Muxlab 4K UHD HDMI/VGA/USB Over IP PoE Wall Plate Transmitter, White

SKU: ML500777TXWH MFR: 500777-TX-WH
Earn VIP Reward Points

Key Features

  • Easily connect your HDMI, VGA, and USB devices with this convenient wall plate transmitter.
  • Experience seamless 4K UHD video and audio transmission over IP networks using this Muxlab device.
  • This Wall Plate Transmitter supports PoE for easy installation and power, reducing cable clutter.
  • Perfect for classrooms or conference rooms, connect laptops & PCs to displays via this transmitter.
  • Enjoy high-quality video with HDMI 2.0b support, ensuring clear visuals for your presentations.
  • This durable Muxlab transmitter offers reliable performance with its robust connectivity options.
See More Product Details
Special Order?Estimated to Ship: 08/18/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$79.99

3 Year

$99.99

4 Year

$129.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Muxlab 500777-TX Specifications

  • Color

    White

  • Environment

    HDMI, VGA and USB connectivity

  • Devices

    Blu-Ray, projectors, monitors, TV, PC, laptops, servers, and Smart White Boards

  • Bandwidth

    300MHz

  • Bandwidth

    300MHz

  • Signal

    HDMI 2.0b (4K/30 4:4:4 & 4K/60 4:2:0), VGA (1920x1200), USB 2.0 and HDCP 2.2

  • Connectors

    One (1) HDMI receptacle
    One (1) Female DB15 connector for VGA
    One (1) USB Type B connector
    One (1) RJ45S for Ethernet connectivity
    One (1) 3.5mm jack for Audio-In
    One (1) 2.1mm jack for power

  • Maximum Distance

    Based on a maximum length of 6.6' (2m) of HDMI cable per end
    Cat5e/6: 330' (100m)

  • Latency

    Typical one (1) frame (16ms)

  • Compression

    JPG2000

  • Network Requirement

    1 Gig Ethernet with IGMP, Jumbo Frames and PoE

  • RJ45 Pin Configuration

    RJ45 Link:
    Pin 1 (R) Pin 2 (T)
    Pin 3 (R) Pin 6 (T)
    Pin 4 (R) Pin 5 (T)
    Pin 7 (R) Pin 8 (T)

  • Power Source

    This device supports PoE (PD), an external power supply is not included. It is intended to be powered via a PoE (PSE) Ethernet Switch. If required, an optional power supply (500993) may be purchased separately

  • PoE

    IEEE 802.3af

  • Power Consumption

    3W

  • Temperature

    Operating: 32 to 104 Degree F (0 Degree to 40 Degree C)
    Storage: -4 to 185 Degree F (-20 Degree to 85 Degree C)
    Humidity: Up to 95% non-condensing

  • Compliance

    Regulatory: FCC, CE, RoHS
    Flammability: 94V0

  • Dimensions

    4.53 x 4.53 x 2.05" (115 x 115 x 52mm)

  • Weight

    1.35 lbs (612.3g)

  • UPC Code

    00627699917770

About Muxlab 500777-TX

The HDMI/VGA/USB over IP PoE Wall Plate Transmitter allows HDMI, VGA and USB equipment to be connected up to 330ft (100m), with video supported at up to 4K (3840 x2160) resolution @ 30Hz via one (1) Cat5e/6 unshielded twisted pair cable in a point-to-point configuration. The USB port may be used for extending various USB devices including Smart Boards. Point-to-multipoint and multipoint-to-multipoint configurations are also possible by connecting several Transmitters and Receivers to the same local Ethernet IP network via an Ethernet Switch. The HDMI/VGA/USB over IP PoE Wall Plate Transmitter also supports PoE (PD) if used with a PoE (PSE) Ethernet Switch. Additional Transmitters may be purchased separately depending on the intended application and number of units required.

For the point-to-multipoint and multipoint-to-multipoint configuration the Ethernet Switch must have Gigabit ports, Jumbo Frame capability, DHCP Server capability, PoE, and additionally support the IGMP communication protocol for the multipoint-to-multipoint case. Muxlab recommends using the Cisco SG300 or SG500 Series Managed Switches.

The Muxlab ProDigital Network Controller is available to simplify the configuration and utilization of the 500777-TX and other Muxlab IP based products via an Ethernet web interface. The Muxlab Control Android and iOS Application may also be used for connectivity management, in combination with the Network Controller.

Applications
Applications include commercial and residential AV systems, classroom systems, digital signage, boardroom systems, conference rooms, and collaborative PC systems.

Muxlab 500777-TX Features

  • HDMI 2.0b up to 4K @ 30Hz (4:4:4) and 4K @ 60Hz (4:2:0)
  • VGA 1920 x1200 @ 60Hz, with 2CH Audio-In
  • Selectable HDMI / VGA with Audio inputs, with auto switching capability
  • Remotely managed over IP & locally managed via push button
  • Extend HDMI, VGA with 2CH Audio, and USB 2.0 up to 330' (100m) over Cat5e/6 cable
  • HDCP 2.2 compliant
  • Compatible with 500758-RX and 500759-RX over IP Receivers
  • PoE powered
  • Available in aluminum and white finish
  • Managed via Pro Digital Network Controller (500812), MuxlabControl Smartphone & Tablet App & 3rd Party Control Apps

Warranty Information

This product has a limited warranty of 36 months.

Key Features

  • Easily connect your HDMI, VGA, and USB devices with this convenient wall plate transmitter.
  • Experience seamless 4K UHD video and audio transmission over IP networks using this Muxlab device.
  • This Wall Plate Transmitter supports PoE for easy installation and power, reducing cable clutter.
  • Perfect for classrooms or conference rooms, connect laptops & PCs to displays via this transmitter.
  • Enjoy high-quality video with HDMI 2.0b support, ensuring clear visuals for your presentations.
  • This durable Muxlab transmitter offers reliable performance with its robust connectivity options.

What's in the box:

  • Muxlab 4K UHD HDMI/VGA/USB Over IP PoE Wall Plate Transmitter (White)
  • Muxlab 3 Year Limited Warranty
