Lowell Manufacturing LWSR-1022 10U Wall Swing-Open Rack with 1 Pair Fixed Rails, 22" Depth, Black

Economical two-part rack features a 16-gauge steel backbox and a front mounting section that attaches with heavy-duty bolts through steel fasteners with securing nuts.

Construction
16-gauge certified U.S. steel construction with black wrinkle powder epoxy finish. Beveled edge corners on mounting section.

Installation Note
Backbox and mounting section are boxed together. Mounting section swings open 90 degrees and requires minimum swing clearance equivalent to mounting section depth (18.178") plus 1" if optional front door is added.

Backbox
• 16" mounting centers
• 10"W center wiring path accommodates wall obstructions and aids cable management
• Removable knockout panel in top with combination EKOs for conduit (1/2"-3/4" and 1"-1-1/2") and KOs for wireless antennae (1/2")
• Removable knockout panel in bottom with combination EKOs for conduit (1/2"-3/4" and 1"-1-1/2")
• Multiple bridge lances and obrounds on back plane for cable management
• Two center locks (upper and lower) are keyed differently than the optional front door

Front Mounting Section
• Connects to backbox (right or left-hand swing) with two heavy duty bolts through steel fasteners/securing nuts
• Welded sides feature upper and lower vents
• Nutserts on front frame are used to add optional surface-mount door (left or right swing)

Rack Rails (10U fixed-position)
One pair mounting rails, 11-gauge steel with black finish, 10-32 threaded holes and numbered RU increments. Rails are recessed from frame to allow 1.38" clearance for equipment knobs and connections between equipment and (optional) front door.

Hardware
Black pilot point screws with captive washers for quick installation and 5/16" Allen wrench.

Compliance
EIA/TIA compliant. RoHS compliant.
