Magma ExpressBox 1T 1 Slot Thunderbolt to PCIe Expansion Chassis
See all Magma items

Magma ExpressBox 1T 1 Slot Thunderbolt to PCIe Expansion Chassis, Supports Half-Length 1 PCI Express Card

SKU: MGEB1T

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Shopper : Why Did You Choose This?Hetan K : We choose EB1T as one to one replacement for EB1F & i being a supplier picked these item for our reqular end customer. Thanks & Regards, Hetan kadakia MOB: + 919870002142

Reviews about this item

Review Summary

Magma ExpressBox 1T Specifications

  • Backplane

    (1) PCI Express Slot (For cards that are 7.75" or less)
    Physical - x16 PCIe 2.0
    Electrical - x4 PCIe 2.0 (Thunderbolt spec)

  • Interconnect Bandwidth

    10 Gbps (1.25GBps) Bi-directional

  • Material

    Heavy-Duty Extruded Aluminum

  • System Cooling

    (2) Fans with Speed Control

  • Power Supply

    65W Power Supply
    100-240 VAC, 47-63HZ

  • Ambient Temperature

    0deg. to 50deg. C

  • Storage Temperature

    -20deg. to 60deg. C

  • Relative Humidity

    5% to 85% non-condensing

  • Supported Operating Systems

    Mac OS X 10.6.8 or higher

  • Dimensions

    9.5 x 2.3 x 6.9" / 24.13 x 5.84 x 17.52 cm

  • Weight

    3.0 lbs / 1.36 kg

  • UPC Code

    748252997906

About Magma ExpressBox 1T

Enhance the power of your Thunderbolt equipped computer with the Magma ExpressBox 1T 1 Slot Thunderbolt to PCIe Expansion Chassis. This harness provides lightning-fast throughput over a single cable via Thunderbolt technology. ExpressBox 1T enables serious professionals to use specialty PCIe cards with any Thunderbolt-equipped computer, so that you can achieve high performance wherever your work takes you. Add a PCIe card to ExpressBox 1T and your computer turns into a powerful workstation capable of HD video capture and editing, media transcoding, audio processing, data processing, or high-speed storage and networks.

Magma ExpressBox 1T Features

  • Need a quiet work environment for your recording or video projects? ExpressBox 1T features quiet ventilated cooling with two user-controlled fans, allowing you to adjust fan speed and noise level based on your working environment needs
  • ExpressBox 1T offers quick and easy installation for its users. Open the chassis with two thumbscrews, no tools required. The card carriage slides right out, providing quick access to the PCIe slots and easy installation of cards
  • Attach a PCIe card to Thunderbolt equipped mobile and all-in-one computers
  • Transfer data at up to 10 Gbps. That's 2x faster than USB 3.0 and 12x faster than FireWire 800!
  • Daisy-chain up to six Thunderbolt devices
  • Use any compatible half-length PCIe card for HD video capture, audio interface, SAS/SATA HBA10 Gigabit Ethernet, 8Gb Fibre Channel, SSD data transfer and more!
  • Connect to high-resolution display, such as DisplayPort, mDP, HDMI and VGA monitors
  • Easy Plug and Play installation
  • Supports any compatible x1, x4, x8 or x16 PCIe card
  • Two Thunderbolt connectors
  • Two cooling fans with speed control
  • Rugged extruded aluminum enclosure
  • External 65W Power Supply

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Features quiet ventilated cooling with two user-controlled fans
  • Card carriage slides right out providing quick access to PCIe slots & easy installation of cards
  • Open the chassis with two thumbscrews no tools required
  • Quick and easy installation for its users
  • Attach a PCIe card to Thunderbolt equipped mobile and all-in-one computers
  • Daisy-chain up to six Thunderbolt devices

What's in the box:

  • Magma ExpressBox 1T 1 Slot Thunderbolt to PCIe Expansion
  • Power Supply
  • Magma 1 Year Warranty
