Marshall Electronics QVW-1708-HDI 6RU 17" HDMI Quad View LED Desktop Monitor
See all Marshall Electronics items

Marshall Electronics QVW-1708-HDI 6RU 17" Full HD HDMI Quad View Rack-Mountable LED Desktop Monitor, 1920x1080 (Supports 4K Input)

SKU: MAQVW1708HDI
Be the first to review this item

This item is no longer available.

Recommended Alternatives

Marshall Electronics QVW-1708: Picture 1 regular
Marshall Electronics Desktop Quad View 17" Native Resolution Monitor, 3G-SDI
$4,411.00$2,999.99
See More Recommendations
Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Marshall Electronics QVW-1708-HDI Specifications

  • Number of Panels

    1

  • Panel Size

    17.3"

  • Panel: Resolution

    1920 x RGB x 1080

  • Panel: Aspect Ratio

    16:9

  • Panel: Active Area

    381.888 x 214.812 mm

  • Panel: Type

    LCD Panel

  • Panel: Brightness

    400 cd/m2

  • Panel: Contrast

    600:1

  • Panel: Color Gamut

    YUV, RGB

  • Panel: Viewing Angles (CR>=10)

    160 deg. x 160 deg.

  • Panel: Backlight type

    LED

  • Video Formats

    1080p/1080i/720p/480p/576p

  • Loss of Input Curtain

    Yes

  • Color Temperature

    D65, D55 and D93

  • Headphone Jack

    Yes

  • Audio Bars

    Yes

  • IMD Functions

    Yes

  • Tally OSD

    Yes

  • Blue-Only Mode

    Yes

  • Closed Caption

    Yes

  • Pixel to Pixel

    Yes

  • Pre-set Gamma points

    Yes

  • Self-Sensing

    Yes

  • Modular Input Slot

    2

  • Re-clocked/Re-Shaped

    Yes

  • Video Input: HDMI Dual

    Yes

  • Tally / GPI

    Tally

  • RS-485/422 with Loop Through

    Yes

  • Ethernet

    Yes

  • Controls on front Panel

    Yes

  • User-Defined Function Buttons

    Yes

  • RotoMenu Control

    Yes

  • Pivot Angle

    Yes

  • Handles/Rack Ears

    Yes

  • Voltage

    12 VDC

  • Consumption

    5 AMPat 12VDC 60W Max

  • Power Switch

    Yes

  • Connecter

    4-Pin XLR

  • Compliance

    CE approved

  • Operating Temperature

    0 to 35 deg. C / 32 to 95 deg. F

  • Storage Temperature

    -10 to 50 deg. C / 14 to 122 deg. F

  • Vesa Mount Pattern

    75mm / 2.95"

  • Dimensions (W x H x D)

    Rack Unit: 17.15 x 10.45 x 1.44" / 435.61 x 265.43 x 36.58mm

  • Weight

    Main Body: 9.35lbs / 4.24kg

  • UPC Code

    801813175554

About Marshall Electronics QVW-1708-HDI

• 1920 x 1080 Native Display (16 x 9)
• Accepts Input Resolutions Up to 4096 x 2160
• IMD - In Monitor Display Functions
• Area Markers
• Hard Tally + Soft Tally
• Network Control via Ethernet
• Presence indicators for TC, CC (608/708), Audio
• Bar Display for Embedded Audio, also Timecode Display
• RS-485 in/out/host ports allow daisy-chaining IMD and display functions
• Pixel-to-Pixel Mode
• Compatible with CalMAN 5 Calibration Technology
• IMD Control via Ethernet or RS-485 serial data
• Status Display Shows True Format / Frame Rate
• Rack Ears Included
• In-field firmware update

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • Marshall Electronics QVW-1708-HDI 6RU 17 " Full HD HDMI Quad View Rack-Mountable LED Desktop Monitor
  • V-PS12V-5A-XLR Power Supply
  • Operating Instructions
  • Marshall Electronics 3 Year Limited Warranty (1 Year + 2 Year with Online Registration)
