Marshall Electronics CV730-ND3 9.2MP 4K Ultra HD 12G-SDI/HDMI/NDI|HX3/USB/IP 30x PTZ Camera, Black

SKU: MARCV730ND3

This item is no longer available.

Recommended Alternatives

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Marshall Electronics CV730-ND3 Specifications

  • Color

    Black

  • Sensor

    1/1.8" 9.2MP CMOS (Sony IMX334)

  • Video Format

    2160p: 59.94 / 50 / 29.97 / 25
    1080p: 59.94 / 50 / 29.97 / 25
    1080i: 59. 94 / 50
    720p: 59.94 / 50

  • Video Output (HD) Interface

    12G-SDI, HDMI 2.0, Ethernet, USB 3.0

  • Optical Zoom

    30x

  • Horizontal Viewing Angle

    63 Degree(Wide) to 3.7 Degree(Tele)

  • Panning Angle

    +170 - 170 Degree

  • Panning Speed

    300 Degree/sec

  • Tilting Angle

    +90 to -30 Degree

  • Tilting Speed

    300 Degree/sec

  • Aperture

    f/1.6 to f/4.8

  • Focal Length (lens spec)

    6.5-202mm

  • Shutter Speed

    1/1 - 1/10,000 sec

  • Minimum Object Distance

    4.92' (1.5m) (Wide/Tele)

  • Focus System

    Auto / Manual / Smart AF

  • Gain Control

    Auto, manual

  • White Balance

    Auto, manual

  • Exposure Control

    Auto, manual

  • WDR

    Yes

  • 3D NR

    Yes

  • Image Flip

    Yes

  • Preset Positions

    256

  • Control Interface

    RS-232 / RS-422 / Ethernet / USB 3.0 / Remote

  • Control Protocol

    VISCA / VISCAIP / PELCO D / NDI / UVC

  • Tally Light

    Yes

  • IP Protocol

    NDI|HX2 / NDI|HX3 / RTSP / RTMP / RTMPS / MPEG-TS / SRT

  • PoE

    PoE++ (IEEE802.3bt)

  • Video Stream

    NDI:
    HEVC 4K59.94fps
    H.264 640x360 29.97fps

    RTSP:
    HEVC 4K 59.94fps
    H.264 1080p 59.94fps
    H.264 640x360 29.97fps

  • Video Compression

    HEVC / H.264

  • Audio Input

    Line In/MIC In, 1x Phone Jack 3.5mm

  • Audio Output

    Ethernet / 12G-SDI / HDMI 2.0 / USB 3.0

  • IR Pass-through

    Yes

  • IR Receiver

    Yes

  • IR Remote Control

    Yes

  • Power Consumption

    POE: 27.5W
    DC In: 27W

  • Storage temperature

    -4 Degree F to 140 Degree F (-20 Degree C to 60 Degree C)

  • Operating temperature

    32 Degree F to 104 Degree F (0 Degree C to 40 Degree C)

  • Dimensions

    7.44 x 7.40 x 9.17" (189 x 188 x 233mm)

  • Weight

    6.6 lbs (3kg)

  • UPC Code

    801813231243

About Marshall Electronics CV730-ND3

Marshall CV730-ND3 PTZ cameras feature a 9.2 million-pixel sensor with a long 30x optical zoom range and flexible simultaneous 12GSDI and HDMI outputs with NDI|HX3 and USB 3.0 capability. The crystal-clear UHD (4K) images up to 3840x2160p at 60fps offers a professional camera source to any production. NDI|HX3 delivers low latency, high quality, frame-accurate video, and audio in real time to IP workflows. NDI 5.5 and NDI|Tools opens the ability to integrate more video devices and applications into your production workflow.

Best of Class
Featuring output selections of 12GSDI, HDMI, IP and USB3.0 from a professional grade 1/1.8" Sony sensor with 9.2 million pixels and smooth synchronous movements. CV730-ND3 is the first to deliver UHD60 performance with NDI|HX3. Ease-of-use delivering crystal-clear images up to 3840x2160p at 60fps, NDI|HX3 provides Video, Audio, Control, Tally and Power over one Ethernet cable for remote broadcast-style adjust & match settings control.

Flexible Zoom Range
Constructed with a precision 30x optical zoom range starting at just under 65 Degree horizontal angle-of-view at 6.5mm all the way out to 202mm which captures a crystal clear head & shoulder shot at very long distances.

Ease of Use
Install one-cable to camera for ND|HX3 to operate all functions - That's It - or use Ethernet for PoE/Preview and other outputs (12GSDI/HDMI) for simultaneous output workflows for streaming, production, or archiving.

Professional Broadcast Performance
Marshall Camera Division continues to develop cutting edge camera products to follow the heritage of broadcast quality incorporating reliability, durability, flexibility with feature sets that matter to our industry partners. Collaboration with broadcast engineers and industry professionals ensures we don't lose our cutting edge.

Applications
The CV730-ND3 is suitable for use in Broadcast, Production, Live Events, Sportscast, Government, Courtroom, House of Worship, College/University, Front of Stage, Confidence, Observation.

Marshall Electronics CV730-ND3 Features

  • 9.2MP Sony UHD sensor (1/1.8")
  • 30x optical zoom (6.5mm-202mm) starting at 65 Degree H.AOV
  • Smart Auto-Focus System; AI-enabled focus ensures faces stay in focus
  • 340 Degree pan & 120 Degree tilt range with select-able transition speeds (5-300 Degree per second)
  • 12G-SDI, HDMI 2.0, USB 3.0 and NDI|HX3. simultaneous outputs
  • 3840x2160p (4K UHD), 1920x1080p (FHD), 1920x1080i (FHD) & 1280x720p resolution
  • 59.94, 50, 29.97, 25fps options up to 4K60 and HD60
  • 3.5mm TRS Stereo Audio over I/O cable (Mic/Line)
  • 12V Power Supply included and PoE++ (IEEE802.3bt)
  • "Min. Illumination - 0.05 lux (f/1.6, 50IRE, 30fps)

Warranty Information

This product has a limited warranty of 36 months.

Key Features

  • Capture stunning 4K Ultra HD video with the Marshall CV730-ND3 PTZ Camera for pristine quality.
  • Experience versatile connectivity with 12G-SDI, HDMI, NDI|HX3, USB, and IP outputs on this PTZ camera.
  • Achieve smooth, accurate shots with the 30x optical zoom & precise PTZ controls for any live production.
  • Remotely manage camera settings via RS-232/RS-422 or IP, ensuring seamless integration and control.
  • Perfect for broadcast, education, or streaming, offering professional-grade video in any environment.
  • Enjoy flexible power options with PoE++ support, simplifying setup and reducing cable clutter for this camera.

What's in the box:

  • Marshall Electronics CV730-ND3 9.2MP 4K Ultra HD 12G-SDI/HDMI/NDI|HX3/USB/IP 30x PTZ Camera (Black)
  • Remote Control
  • AC Power Cord
  • Power Adapter
  • RS-422 Connector
  • Metal Plate A
  • Metal Plate B
  • 4x M3 Screw
  • Marshall Electronics 3 Year Limited Warranty
