Magewell Pro Convert HDMI TX 1-Channel NDI Encoder
See all Magewell items

Magewell Pro Convert HDMI TX 1-Channel NDI Encoder

SKU: MA64050
(1)

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

2021-04-04T12:30:14

Rated 4 out of 5

Easy to setup and use.

This is an excellent product - easy to set up and use. Appears well built and plan on getting more when budget allows. That's the only drawback at this time is the cost, but it appears everyone in this marketplace is priced the same.

ROSE S.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Magewell Pro Convert Specifications

  • Supported Web Browser (tested)

    Microsoft Internet Explorer 11
    Microsoft Edge
    Mozilla Firefox version 61 and above
    Google Chrome version 49 and above
    Apple Safari 11.1 and above
    Opera 55.0.2994.44 and above

  • Supported Software (tested)

    OBS
    XSplit
    vMix
    VidBlasterX
    Wirecast
    streamstar SW
    mimoLive
    Any other NewTek NDI-enabled encoding or streaming software

  • Input Interface

    HDMI:
    DVI-D 1.0
    HDMI 1.4

  • Storage Interface

    SD Card (functions to be developed)

  • PTZ + TALLY Control

    Mini-DIN-8 jack

  • Mounting Hole

    1/4-20 mounting hole

  • Network Interface

    10/100/1000Mbps Ethernet
    IEEE 802.3af PoE

  • USB Interface

    USB2.0 Type B
    5V/2.1A power supply
    USB RNDIS/ECM

  • Input feature

    Support input video resolutions at up to 2048x1200

  • HDMI Specific Features

    165MHz HDMI receiver
    Adaptive HDMI equalizer support for cables lengths up to 30M
    Support for customized EDID
    Support for extraction of AVI/Audio InfoFrames
    Full colorimetry support
    Support up to 2048x1200 4:4:4/4:2:2 60fps input signals
    Support 8 input and 2 output IEC60958 audio streams

  • HDMI Specific Features (Contd.)

    Support for extraction of audio formation information & channel status data
    Support for extraction of video timing information
    Support for extraction of 3D format information
    Support for Side-by-Side Half, Top-and-Bottom, Frame Packing 3D mode.

  • NDI Output Format

    Support for 4:2:2 8-bit output
    Support for up to 2048x1200 60fps
    Support for NDI 3.x

  • Video Processing Features

    Video color format conversion:
    Auto or manual selection of input color format & quantization range
    Auto or manual selection of output color format, quantization range & saturation range
    Support for RGB, YUV BT.601, YUV BT.709, YUV BT.2020 input color formats
    Support for YUV BT.601, YUV BT.709, YUV BT.2020 output color formats
    Support for Limited or Full quantization range/Limited, Full & 'Extended gamut' saturation range

  • Video Processing Features (Contd.)

    Video frame rate conversion
    Video mirror flip
    Video processing pipelines with 160 Mpixels/s
    Video brightness, contrast, saturation, hue adjustment
    Video de-interlacing:
    Top field only
    Bottom field only
    Video aspect ratio conversion:
    Auto or manual selection of output aspect ratio

  • NDI Source Name

    Support for setting the device name shown in the system using Web UI. By default, the device name is 'Pro Convert'.
    Support for setting the source name shown in the system using Web UI. By default, the source name is 'board-index + serial number'.
    Support for setting board-index, from 0 to F, through on-board rotary switch

  • Firmware Upgrade

    Support for manual update using Web UI

  • LED Indicator

    Status LEDs indicate:
    Power supply indicator: on/off
    Input signal indicator: locked/unlocked

  • Working Environment

    Operating temperature: 32 to 113 Degree F (0 to 45 Degree C)
    Storage temperature: -4 to 158 Degree F (-20 to 70 Degree C)
    Relative Humidity: 5% to 90% non-condensing

  • Power Consumption

    5V max current: -1.5A
    Max power consumption: -6W

  • Dimensions (L x W x H)

    3.97 x 2.37 x 0.91 (100.9 x 60.2 x 23.3mm)

  • UPC Code

    0814395021195

About Magewell Pro Convert

Pro Convert family of NDI encoders, built on NewTek's extremely popular NDI media-over-IP technology, help users reliably bring traditional video signals into IP-based live production and AV infrastructures. Available in 4K and 1080p60 configurations with a choice of input interfaces, the converters enable users to easily and cost-effectively connect their existing equipment into NDI-enabled networks.

The ultra-compact Pro Convert devices are ideal for both in-studio and portable field use. Value-added features for live production applications include a 1/4"-20 thread for standard camera-mounting accessories, preview and program tally lights, and NDI-based PTZ camera control. The units can be powered by the included AC adapter or via Power over Ethernet (PoE) for further deployment simplicity.

Magewell Pro Convert Features

  • Support for NDI
  • Support for encoding videos
  • Support for encoding embedded audio
  • Support for PoE (Power over Ethernet)
  • Support for plug-and-play
  • Support for Ethernet over USB
  • Support for connection and management of PTZ camera
  • Support for web-based UI remote control

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Support for NDI
  • Support for encoding videos
  • Support for encoding embedded audio
  • Support for PoE (Power over Ethernet)
  • Support for plug-and-play
  • Support for Ethernet over USB

What's in the box:

  • Pro Convert HDMI TX 1-Channel NDI Encoder
  • Power Adapter
  • USB Type A to Type B Cable
  • Mini DIN8 to DIN8+DB9 Cable
  • Tally Light
  • L Bracket
  • Magewell 2 Year Limited Warranty
