Musical Fidelity MX-VYNL Fully Balanced MM/MC Phono Stage Pre-Amplifier, Silver

SKU: MFIMXVYNILSI

This item is no longer available.

Overview
Compare
Accessories
Specs
Protection

Reviews about this item

Review Summary

2021-03-14T15:48:00

Rated 5 out of 5

Music Fidelity phono stage under 500.00

Don't let let it's size fool you. Paired with a sumiko blackbird MC and a pro-ject perspex 6 turntable it performs flawlessly. Great price point and impedance range along with its low noise flexible applications I am more than satisfied so far. I have the model with the additional digital out so I can rip vinyl from either of my turntables. My MM turntable is an audio technica lp120 with an Otofon blue I use for older low lower quality lp recordings. Give this little dynamo a chance.

KEVIN B.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Musical Fidelity MX-VYNL Specifications

Output
  • Output

    4 Volts RMS single ended from RCA sockets
    8 Volts RMS balanced from XLR sockets

Performance

Jump to...
  • Frequency response

    RIAA +/-0.1dB IEC +/-0.1dB

  • Channel separation

    < -86dB

  • SNR A-wtd

    < -101dB

  • THD

    < 0.007%

  • XLR input

    5mV / 2.5mV selectable, 70mV max (23dB headroom)

  • Channel separation

    < -83dB

  • SNR A-wtd

    < -98dB

  • THD

    < 0.01%

  • XLR input

    0.8mV / 0.4mV selectable, 12mV max (24dB headroom)

  • Inputs

    Balanced Mini-XLR
    RCA 1 pair RCA sockets

Outputs

Jump to...
  • Outputs

    Balanced XLR male sockets EIA Standard RS-297-A
    RCA 1 pair RCA sockets

  • Connector

    1.3mm pin DC power jack

  • Outboard power supply

    12V/500mA DC

  • Mains voltages

    100-240VAC 50-60Hz universal worldwide supply

  • Consumption

    < 8 watts

General

Jump to...
  • Color

    Silver

  • Dimensions (W x H x D)

    8.66 x 2 x 8.5" (220 x 53 x 215mm)

  • Weight

    4.1 lbs (1.9kg)

  • UPC Code

    9120082385848

1 Accessories for Musical Fidelity MX-VYNL Fully Balanced MM/MC Phono Stage Pre-Amplifier, Silver

  • All Accessories (1)
  • Laptop Stand (1)

About Musical Fidelity MX-VYNL

FEATURED REVIEWS

Music Fidelity phono stage under 500.00

By KEVIN B.

Don't let let it's size fool you. Paired with a sumiko blackbird MC and a pro-ject perspex 6 turntable it performs flawlessly. Great price point and impedance range along with its low noise flexible applications I am more than satisfied so far. I have the model with the additional digital out so I can rip vinyl from either of my turntables. My MM turntable is an audio technica lp120 with an Otofon blue I use for older low lower quality lp recordings. Give this little dynamo a chance.

The MX-VYNL is a Fully balanced, configurable, high performance phono stage.

The MX-VYNL is a fully balanced, very high performance phono stage, able to operate with virtually any moving coil or moving magnet cartridge. With both traditional RCA inputs and our unique XLR fully balanced connection the MX-VYNL can be connected to 2 turntables simultaneously.

The MX-VNYL offers a wide range of input impedance settings for moving coil cartridges as well as several capacitance settings for moving magnet units. Unlike many of our competitors units the MX-VYNL allows easy adjustment of these settings while playing. This allows easy experimentation and tuning to find the optimum setting for all your equipment.

The MX-VYNL also includes our renowned RIAA correction that offers extremely accurate results to beyond 80kHz. That may sound extreme, but there is a good deal of information above 20 kHz that needs correction. If it isn't corrected, it will show itself as ringing and overshoot.

With both extraordinarily low noise and exceptional overload margin the MX-VYNL can comfortably handle even the most demanding of cartridges and satisfy the most discerning of listeners.

Musical Fidelity MX-VYNL Features

  • Fully balanced XLR and traditional RCA inputs
  • Fully balanced XLR and traditional RCA outputs
  • Fully isolated inputs allow for switching between two turntables at once
  • Adjustable input impedance on MC whilst it is playing
  • Adjustable capacitance on MM whilst it is playing
  • Very wide overload margin
  • Accurate RIAA to beyond 80kHz
  • Incredible noise ratio
  • Low impedance output
  • State of the art SMD technology
  • Beautiful aesthetics and build quality

Key Features

  • Experience superior sound quality with this Musical Fidelity phono preamp, enhancing your vinyl.
  • Enjoy low noise and exceptional clarity with the MX-VYNL, designed for audiophile listening.
  • Achieve precise RIAA equalization for accurate vinyl playback, preserving the original recording.
  • Connect effortlessly with balanced XLR and RCA connectivity options for versatile setup needs.
  • Fine-tune your audio with adjustable gain control, optimizing performance for any cartridge type.
  • Built with high-quality components, this phono preamp ensures lasting durability and performance.

What's in the box:

  • MX-VYNL Fully Balanced MM/MC Phono Stage Pre-Amplifier (Silver)
  • Power Supply
  • User Manual
  • Musical Fidelity 5 Year Limited Warranty
