NEC AS242W 24" Full HD Widescreen Desktop LED Monitor, Black
See all NEC items

NEC AS242W 24" Full HD Widescreen Desktop LED Monitor, 1920x1080, Black

SKU: NCAS242WBK
Be the first to review this item

This item is no longer available.

Recommended Alternatives

NEC MultiSync EA271Q: Picture 1 regular
NEC EA271Q 27" WQHD PLS LED Monitor, Integrated Speakers, SpectraViewII Software
$769.00
See More Recommendations
Overview
Compare
Accessories
Specs
Protection

Reviews about this item

Review Summary

NEC AS242W Specifications

  • Panel Technology

    TN

  • Viewable Image Size

    24"

  • Aspect Ratio

    16:9

  • Native Resolution

    1920 x 1080

  • Pixel Pitch

    0.27mm

  • Pixels Per Inch

    94 at native resolution

  • Backlight Type

    W-LED

  • Brightness

    250cd/m2 (typical)

  • Contrast Ratio

    1000:1 (typical)

  • Viewing Angle

    Vertical: 170 deg.
    Horizontal: 176 deg.
    (85U/85D/88L/88R) at CR>5

  • Response Time

    5ms (typical)

  • Colors

    More than 16.7 million

  • Synchronization Range

    Horizontal (Analog/Digital): 31.5 to 81.1kHz
    Vertical: 56 to 76 Hz

  • Video Input Signal

    Analog RGB 0.7Vp-p/75Ohms

  • Sync Input Signal

    Separate Sync: TTL Level (Positive/Negative)
    Composite Sync: TTL Level (Positive/Negative)
    Composite Sync on Green: (0.3Vp-p negative 0.7Vp-p positive)

  • Input Connectors

    DVI-D, VGA 15-pin D-sub

  • VESA Hole Configuration

    100 x 100mm

  • Environmental Compliance

    ENERGY STAR: 6.0
    TCO: 6.0
    EPEAT: Silver
    RoHS: Yes

  • Power Consumption

    On: 19W
    Power Savings Mode: 0.45W (typical)

  • Operating Temperature

    41 to 95 deg. F / 5 to 35 deg. C

  • Storage Temperature

    14 to 140 deg. F / -10 to 60 deg. C

  • Operating Humidity

    20 to 80%

  • Storage Humidity

    10 to 85%

  • Operating Altitude

    6562' / 2000.1m

  • Storage Altitude

    40000' / 12192m

  • Additional Functions

    ECO Mode
    Carbon footprint meter
    Tilt
    Rapid Response
    Ambix
    XtraView
    NaViSet software
    VESA mount
    HDCP
    DDC/CI
    No Touch Auto Adjust
    Plug and Play (VESA DDC 2B)
    VESA DPMS power management
    AccuColor color control
    Digital smoothing
    Digital controls
    ISO 9241-307 Class I

  • Dimensions (W x H x D)

    With stand: 22.5 x 15.8 x 8.3" / 571.5 x 401.32 x 210.82mm
    Without stand: 22.5 x 13.8 x 2" / 571.5 x 350.52 x 50.8mm

  • Weight

    With stand: 8.8lbs / 3.99kg
    Without stand: 7.9lbs / 3.58kg

  • UPC Code

    805736054637

0 Accessories for NEC AS242W 24" Full HD Widescreen Desktop LED Monitor, 1920x1080, Black

About NEC AS242W

The 24" NEC AccuSync AS242W, a widescreen monitor boasting tremendous value, enhances your desktop computing with full HD resolution and eco-friendly benefits. The LED backlighting of this monitor permits a slimmer profile, lighter weight and increased power savings compared to previous generation models, while ECO Mode helps extend the life of the product. Additional benefits include a carbon footprint meter and Rapid Response technology, both of which make this model ideal for small-to-medium-sized businesses, schools and government offices.

NEC AS242W Features

  • LED backlight technology provides for industry-leading low power consumption and less hazardous materials
  • Ambix dual-input technology allows for digital/analog compatibility with upgraded video cards and software as well as connection to two systems
  • Rapid Response technology delivers virtually uninterrupted, undistorted viewing of high-speed, full-motion video
  • ECO Mode function helps save power, reduce heat and extend the life of the display by allowing you to dim the backlight
  • Carbon footprint meter helps track and calculate the reduction of green gas emissions
  • NaViSet Administrator 2: Free software solution that greatly eases administration and management of larger display device installations

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Carbon footprint meter helps track and calculate the reduction of green gas emissions

What's in the box:

  • NEC AS242W 24" Full HD Widescreen Desktop LED Monitor
  • Setup Sheet
  • User Manual
  • Power Cord
  • 15-pin D-sub Cable
  • NEC 3 Year Parts and Labor Limited Warranty (Including Backlight)
