NEC EA271U-BK-SV Specifications

Display

Display

Jump to...
  • Panel Technology

    IPS

  • Aspect Ratio

    16:9

  • Pixel Pitch

    0.16mm

  • Backlight Type

    W-LED

  • Viewable Image Size

    27"

  • Native Resolution

    3840x2160

  • Pixels Per Inch

    163 at native resolution

  • Brightness (typical)

    350 cd/m2

  • Contrast Ratio (typical)

    1000:1

  • Viewing Angle (typical)

    178 deg. Vert., 178 deg. Hor. (89U/89D/89L/89R) at CR>10

  • Response Time (typical)

    5 ms

  • Displayable Colors

    1.07 billion

  • Active Screen Area

    596.74 x 335.66mm

  • Lookup Table

    Yes

  • Color Gamut

    Adobe RGB Coverage/Size: 78.1% / 81.6%
    NTSC Coverage/Size: 75.1% / 78.0%
    sRGB Coverage/Size: 100.0% / 110.1%

Synchronization Range

Jump to...
  • Horizontal (Analog/Digital)

    31.5 KHz - 136.0 KHz

  • Vertical

    30.0 Hz - 75.0 Hz

Signal Compatibility/Connectivity

Jump to...
  • Input Terminals

    Connectors: 1x DisplayPort, 2x HDMI, 1x USB Type-C

  • Hub

    USB 3.1 and USB-C, 1 up / 3 down

  • Power Delivery

    USB-C 60W

Power Consumption (Typical)

Jump to...
  • On

    38W

  • Power Savings Mode

    0.29W

  • Power Consumption (Max)

    150W

Environmental Conditions

Jump to...
  • Operating Temperature

    41 to 95 deg. F (5 to 35 deg. C)

  • Operating Humidity

    20-80%

  • Operating Altitude

    16,404' (5000m)

  • Storage Temperature

    14 to 140 deg. F (-10 to 60 deg. C)

  • Storage Humidity

    10-85%

  • Storage Altitude

    40,000' (12,192m)

Environmental Compliance

Jump to...
  • ENERGY STAR

    7.0

  • RoHS

    Yes

  • TCO

    7.0

General

Jump to...
  • Bezel Width (Left/Right, Top/Bottom)

    1.0 / 1.0 / 1.0 / 18.7mm

  • VESA Hole Configuration

    100 x 100mm

  • Dimensions (WxHxD)

    With Stand: 24.1 x 14.9 - 20.8 x 9.8" (61.21 x 37.85 - 52.83 x 24.89cm)
    Without Stand: 24.1 x 14.2 x 2.6" (61.21 x 36.07 x 6.60cm)

  • Weight

    With Stand: 20.9 lbs (9.48kg)
    Without Stand: 13.4 lbs (6.08kg)

6 Accessories for NEC EA271U-BK-SV 27" IPS 4K UHD Widescreen LED Monitor with Integrated Speakers, Includes SpectraViewII Software and Spyder5 Color Sensor

  • All Accessories (6)
  • Cables & Adapters (4)
  • Cleaning Accessories (2)

About NEC EA271U-BK-SV

The 4K UHD 27" NEC MultiSync EA271U is a large workspace for the most demanding applications. With 3 bezels measuring only 1.0mm each, this widescreen model features IPS panel technology with wide viewing angles (178 deg. horizontal/vertical) and an LED backlight for a slimmer profile, lighter weight and increased power savings.

This model also features a height-adjustable stand and full connectivity with DisplayPort and two HDMI inputs as well as a DisplayPort output. In addition, the USB Type-C input can serve as a single connection to a laptop, providing power, video and USB connectivity through one cable. The EA271U includes touch-sensitive On Screen Display controls, a Picture by Picture (PBP) mode for two inputs onscreen at the same time, streamlined cable management and ControlSync technology, which allows users to control the settings of up to six units in a multi-monitor configuration. The included SpectraViewII software and Spyder5 color calibration sensor ensure that colors are rendered accurately.

• USB Type-C 60W power delivery
• PBP mode
• PBP button
• Tilt
• Swivel
• Pivot
• Height-adjustable stand
• ControlSync
• Customize Setting
• Integrated speakers
• 3-port USB 3.1 hub
• LED backlit
• Auto brightness with ambient light sensor
• Human sensor
• ECO Mode
• Carbon footprint meter
• Resettable cost meter
• 3-sided narrow bezel
• Carrying handle
• Rapid Response
• XtraView
• Hot Key
• Touch OSD controls
• OSD Lock Out
• Cable management
• NaViSet Administrator software
• VESA mount
• HDCP
• DDC/CI
• Plug and Play (VESA DDC2B)
• VESA DPMS power management
• Uniformity correction
• Digital controls
• ISO 9241-307 Class I
• DICOM SIM

Ambient Light Sensor
Automatically adjusts the backlight and power management depending on the ambient lighting brightness.

Carbon Footprint Meter
Informs and motivates responsible use of the display by calculating and tracking the conservation of green gas emissions in real time.

ControlSync
Allows users to control up to six units in a multi-monitor configuration. Upon establishing one unit as the master, users will be able to control many performance attributes of the multi-monitor setup in unison through the single monitor.

Human Sensor
Monitors the presence of a user in front of the display and can go into power saving mode if the user leaves, saving up to 99% power.

Kensington Lock
Enables a security cable to be attached to the projector.

LED Backlight
Provides for industry-leading low power consumption and less hazardous materials.

Picture by Picture (PBP) mode
Displays a either second video source or the same video source in an window beside the main video source.

Rapid Response
Delivers virtually uninterrupted, undistorted viewing of high-speed, full-motion video.

XtraView+
Delivers wide viewing angles of up to 178 deg. horizontally and vertically (up to 89 deg. up, down, left and right) with less color shift and without any glare, reflection or distortion.

NEC EA271U-BK-SV Features

  • 4K UHD IPS panel with wide viewing angles for excellent image reproduction
  • Full connectivity, including DisplayPort and two HDMI inputs as well as USB Type-C
  • USB Type-C input delivers 60W of power as well as video and USB over one cable
  • Touch-sensitive OSD controls are integrated into the bezel, making display adjustments easier than ever
  • Human and ambient light sensors automatically detect your work conditions to determine the proper display brightness and conserve power
  • Fully adjustable quick-release stand, including height-adjust (150mm), pivot, tilt and swivel capabilities, adds flexibility and comfort to your viewing preferences
  • Includes the SpectraViewII calibration software and the CC-SPYDER5 color calibration sensor

What's in the box:

  • NEC EA271U-BK-SV 27 " IPS 4K Ultra HD Business-Class Widescreen LED Desktop Monitor
  • SVIISOFT SpectraViewII Calibration Software
  • CC-SPYDER5 Spyder5 Color Calibration Sensor
  • Power Cable
  • DisplayPort Cable
  • USB 3.0 Cable
  • ControlSync Cable
  • Factory Calibration Report
  • Setup Manual
  • NaViSet Administrator 2 Flyer
  • NEC 3 Year Parts and Labor Limited Warranty
