Magenta Research Voyager Multimode USB 4 Port Hub Remote Transceiver

SKU: MV2350201MM MFR: 2350201-MM
Earn VIP Reward Points

Key Features

  • Extend your USB connections up to 10km with this Magenta Research USB Extender over fiber!
  • This 4-Port USB hub supports speeds up to 480Mbps for efficient data transfer and performance.
  • Connect up to 14 USB devices or 3 USB hubs, offering versatile connectivity with this KVM switch.
  • Each USB port provides 500mA, ensuring reliable power for your connected USB devices.
  • The robust aluminum enclosure protects the USB hub, ensuring durability and a long lifespan.
  • This USB KVM extender supports a wide temperature range, suitable for various environments.
See More Product Details
Special Order?Estimated to Ship: 08/15/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$174.99

3 Year

$224.99

4 Year

$299.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Magenta Research Remote Transceiver Specifications

  • Range

    Up to 1640.42'/ 500m over OM2 or greater
    Up to 902.23'/ 275m over OM1
    Up to 10Km (6.2 miles) over OS1 (single mode SFPs required)

  • Speeds

    USB 2.0: Up to 480Mbps
    USB 1.1: Up to 12Mbps

  • USB Hub Support

    Any single chain can include up to 3 USB hubs plus one Voyager USB

  • USB Host Support

    xHCI (USB 3.0) at USB 2.0 speed, EHCI (USB 2.0) and OHCI/UHCI (USB 1.1)

  • Maximum USB devices supported

    14 USB devices or 3 USB hubs with 11 USB devices

  • AC Adapter

    Input: 100 / 240V AC, 50 to 60Hz, 600mA maximum
    Output: 5V DC, 3A

  • AC Adapter Connector

    1.7mm centre-positive jack

  • Remote Transceiver: USB Connector

    4x USB Type A Receptacles

  • Remote Transceiver: Link Connector

    1x SFP Duplex LC

  • Remote Transceiver: Enclosure Material

    Black Anodized Aluminum

  • Remote Transceiver: Available Current

    500mA to each USB port

  • Compliance: EMC

    FCC (Class B), IC (Class B), CE (Class B)

  • Compliance: Environmental

    RoHS2 (CE)

  • Voyager Matrix

    CPU and REMOTE Transceivers require Simplex I/O cards when integrated with VG-Matrix

  • Operating temperature range

    0 to 50 deg. C / 32 to 122 deg. F

  • Storage temperature range

    -20 to 70 deg. C / -4 to 158 deg. F

  • Operating Humidity

    20 to 80% relative humidity, non-condensing

  • Storage Humidity

    10 to 90% relative humidity, non-condensing

  • Dimensions (W x H x D)

    Remote Transceiver: 3.94 x 2.99 x 1.02" / 100 x 76 x 26mm

About Magenta Research Remote Transceiver

An innovative solution for extending the reach of your USB peripheral devices, the Voyager Multimode USB 4 Port Hub Remote Transceiver is a high-quality, durable, and efficient device that breaks the standard 5m cable limit. This advanced USB 2.0 Fiber Optic KVM extender allows you to position your USB devices up to an impressive 500 meters from your computer, making it an ideal choice for professional settings such as control rooms or studios.

Comprising two distinct units, the CPU Transceiver (UDM-USB-CPU) and the REMOTE Transceiver (UDM-USB-REM), the Voyager Multimode USB 4 Port Hub Remote Transceiver offers unparalleled flexibility. For added convenience, these units can also be ordered as a pair under the designation UDM-USB-KIT.

Designed with user-friendly features, this reliable USB extender offers transparent USB extension and true plug-and-play functionality, eliminating the need for software drivers. It's compatible with all major operating systems, including Windows, Mac OS X, and Linux, ensuring seamless integration into your existing setup.

Moreover, the Voyager Multimode USB 4 Port Hub Remote Transceiver is compatible with Voyager VG Matrix Routers: VG-160 and VG-48, further enhancing its versatility and making it a valuable addition to any professional tech environment. Experience the convenience and efficiency of extended USB connectivity with the Voyager Multimode USB 4 Port Hub Remote Transceiver.

Magenta Research Remote Transceiver Features

  • Extends USB connectivity up to 500 meters for superior device management
  • High-quality 4-port USB 2.0 Fiber Optic KVM extender for professional environments
  • Durable and reliable design with CPU and REMOTE Transceiver units
  • User-friendly plug-and-play setup; no software drivers required
  • Compatible with Windows, Mac OS X, and Linux operating systems
  • Efficient integration with Voyager VG Matrix Routers: VG-160 and VG-48

Key Features

  • Extend your USB connections up to 10km with this Magenta Research USB Extender over fiber!
  • This 4-Port USB hub supports speeds up to 480Mbps for efficient data transfer and performance.
  • Connect up to 14 USB devices or 3 USB hubs, offering versatile connectivity with this KVM switch.
  • Each USB port provides 500mA, ensuring reliable power for your connected USB devices.
  • The robust aluminum enclosure protects the USB hub, ensuring durability and a long lifespan.
  • This USB KVM extender supports a wide temperature range, suitable for various environments.

What's in the box:

  • Magenta Research Voyager Multimode USB 4 Port Hub Remote Transceiver
  • Multimode Fibre Optic SFP Module
  • Power Supply Unit
  • Magenta Research 2 Year Warranty
