35% Off

Muxlab VGA Wall Balun II, Monitor Side, United Kingdom

SKU: ML500041WPUK MFR: 500041-WP-UK
$84.50
$130.00
Save: $45.5 (35%)
Earn VIP Reward Points

Key Features

  • Extend your VGA signal with this wall balun, reaching up to 450 feet via Cat 5E/6 cable.
  • This VGA wall plate supports resolutions up to 1280x1024, ensuring clear display quality.
  • Easily connect CRT/LCD monitors, projectors, and PCs using this user-friendly VGA balun.
  • Enjoy transparent transmission with bandwidth up to 60 MHz using this reliable VGA extender.
  • This durable VGA wall unit is designed with ABS fire retardant plastic for enhanced safety.
  • Simplify your setup; this VGA wall balun fits standard European 3.3" faceplates for easy install.
See More Product Details
Special Order?Estimated to Ship: 08/21/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$8.49

2 Year

$14.99

3 Year

$21.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Muxlab VGA Wall Balun II Specifications

  • Environment

    VGA. VESA VP&D 1.0, VIP ver 2.0

  • Devices

    CRT/LCD monitors, plasma, laptops, PCs, projectors

  • Transmission

    Transparent to the user

  • Bandwidth

    DC to 60 MHz

  • Input Signal

    Video: 1.1 Vp-p
    H &V sync: TTL standard. 300 kHz max. bandwidth

  • Insertion Loss

    Less than 3dB per pair over the frequency range

  • Common Mode Rejection Ratio

    15 kHz: -60dB typ.
    100 kHz to 10 MHz: -40dB typ.
    200 MHz: -20dB typ.

  • Return Loss

    -15dB max from DC to 60 MHz

  • Connectors

    DB15 HD Receptacle, RJ45 Shielded

  • Maximum Distance

    (via Cat 5E/6 UTP/STP Cable)
    VGA: 640x480 pixels (15 MHz), 450' / 137.16m
    SVGA: 800x600 pixels (30 MHz), 350' / 106.68m
    XGA: 1024x768 pixels (60 MHz), 250' / 76.20m
    SXGA: 1280x1024 pixels (100 MHz), 200' / 60.96m
    WXGA: 1366x768 pixels, 180' / 54.86m

  • Compatibility

    Not compatible with the VGA Balun (500010, 500011, 500014) or Active VGA Balun Kit (500035, 500036)

  • Reset Button

    May be needed when used with certain display devices

  • Grounding screw

    Grounding screw for optional use

  • Cable

    Cat 5E/6 or better unshielded twisted pair (UTP)

  • Impedance

    Input: RGB 75Ohms
    Output: RGB 100Ohms

  • Temperature

    Operating: 0 to 55 deg. C / 32 to 131 deg. F
    Storage: -20 to 85 deg. C / -4 to 185 deg. F
    Humidity: Up to 95% non-condensing

  • Enclosure

    ABS fire retardant plastic

  • Regulatory

    FCC, CE, RoHS, European Standard for 3.3" (86mm) faceplate

  • Dimensions

    86 x 86 x 36mm / 3.39 x 3.39 x 1.42"
    Choose 40mm / 1.57" deep back box to allow for Cat 5E/6 wiring connection

  • Weight

    4.1oz / 116.23g

About Muxlab VGA Wall Balun II

Where high-quality video distribution is essential, the VGA Wall Balun II (500041-WP-UK, 500043-WPUK) offers a sophisticated and streamlined solution for extending VGA signals. This innovative device eliminates the need for costly and cumbersome VGA cables by enabling a VGA source to connect to a VGA monitor through a single Cat5e/6 cable. The VGA Wall Balun II is engineered to transmit VGA video up to 350 feet (107 meters) with a resolution of 800 x 600, ensuring clear and reliable video quality over extended distances.

Crafted with durability and ease of installation in mind, the VGA Wall Balun II is designed for seamless integration into various settings, including digital signage, boardroom systems, classroom video instruction, and custom audio-video systems. Its versatile nature makes it a go-to choice for professionals seeking a reliable video distribution solution.

The 500043-WP-UK model is compatible with the 500041-WP-UK and can also be used in conjunction with the 500041 or 500042 models for added flexibility. Similarly, the 500041-WP-UK pairs with the 500043-WP-UK and is also compatible with the 500040 or 500043 models, offering a comprehensive video distribution system.

This VGA Wall Balun II features a convenient reset button, which proves invaluable when used with sync-sensitive displays, ensuring optimal performance and compatibility. Customers trust the reputable brand Muxlab, known for its commitment to high-quality products, and the VGA Wall Balun II is no exception. With its high number of positive reviews, this product stands out as an effective and well-regarded solution for video signal distribution.

Choose the VGA Wall Balun II for a professional-grade, reliable, and versatile video extension system that simplifies installation and delivers exceptional performance.

Muxlab VGA Wall Balun II Features

  • Fully supports Cat5e/6 unshielded twisted pair (UTP)
  • Cost efficient versus VGA cable
  • Compatible with 86x86mm back boxes
  • Compatible with 50x50mm faceplate opening
  • Save conduit space

Key Features

  • Extend your VGA signal with this wall balun, reaching up to 450 feet via Cat 5E/6 cable.
  • This VGA wall plate supports resolutions up to 1280x1024, ensuring clear display quality.
  • Easily connect CRT/LCD monitors, projectors, and PCs using this user-friendly VGA balun.
  • Enjoy transparent transmission with bandwidth up to 60 MHz using this reliable VGA extender.
  • This durable VGA wall unit is designed with ABS fire retardant plastic for enhanced safety.
  • Simplify your setup; this VGA wall balun fits standard European 3.3" faceplates for easy install.

What's in the box:

  • Muxlab VGA Wall Balun II
  • MuxLab Lifetime Warranty
