NEC NP-P502H Full HD DLP Projector, 1920x1080, 5000 Lumens

The NEC P502H (5000 lumens) gives your presentations a boost in brightness. A widescreen professional installation projector loaded with eco-friendly and advanced technologies makes it ideal for higher education classrooms, corporate boardrooms and government training rooms. Advanced installation features such as horizontal & vertical lens shift provides even great installation flexibility. Adding horizontal & vertical keystone keeps the image square on the screen if installation challanges exist.

• Dual HDMI inputs (with HDCP) ensures quick switching between presentations
• 6,000:1 Contrast Ratio creating extremely detailed images
• Built-in HDBaseT enables simplified installations with a single cable for video, audio and control signals: LAN connection for control and asset management over the network
• 5000-hour filter drastically reduces cleaning frequency, thereby decreasing the total cost of ownership
• Variable audio-out allows the remote control to adjust speaker volume
• Eco-friendly features, minimal maintenance and cost savings mean these projectors are still great for demanding integration applications such as higher education and corporate
• Powerful 20W speakers provide volume needed for large rooms
• Horizontal & Vertical lens shift enables flexible projector placement
• IEU Lite (Image Express Utility Lite) for audio and video transmission from a computer to the projector over the network
• NaViSet Administrator 2: Free software solution that greatly eases administration and management of larger display device installations

1080p native resolution (1920x1080)
High resolution provides detailed display of text, graphics and images. HD video is displayed in 16:9 wide aspect ratio.

20W Audio
Powerful 20-watt speaker provides volume needed for large rooms

3D Ready
When combined with active shutter glasses (NP02GL), this projector uses DLP Link technology, developed by Texas Instruments, to create 3D images.

Auto Power On
Powers on the projector as soon as it is plugged into a power outlet.

BrilliantColor
Advanced video processing from Texas Instruments delivers exceptional picture management control for both progressive and interlaced sources, while making images more vibrant, colors more realistic and blacks richer with detail.

Built-In Closed Captioning
Enables decoding and display of text information from a video.

Built-in Wall Color Correction
Presets provide for adaptive color tone correction to display properly on non-white surfaces.

Crestron Roomview
Provides unified management, including the ability to switch the power on and off for multiple projectors connected to a network.

DLP Technology
High contrast images (10,000:1) from the latest Texas Instruments DLP engine featuring BrilliantColor technology with improved color accuracy

Dual HDMI inputs (with HDCP)
Ensure quick switching between presentations and allows for simultaneous digital connections of high-definition sources, such as Blu-ray players, cable boxes, satellite receivers and computers

ECO Mode
Extends lamp life, lowers audible noise and reduces total cost of ownership.

Image Express Utility Lite with audio transfer
Provides wired and wireless data transmission via peer-to-peer or over the network

Advanced AccuBlend
Ensures detailed images when non-native resolution sources are connected to the projector.

Lens Shift
Vertical and horizontal lens shift enables flexible projector placement.

Power Management
Enables projector to automatically turn off when an incoming signal is not detected from any of the inputs.

USB Viewer
Permits playback (without a PC) of presentations or display images stored as JPG files from a USB flash drive.

Variable Audio Out
Adjusts the volume of an external speaker system using the projector's remote control.

Virtual Remote
Used over the VGA cable to control the projector directly from a computer without the need for additional control cables.

Wired Network Connection
Integrated RJ45 connection for quick connection to the LAN (10/100 base-T capability).

Wireless Imaging Utility
Allows users to send an image from an iPad directly to the projector.

Integrated and Powerful
• Project uncompressed FHD video with integrated HDBaseT
• High performance video processing/scaling creates life-like images
• Integrated software applications such as Crestron Roomview, AMX Beacon and PJ Link allow for complete interactivity and control

Flexible
• Horizontal & vertical keystone adjustment provides the ability to square the image to the screen
• Lens shift capabilities make alignment easy: P452W/P502W (+59 vertical, +/- 28% horizontal), P502W/P502H (+62 vertical, +/- 25% horizontal)

Built-In HDBaseT Support
Simplify your installations with HDBaseT. Optimized for video applications and supporting uncompressed full HD digital video, audio, ethernet, power and various control signals. With only a single cable (up to 100m) to run, infrastructure and labor costs are reduced, installations are significantly easier and there is no cable clutter to manage. With uncompressed HD video support, images have never been more stunning. What's more, control signals are contained in the same cable.

Advanced Networking Capabilities
• Integrated RJ45 connection for quick connection to the LAN (10/100 base-T capability)
• Remote diagnostics enable the user to monitor and make adjustments to the projector remotely
• PC CTL 4.0 controls the power switching input selection and other functions while managing lamp usage and a variety of other vital information over the network. Email notification and projector scheduling for better asset management is included with the software.
• PC CTL 5.0 for MAC users
• Control and receive important broadcast messages via Crestron Roomview
• Wireless Image Utility (WIU) sends images directly from an iPad to the projector (requires wireless LAN module NP05LM1)
• Simple Access Point Sending photos and documents have never been easier from a computer or iPad.
• MultiPresenter enables up to 16 wireless devices to be connected to the projector simultaneously with access controlled by the moderator.

Multi-screen Projection Function
The multi-screen projection function allows you to share screens from multiple devices on various split-screen displays. Display information from up to 16 PCs, tablet PCs, smart phones and other network connected devices on a multi-screen display of up to 16 screens. Easily share screens and information regardless of device or operating system.

Remote control
Easy control from remote allows you to adjust lamp mode, aspect ratio, volume and image all with the touch of a button.

Dual HDMI inputs
Among the M Series' wide selection of inputs are 2 HDMI w/HDCP (one MHL compatible) for connecting to high-definition sources such as Blu-ray players, cable boxes, satellite receivers and personal computers.

Variable audio-out
This input enables the remote control to be used to adjust volume of self powered external speakers that are connected to the projector. In stand-by mode, the audio-out stays active, allowing the last input used to pass to the selfpowered external speakers.

Top cover lamp change
This feature provides for easy lamp changes without removal of the projector from the mount.

Wall color correction presets
These provide for adaptive color tone correction to display properly on non-white surfaces.

Input panel cover
This optional accessory creates a clean look for your installation, while hiding signal cables and the power cord.

FUll HD 3D video (144Hz)
When combined with active shutter glasses and 3D emitter, the P Series Projectors create 3D images from a computer or Blu-ray player. The projectors utilize the 3D sync line output to connect to the 3D emitter.

AutoSense
Automatically syncs with any computer signal and features one-touch image optimization.

64-step image magnification
With location control

Discreet source keys
For source selection

Remote diagnostics
Enable the user to monitor and make adjustments to the projector remotely

Built-in HTTP page
For control and monitoring over a LAN network. Email notification of error messages or lamp end-of life can be sent to remote locations.

Wireless LAN (Optional)
Allows you to transmit images from a PC wirelessly to the projector, eliminating the need for traditional cumbersome cables.
