Manley Labs Stereo Variable Mu Limiter Compressor, Mastering Version with M/S & T-Bar Mod

SKU: MLMMSSLCMSTB MFR: MMSSLCHPMSTBAR
Earn VIP Reward Points

Key Features

  • Achieve pristine sound quality with the Manley Stereo Variable Mu Limiter Compressor.
  • Use as a dynamic processor for mastering to get that radio-ready, polished sound.
  • Enjoy versatile compression ratios, from subtle 1.5:1 to aggressive 20:1 limiting.
  • Utilize the M/S & T-Bar mod for enhanced stereo imaging and precise control.
  • Experience user-friendly operation with illuminated Sifam meters for visual feedback.
  • Rely on the durability of premium tubes like 5670, 5751, and 12AL5 for lasting value.
See More Product Details
Special Order?Estimated to Ship: 08/15/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$499.99

3 Year

$649.99

5 Year

$949.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Manley Labs Compressor Specifications

  • Number of Channels

    2

  • Inputs

    2x XLR transformer balanced (600Ohms)

  • Outputs

    2 x XLR transformer balanced (600Ohms)

  • Input Level

    Input Level Switch: -8, -4, -2, -1, 0, +1, +2, +4, and +8 dB

  • Compression Threshold

    Continuously variable threshold for compression and limiting

  • Ratio

    Compressor: 1.5:1
    Limiter: 4:1 to 20:1

  • Attack Time

    Variable Attack: 25 to 70ms

  • Release Time

    Recovery 5 Steps: 0.2, 0.4, 0.6, 4.0, 8.0 sec

  • Maximum Output Level

    +3 dBu (26 Vrms) 26dB Headroom

  • Make-up Gain

    +35dB

  • Frequency Response

    20Hz to 25kHz

  • THD & Noise

    <0.1% THD at 1kHz
    Noise Floor: -85 dB typical

  • Meter

    Illuminated Sifam meters

  • Tubes per Side

    Fully Differential All-Tube Circuitry: 5670, 5751 (or 12AX7), 7044 (or 5687) & 12AL5
    (T-Bar mod replaced 5670s with 2 pairs of 6BA6s)

  • High Pass Filter

    HP SC: High-Pass Side-Chain Filter:
    -1 to -3dB at 100Hz
    -4 to -6dB at 50Hz

  • Rackmountable

    2U

  • Power Supply

    120 VAC, 80W, 60Hz

  • Fuse

    Mains Fuse Value: 1.25A
    Mains Fuse Type: MDA or MDL SLO-BLO Time Delay: 1-1/4" x 1/4"

  • Dimensions (W x H x D)

    19.0 x 3.5 x 10.0" / 48.26 x 8.89 x 25.40cm
    Power Transformer protrudes 3.5" / 8.89cm out back of chassis

  • Weight

    14.0lbs / 6.35kg

About Manley Labs Compressor

You can elevate your audio mastering experience with the Manley Labs Stereo Variable Mu Limiter Compressor, a high-quality, professional-grade audio tool that has been a best-seller for years. This innovative device is a staple in mastering studios worldwide and has played a significant role in the production of hit records over the last decade, and likely many more to come.

The term "Mu" is tube jargon for gain, and "Variable Mu" is Manley Labs' registered trademark for this advanced limiter compressor. Its unique operation is based on the "remote cut-off" or re-biasing of a vacuum tube to achieve compression, a technique also used by the esteemed vintage Fairchild 670, making it one of the few all-tube compressors known to use this method.

At the heart of the peak-reducing and compression action is the unique 5670 dual triode. This component is continuously re-biased by the vacuum tube rectified side-chain control voltages, enabling the tube to smoothly alter its gain. The Compress mode offers a soft-knee 1.5 to 1 ratio, while the sharper knee Limit mode starts at 4 to 1, escalating to a dramatic ratio of 20 to 1 when limiting over 12dB. Interestingly, the knee softens as more limiting is applied.

The Stereo Variable Mu Limiter Compressor also allows for creative use of distortion. By increasing the Input and decreasing the Output while using minimal or no compression, you can add a unique touch to your audio. The device features a ganged input control, but rest assured, it is far from mono-unfriendly. With separate threshold and output controls, you can easily make compensations. Moreover, the stereo input control proves its worth when you switch to LINK mode, making this device an unparalleled tool for final mix, 2-track, or mastering limiting and compression.

In the words of one reviewer, using the Manley Labs Stereo Variable Mu Limiter Compressor is "like pouring a bowl of sweet cream over the mix." Experience the difference this durable, advanced audio equipment can make in your audio mastering process.

Manley Labs Compressor Features

  • Manley input & output transformers with nickel laminations in mu-metal cases with flat frequency response from 20Hz-25KHz
  • Balanced Inputs and Outputs (600 Ohms)
  • Fully differential ALL-TUBE circuitry using one each 5670, 5751 (or 12AX7), 7044 (or 5687) & 12AL5 per channel
  • Independently regulated B+ and Heater supplies
  • Hard-wire BYPASS switch
  • Stepped switch Input attenuator as of 10/2011. (older units use Silent dual-ganged potentiometer)
  • Recovery 5 steps: 0.2s, 0.4s, 0.6s, 4sec., 8sec
  • Variable attack: 25msec-70msec
  • Continuously variable threshold
  • Limit (4:1 to 20:1) or Compress (1.5 to 1)
  • HP SC: High Pass Side Chain Filter -3dB at 100Hz
  • Large Illuminated Sifam meters (older units before serial number MSLC61642 shipped before 12/2003 use: 26V 1.2W FesFESTOON LAMPS; Manley's Part Number: VAR016B) Order spare bulbs using our parts order form. (newest units after serial number MSLC61642 shipped after 12/2003 use white LED lighting)
  • Stereo Link Switch
  • Several units can be linked for Surround (custom order )
  • Maximum gain: 35dB
  • Max. output: +30dBu (26Vrms) 26dB Headroom
  • Less than 0.1% THD at 1KHz Noise floor: -85dB typical
  • Power Consumption (120/240VAC): 80 watts
  • Unit is factory set for 100V, 120V or 220-240VAC operation for original destination country's mains voltage
  • Operating Mains Voltage changeable with power transformer changeover switch and fuse value change
  • Mains Fuse Value for 100-120VAC operation: replace with 1.25A as of 10/2011
  • Mains Fuse Value for 220-240VAC operation: replace with 0.6A (600mA) as of 10/2011
  • Mains Fuse Type: MDA or MDL SLO-BLO Time delay 1 1/4" x 1/4"
  • Mains Voltage Frequency: 50-60Hz

Product Documents

User Manual

Key Features

  • Achieve pristine sound quality with the Manley Stereo Variable Mu Limiter Compressor.
  • Use as a dynamic processor for mastering to get that radio-ready, polished sound.
  • Enjoy versatile compression ratios, from subtle 1.5:1 to aggressive 20:1 limiting.
  • Utilize the M/S & T-Bar mod for enhanced stereo imaging and precise control.
  • Experience user-friendly operation with illuminated Sifam meters for visual feedback.
  • Rely on the durability of premium tubes like 5670, 5751, and 12AL5 for lasting value.

What's in the box:

  • Manley Labs Stereo Variable Mu Limiter Compressor
  • IEC Power Cable
  • Manley 90 Day Limited Warranty (with 5 Year with Registration)
