Magenta Research Voyager Singlemode USB 4 Port Hub Remote Transceiver

SKU: MV2350201SM MFR: 2350201-SM
Earn VIP Reward Points

Key Features

  • Extend your USB connectivity up to 10km with this Singlemode USB 4 Port Hub transceiver.
  • Experience reliable performance with speeds up to 480Mbps using this USB KVM extender.
  • Connect up to 14 USB devices or 3 USB hubs, expanding your workstation's capabilities easily.
  • This Magenta Research Voyager supports xHCI, EHCI, and OHCI/UHCI USB host connections.
  • Ensure seamless integration with Voyager Matrix using Simplex I/O cards for CPU and remote.
  • Durable aluminum enclosure protects your USB 4 Port Hub, ensuring long-lasting connectivity.
See More Product Details
Special Order?Estimated to Ship: 08/18/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$209.99

3 Year

$299.99

4 Year

$359.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Magenta Research Remote Transceiver Specifications

  • Range

    Up to 1640.42'/ 500m over OM2 or greater
    Up to 902.23'/ 275m over OM1
    Up to 10Km (6.2 miles) over OS1 (single mode SFPs required)

  • Speeds

    USB 2.0: Up to 480Mbps
    USB 1.1: Up to 12Mbps

  • USB Hub Support

    Any single chain can include up to 3 USB hubs plus one Voyager USB

  • USB Host Support

    xHCI (USB 3.0) at USB 2.0 speed, EHCI (USB 2.0) and OHCI/UHCI (USB 1.1)

  • Maximum USB devices supported

    14 USB devices or 3 USB hubs with 11 USB devices

  • AC Adapter

    Input: 100 / 240V AC, 50 to 60Hz, 600mA maximum
    Output: 5V DC, 3A

  • AC Adapter Connector

    1.7mm centre-positive jack

  • Remote Transceiver: USB Connector

    4x USB Type A Receptacles

  • Remote Transceiver: Link Connector

    1x SFP Duplex LC

  • Remote Transceiver: Enclosure Material

    Black Anodized Aluminum

  • Remote Transceiver: Available Current

    500mA to each USB port

  • Compliance: EMC

    FCC (Class B), IC (Class B), CE (Class B)

  • Compliance: Environmental

    RoHS2 (CE)

  • Voyager Matrix

    CPU and REMOTE Transceivers require Simplex I/O cards when integrated with VG-Matrix

  • Operating temperature range

    0 to 50 deg. C / 32 to 122 deg. F

  • Storage temperature range

    -20 to 70 deg. C / -4 to 158 deg. F

  • Operating Humidity

    20 to 80% relative humidity, non-condensing

  • Storage Humidity

    10 to 90% relative humidity, non-condensing

  • Dimensions (W x H x D)

    Remote Transceiver: 3.94 x 2.99 x 1.02" / 100 x 76 x 26mm

About Magenta Research Remote Transceiver

The Voyager USB 2.0 Fiber Optic KVM extender enables users to extend beyond the standard 5m cable limit for USB peripheral devices. With the Voyager USB 2.0 Fiber Optic KVM extender, USB devices can be located up to 500 meters from the computer. The Voyager USB 2.0 Fiber Optic KVM extender is composed of two individual units: the CPU Transceiver (UDM-USB-CPU) and the REMOTE Transceiver (UDM-USB-REM) They can also be ordered as a pair (UDM-USB-KIT).

The Voyager USB 2.0 Fiber Optic KVM extender includes the Voyager USB suite of features:
• Transparent USB extension
• True plug and play; no software drivers required
• Works with all major operating systems: Windows, Mac OS X and Linux

Compatible with Voyager VG Matrix Routers: VG-160 and VG-48

Key Features

  • Extend your USB connectivity up to 10km with this Singlemode USB 4 Port Hub transceiver.
  • Experience reliable performance with speeds up to 480Mbps using this USB KVM extender.
  • Connect up to 14 USB devices or 3 USB hubs, expanding your workstation's capabilities easily.
  • This Magenta Research Voyager supports xHCI, EHCI, and OHCI/UHCI USB host connections.
  • Ensure seamless integration with Voyager Matrix using Simplex I/O cards for CPU and remote.
  • Durable aluminum enclosure protects your USB 4 Port Hub, ensuring long-lasting connectivity.

What's in the box:

  • Magenta Research Voyager Singlemode USB 4 Port Hub Remote Transceiver
  • Singlemode Fibre Optic SFP Module
  • Power Supply Unit
  • Magenta Research 2 Year Warranty
