32% Off

Marshall Electronics QVW-1708 Desktop Quad View 17" Native Resolution Monitor with 4K Quad 3G-SDI

SKU: MARQ17083GDT MFR: QVW-1708-3G-DT
Earn VIP Reward Points

Key Features

  • Experience superior clarity with this 17" Marshall monitor's native 1920x1080 resolution.
  • Enjoy versatile connectivity with 4K Quad 3G-SDI inputs and active loop-through outputs.
  • Utilize the quad view feature for efficient multi-camera monitoring in live productions.
  • Rely on the rugged design, including rack ears, for field and studio production environments.
  • Customize your display with user-defined function buttons for quick access to key settings.
  • Achieve accurate color representation with preset gamma points and color temperature settings.
See More Product Details
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$289.99

3 Year

$449.99

4 Year

$549.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Marshall Electronics QVW-1708 Specifications

Panel
  • Number of Panels

    1

  • Panel Size

    17.3" (43.9cm)

  • Resolution

    1920 x RGB x 1080

  • Aspect Ratio

    16:9

  • Active Area

    381.888 x 214.812 mm

  • Type

    LCD Panel

  • Brightness

    400 cd/sq. m

  • Contras

    600:1

  • Color Gamut

    YUV, RGB

  • Viewing Angles (CR>=10)

    160 x 160 Degree

  • Backlight type

    LED

Features

Jump to...
  • Video Formats

    1080p/1080i/720p/625i/525i

  • Loss of Input Curtain

    Yes

  • Color Temperature

    D65, D55 and D93

  • Headphone Jack

    Yes

  • Audio Bars

    Yes

  • IMD Functions

    Yes

  • Tally OSD

    Yes

  • Blue-Only Mode

    Yes

  • Closed Caption

    Yes

  • Pixel to Pixel

    Yes

  • Pre-set Gamma points

    Yes

  • Self-Sensing

    Yes

  • Modular Input Slot

    2

  • Re-clocked/Re-Shaped

    Yes

  • Inputs

    4K Formats: 4096 x 2160, 3840 x 2160
    HD-SDI
    3G-SDI
    3GSDI x 4 with active loop-through

  • Outputs

    SD-SDI
    HD-SDI
    3G-SDI

Control Features

Jump to...
  • Tally / GPI

    Tally

  • RS-485/422 with Loop-Through

    Yes

  • Ethernet

    Yes

  • Controls on Front Panel

    Yes

  • User-Defined Function Buttons

    Yes

  • RotoMenu Control

    Yes

  • Pivot Angle

    Yes

  • Handles/Rack Ears

    Yes

  • Voltage

    12 VDC

  • Consumption

    5 AMP@ 12VDC 60W Max

  • Power Switch

    Yes

  • Connector

    4-Pin XLR

Compliance

Jump to...
  • Compliance

    CE approve

Environmental

Jump to...
  • Vesa Mount Pattern

    75mm

  • Operating Temperature

    32 to 95 Degree F (0 to 35 Degree C)

  • Storage Temperature

    14 to 122 Degree F (-10 to 50 Degree C)

  • Rack Unit Dimensions (W x H x D)

    17.2 x 10.5 x 1.4" (43.6 x 26.5 x 3.7cm)

  • Weight (Main Body)

    9.4 lb (4.2kg)

  • UPC Code

    801813186666

About Marshall Electronics QVW-1708

6RU 17" Full Resolution Rack-mountable Desktop Monitor with Quad Input, 2K/4K compatibility and advanced IMD features.

The QVW-1708-3G is part of Marshall Electronics' Quad Viewer series of rack mount monitors which can function as a single display supporting inputs up to 4K or four separate displays in Quad View mode supporting inputs up to 1920 x 1080 in each quadrant.

• Convenient, intuitive front panel controls in addition to control via network
• Quad 3GSDI inputs with active loop-through and auto format detection

The QVW-17083-3G can be mounted in any standard EIA 19-inch equipment rack. The attached rack ears can be angled to provide the user control over the viewing angle. A VESA standard 75mm hole pattern also allows custom mounting installations.

Quad-Viewer Feature
Allows viewing of 4 inputs on the screen at once. Each input source is scaled and positioned in real-time so that all 4 inputs can be seen. Besides the standard Quad layout, there are 3 other layouts (including Full Screen) to choose from

Marshall Electronics QVW-1708 Features

  • 1920 x 1080 Native Display (16 x 9)
  • Accepts Input Resolutions Up to 4096 x 2160
  • IMD - In Monitor Display Functions
  • Area Markers
  • Hard Tally + Soft Tally
  • Network Control via Ethernet
  • Presence indicators for TC, CC (608/708), Audio
  • Bar Display for Embedded Audio, also Timecode Display
  • RS-485 in/out/host ports allow daisy-chaining IMD and display functions
  • Pixel-to-Pixel Mode
  • Compatible with CalMAN 5 Calibration Technology
  • IMD Control via Ethernet or RS-485 serial data
  • Status Display Shows True Format / Frame Rate
  • Rack Ears Included
  • In-field firmware update

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Experience superior clarity with this 17" Marshall monitor's native 1920x1080 resolution.
  • Enjoy versatile connectivity with 4K Quad 3G-SDI inputs and active loop-through outputs.
  • Utilize the quad view feature for efficient multi-camera monitoring in live productions.
  • Rely on the rugged design, including rack ears, for field and studio production environments.
  • Customize your display with user-defined function buttons for quick access to key settings.
  • Achieve accurate color representation with preset gamma points and color temperature settings.

What's in the box:

  • QVW-1708 Desktop Quad View 17 " Native Resolution Monitor with 4K Quad 3G-SDI
  • Power Supply
  • Rack Ears
  • Desktop Stand
  • Marshall Electronics 1 Year Limited Warranty
