Marantz PMD-526C Specifications

  • Channels

    2x, stereo

  • Frequencies Supported

    10 Hz to 20 kHz, +/-1 dB

  • Dynamic Range

    > 85 dB (10 Hz to 20 kHz, A-weighted)

  • Signal-to-Noise Ratio

    > 90 dB (1 kHz, 0 dB, A-weighted)

  • Channel Separation

    > 80 dB (1 kHz, 0 dB, A-weighted)

  • Total Harmonic Distortion

    < 0.01% (1 kHz, 0 dB, A-weighted)

  • Analog Output Type

    2x RCA (unbalanced)
    2xxLR (balanced)

  • Load Impedance

    > 10kOhms

  • Output Level

    Unbalanced: 2 Vrms / at 10 kOhms load
    Balanced: +4 dBu

  • Input Type

    1x 3.5mm TRS terminal

  • Input Impedance

    > 10 kOhms

  • Maximum Input Level

    1 Vrms

  • Bluetooth Class

    Output class: Class 2

  • Bluetooth Version

    4

  • Bluetooth Supported Profiles

    A2DP, AVRCP, HFP, SPP, BAS, BLE, DIS, FMP, HRP, HRS, HTP, HTS, IAS, LLS

  • Bluetooth Range

    49' (15m)

  • IR

    Infrared Transmission Protocol: NEC format
    Transmit output level: > 200 mVp-p

  • Serial

    D-sub 9-pin female RS-232C
    Mode: Full duplex
    Baud rate: 9600/38400 b/s (selectable in the menu)
    Data: 8-bits
    Start bit: 1 bit
    Stop bit: 1 bit
    Parity: none
    Flow control: none

  • Sample Rate

    CD-DA, Audio file 44.1 kHz

  • Word Length

    CD-DA, Audio file 16-bit

  • File Format

    WAV / MP3 / AAC

  • Bit Rate

    MP3, AAC, CBR / VBR ST / Mono 32 to approximately 320 kps

  • D3 Tag

    MP3 V1.x 2.4

  • CD Player

    File System: CD-DA (CD-TEXT), CD-ROM (ISO9660)
    Disc: CD, CD-R

  • USB

    File system: FAT 16/32
    Media type: Flash/ HDD

  • SD Format Support

    File system: FAT 16/32

  • Operating Temperature

    41 to 95 deg. F (5 - 35 deg. C)

  • Operating Humidity

    25 to approximately 85% non-condensing

  • LCD Display

    LCD 2 lines, 16 characters x 2 lines LCM display

  • Power Requirements

    100 to 230 VAC

  • Power Consumption

    15 W

  • Dimensions (W x H x D)

    19 x 1.7 x 9.4" (483 x 240 x 44mm)

  • Weight

    6.4lbs (2.9kg)

  • UPC Code

    694318022214

About Marantz PMD-526C

The Marantz Professional PMD-526C is a highly versatile yet affordable media player that excels in applications where users bring their own devices to the venue. The PMD-526C plays not only CD media but provides Bluetooth connectivity, USB playback, SD card functionality and a 3.5mm AUX input. Perfect for both advanced individual users and commercial applications, this player features Bluetooth Pairing, Front Panel Lock, Power On Play, direct access to tracks, memory of settings after loss of power, RS-232c control and balanced XLR output.

The PMD-526C offers the kind of performance, build quality and versatility that is difficult to find even on competitive units costing several hundreds of dollars more. Perfect for retail, education and hotel/conference applications, this player also features pitch control and tempo lock, making it ideal for dance and fitness applications.

Marantz PMD-526C Features

  • Bluetooth 4.0 pairing to (8) devices
  • Slot-loading CD transport
  • Playback from SD/SDHC media
  • USB host port for file playback
  • Pitch and Tempo Control
  • 10-button direct track access
  • 3.5mm AUX input for playback from portable players
  • RS-232c control capable
  • Balanced (XLR) and unbalanced (RCA) outputs
