What operating systems is the MOTU Micro Express 4x6 USB MIDI Interface compatible with?

The MOTU Micro Express 4x6 USB MIDI Interface is compatible with both Mac and PC systems. The included ClockWorks console software supports Mac OS X and Windows 7/Vista.

What are the one-touch presets on the MOTU Micro Express 4x6 USB MIDI Interface?

The MOTU Micro Express 4x6 USB MIDI Interface features 16 one-touch presets, including 8 that are factory-set and 8 that are user-programmable. These presets allow for quick access to different operational configurations.

What is the purpose of the SMPTE time code synchronization feature on the MOTU Micro Express 4x6 USB MIDI Interface?

The SMPTE time code synchronization feature on the MOTU Micro Express 4x6 USB MIDI Interface allows for precise syncing across multiple devices. It can convert and stripe time code in all frame formats, ensuring smooth and glitch-free synchronization.

Can the MOTU Micro Express 4x6 USB MIDI Interface be expanded?

Yes, the MOTU Micro Express 4x6 USB MIDI Interface is designed for easy expansion. You can connect additional sound modules or synths via any available USB port.

What does the MIDI Machine Control (MMC) feature do on the MOTU Micro Express 4x6 USB MIDI Interface?

The MIDI Machine Control (MMC) feature on the MOTU Micro Express 4x6 USB MIDI Interface allows the interface to function as either an MMC master or slave. This means it can distribute transport commands to all connected MMC devices, facilitating comprehensive device management.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

MOTU Micro Express 4x6 USB MIDI Interface with Timecode for Mac and PC Specifications

  • Connection

    USB

  • MIDI In

    4

  • MIDI Out

    6

  • Activity Indicators

    In and Out on each port

  • Multiple Units

    Yes

  • Stand-Alone

    Stand-alone MIDI patchbay / merger / processor

  • Bypass/Panic

    Panic button

  • Synchronizer

    Stripes SMPTE time code in all frame rates (24, 25, 29.97 drop, 29.97 non-drop, 30)
    Converts LTC to MIDI Time Code (MTC) to sync a Mac, PC or any other devices to SMPTE time code
    Front panel SMPTE stripe button
    Front panel SMPTE lock and tach LED's

  • System Requirements

    USB equipped Mac or PC

  • Specialties

    MIDI Time Stamping (MTS) ready

  • Rack Height

    With rack ears attached, fits one half of a standard 19 inch (48.26 cm) rack at 1U high

  • Dimensions

    Chassis Excluding rack ears: 9.50 x 7.00 x 1.75" (24.13 x 17.78 x 4.44cm)

  • UPC Code

    839128005136

0 Accessories for MOTU Micro Express 4x6 USB MIDI Interface with Timecode for Mac and PC

About MOTU Micro Express 4x6 USB MIDI Interface with Timecode for Mac and PC

You can elevate your music production and live performance capabilities with the MOTU Micro Express 4x6 USB MIDI Interface with Timecode, a compact yet advanced version of the acclaimed MIDI Express XT. This professional-grade interface is designed to seamlessly integrate with both Mac and PC systems, offering unparalleled versatility for musicians, producers, and audio engineers.

Crafted for high-quality performance, the Micro Express USB is a sleek half-rack unit equipped with 4 inputs and 6 outputs, providing ample connectivity for your MIDI devices. With 96 MIDI channels at your disposal, you can manage complex setups with ease. The interface's full Time Code and MIDI Machine Control implementation ensure that it meets the rigorous demands of professional studio environments.

Innovative and user-friendly, the Micro Express stands out with its 16 convenient one-touch presets, including 8 factory and 8 user-programmable options. These presets allow instant access to various operational configurations directly from the front panel, streamlining your workflow.

The included ClockWorks console software enhances your MIDI routing, merging, and muting capabilities, offering a comprehensive control solution for both Mac OS X and Windows 7/Vista users.

As a top-tier SMPTE time code synchronizer, the Micro Express excels in converting and striping time code across all frame formats, such as 23.976, 24, 25, 29.97 drop and non-drop, and 30. Its SMPTE "jam sync" feature with adjustable freewheeling ensures smooth and glitch-free synchronization.

The interface's support for MIDI Machine Control (MMC) allows it to function as either an MMC master or slave, distributing transport commands to all connected MMC devices for cohesive device management.

Enhance your expressive capabilities during live performances by connecting a foot switch to the front-panel pedal input. Program it to generate MIDI data upon activation, such as sending patch changes to synths and sound modules, adding a new dimension to your stage presence.

The Micro Express is also designed for convenience with its expandable, plug-and-play bus-powered USB operation. High-speed MIDI throughput and sub-millisecond timing accuracy are guaranteed, along with the flexibility of "hot-swapping" and easy expansion. Simply connect additional sound modules or synths via any available USB port, and because it's bus-powered, the Micro Express is ready to accompany you wherever your music takes you.

Choose the MOTU Micro Express 4x6 USB MIDI Interface with Timecode for a reliable, professional, and innovative solution that brings precision and versatility to your musical endeavors.

MOTU Micro Express 4x6 USB MIDI Interface with Timecode for Mac and PC Features

  • Compact 4x6 USB MIDI Interface with Timecode for seamless Mac and PC integration
  • Professional-grade performance with 4 inputs, 6 outputs, and 96 MIDI channels
  • 16 one-touch presets for instant configuration and streamlined workflow
  • Advanced SMPTE time code synchronization across all frame formats
  • MIDI Machine Control (MMC) compatibility for comprehensive device management
  • Bus-powered with plug-and-play functionality for easy expansion and portability

Product Documents

User Manual

Key Features

  • Compact 4x6 USB MIDI Interface with Timecode for seamless Mac and PC integration
  • Professional-grade performance with 4 inputs, 6 outputs, and 96 MIDI channels
  • 16 one-touch presets for instant configuration and streamlined workflow
  • Advanced SMPTE time code synchronization across all frame formats
  • MIDI Machine Control (MMC) compatibility for comprehensive device management
  • Bus-powered with plug-and-play functionality for easy expansion and portability

What's in the box:

  • MOTU Micro Express 4x6 USB MIDI Interface with Timecode
  • USB Cable
  • Software Console for Macintosh and Windows
  • MOTU 90 Day Warranty
