NEC Large Touch Display Specifications

Display

Display

Jump to...
  • Panel Technology

    VA

  • Viewable Image Size

    65"

  • Native Resolution

    1920 x 1080

  • Pixel Pitch

    0.75mm

  • Backlight Type

    LED Direct-lit

  • Pixels Per Inch

    33.89@ native resolution

  • Brightness (typical)

    400cd/m square

  • Contrast Ratio (typical)

    4000:1

  • Viewing Angle

    176 Degree Vertical, 176 Degree Horizontal (88U/88D/88L/88R) @ CR>10

  • Response Time (Gray to Gray)

    8ms

  • Refresh Rate

    60Hz

  • Aspect Ratio

    16:9

  • Active Screen Area

    56.2 x 31.6" (142.8 x 80.35 cm)

  • Orientation

    Landscape/Portrait

  • Displayable Colors

    More than 16.7 million

Synchronization Range

Jump to...
  • Horizontal (Analog/Digital)

    Analog: 15.625/15.734/31.5-91.1 kHz Digital: 31.5 - 91.1 KHz

  • Vertical

    Analog: 50-85 Hz Digital: 50.0 - 85.0 Hz

Input Signal

Jump to...
  • Video

    Analog RGB 0.7 Vp-p/75 Ohms (Analog), TMDS (Digital)

  • Sync

    Separate sync: TTL Level (Positive/Negative)
    Composite sync on green: (0.3Vp-p negative 0.7Vp-p positive)

Connectivity

Jump to...
  • PC Signal Compatibility

    Yes

  • Macintosh Compatibility

    Yes (for video only)

  • Input Terminal Digital

    HDMI (3)

  • Input Terminal Analog

    VGA 15-pin D-sub

  • Input Terminal Audio

    3.5mm Mini-Jack

  • Output Terminal Audio

    3.5mm Mini-Jack

Power Consumption (typical)

Jump to...
  • On

    140W

  • ECO Mode Standby

    <0.5W

  • Power Consumption (max brightness) On

    190W

  • Power Consumption (typical)

    <2.0W

Power Consumption

Jump to...
  • Input Current

    2.5A - 0.9A @ 100V - 240V

VESA Hole Configuration

Jump to...
  • VESA Hole

    400 x 400 mm (M8 x 4-hole)

Environmental Conditions

Jump to...
  • Operating Temperature

    32-104 Degree F (0-40 Degree C)

  • Operating Humidity

    10-80%

  • Operating Altitude

    6562' (2000 m)

  • Storage Temperature

    -4-140 Degree F (-20-60 Degree C)

  • Storage Humidity

    10-80%

Physical Specifications

Jump to...
  • Bezel Width (Left/Right, Top/Bottom)

    1.2"/1.2", 1.2"/1.2"; 30.0mm/30.0mm, 30.2mm/30.2mm

  • Dimensions (W x H x D)

    Without stand: 58.6 x 34.0 x 3.4" (148.95 x 86.45 x 8.67 cm)

  • Weight

    Without stand: 93.0 lb (42.2 kg)

  • UPC Code

    805736065237

About NEC Large Touch Display

NEC's 65" E651-T large-screen LCD display offers digital signage and education users commercial touchscreen capabilities at a cost-conscious price. This display also utilizes LED-backlighting to minimize depth and power consumption. Within the E651-T bezel is integrated, low-profile, IR-imaging technology that allows for up to ten simultaneous touches. Its anti-glare glass coating protects the panel and allows for higher brightness transmittance making this display ideal for the in-classroom environment

NEC Large Touch Display Features

  • Multi-Touch support of up to 10-simultaneous touches
  • AG Protective and tempered glass increases the overall security of the panel and delivers an unmatched touch experience with anti-glare capabilities to reduce incident light reflection and minimize fingerprinting
  • Included stylus for smooth on-screen editing and collaboration
  • Included DisplayNote licence for collaboration purposes
  • Portrait or landscape instlalations suitable for in-classroom or signage spaces
  • Integrated USB Media Player and auto-input switching capabilities so the screen sees zero downtime of content
  • Integrated 10W x 2 audio for convenient audio playback
  • Clean design includes metal bezel and pull-down IR receiver
  • CEC support through HDMI connections for enabling connected video devices
  • Integrated 10-point IR Touch
  • Adjustable Picture Modes
  • Signal Check Priority
  • CEC Control
  • Sleep Timer
  • Power Save Modes
  • Portrait Capable
  • Button/IR Lock
  • USB Media Player

Key Features

  • Multi-Touch support of up to 10-simultaneous touches
  • Included stylus for smooth on-screen editing and collaboration
  • Included DisplayNote licence for collaboration purposes
  • Portrait or landscape instlalations suitable for in-classroom or signage spaces
  • Integrated 10W x 2 audio for convenient audio playback
  • Clean design includes metal bezel and pull-down IR receiver

What's in the box:

  • 65" Large Format Touch Display
  • 3m Power Cord
  • Wireless Remote Control
  • Batteries
  • Setup Manual
  • Stylus Pen
  • Screws
  • NEC 3 Year Warranty
