Power

    +12V DC @ 2.4W nominal - ( supports 7 - 17V DC input range )

  • USB

    Mini "Type B" connection for firmware upgrades and remote control

  • Ambience

    41 - 104 Degree F (5 - 40 Degree C)

  • Humidity

    90% (non condensing)

  • Dimensions (W x H x D)

    5.51 x 3.34 x 0.86" (140 x 90 x 22mm) (Including connectors)

  • Weight

    10.6 oz (300g)

  • UPC Code

    4250479328655

About Lynx Technik AG SPG 1708

When precision and versatility are paramount in synchronizing video and audio signals for HDTV and SDTV systems, the Lynx Technik AG SPG 1708 Analog Sync Pulse Generator with Genlock emerges as the industry standard. This durable and advanced module is engineered to deliver high-quality, reliable sync pulses, ensuring seamless integration and synchronization for professional broadcast environments.

The SPG 1708 is a compact yet innovative solution, offering a comprehensive range of outputs including three Tri-Level sync outputs and three Bi-Level sync outputs, along with a dedicated Audio Sync output. This output versatility is complemented by the inclusion of both 48kHz Word Clock and Digital Audio Sync Signal (DARS) capabilities, catering to a broad spectrum of audio and video synchronization needs.

With an exceptional accuracy of 2ppm and a temperature-stabilized design, the SPG 1708 stands out for its robust performance under varying operational conditions. The genlock feature of this sync generator is highly flexible, allowing it to lock onto any HD or SD Sync input. Its full cross-lock functionality is particularly noteworthy, as it maintains synchronization even when dealing with unmatched standards.

The frequency-locked outputs, including Bi-Level and Tri-Level sync outputs and audio sync signals, remain consistent with the reference signal, regardless of the sync standard selected for the outputs. This ensures that output signals are timing locked when they share the same frame rate group as the reference. For precise alignment, the SPG 1708 allows for the application of delays in units of output line and pixel, which can be controlled remotely via the yelloGUI software.

The SPG 1708 supports a wide array of Tri-Level Sync output selections, including multiple frame rates for 1080i, 1080p, 720p, and 1080psf formats, ensuring compatibility with various HDTV standards. For Bi-Level Sync, it accommodates NTSC, PAL, and PAL M/N formats. The module also offers the flexibility to output Color Bars, Black Burst, or just the Sync signal, with a selectable 7.5 IRE pedestal for NTSC standards and adjustable burst phase in 8 increments.

User controls are thoughtfully positioned on the top side of the module, clearly labeled for ease of use. For those requiring deeper customization, the SPG 1708 can be remotely controlled via USB, unlocking a wider range of options and settings through the intuitive yelloGUI software.

In summary, the SPG 1708 HDTV / SDTV Analog Sync Pulse Generator with Genlock is an essential tool for professionals in the audio and video industry who demand a high channel count, SDI audio interface compatibility, and a reliable sync pulse generator that can adapt to a multitude of broadcast standards.

Lynx Technik AG SPG 1708 Features

  • Supports all regular analog Tri- and Bi-Level Sync standards
  • Simultaneous HD/Tri-Level and SD/Bi-Level sync outputs
  • 3 x HD/Tri-Level and 3 x SD/Bi-Level sync outputs
  • Genlock with cross lock to any sync standard
  • "Color Bars", "Black Burst" or "Sync Only" for SD
  • NTSC, PAL or PAL M/N for Bi-Level sync outputs
  • Programmable sync delay output relative to reference
  • Burst phase adjustment for NTSC and PAL sync
  • Audio Sync output 48kHz Word Clock or DARS
  • yelloGUI compatible to access additional internal settings

Key Features

  • Achieve impeccable audio sync with this HDTV/SDTV analog sync pulse generator.
  • Genlock feature ensures seamless integration with your existing video equipment.
  • Enjoy versatile format support, including 1080i/p and 720p HD sync standards.
  • Generate reliable bi-level SD sync outputs for NTSC, PAL, and PAL M/N formats.
  • Utilize the word clock or DARS outputs for precise 48kHz audio synchronization.
  • Easily upgrade firmware via USB for continued compatibility and performance.

What's in the box:

  • Lynx Technik AG SPG 1708 HDTV / SDTV Analog Sync Pulse Generator with Genlock
  • AC Power Supply
  • Lynx Technik AG 3 Year Limited Warranty
