NEC P506QL 4K UHD DLP Laser Entry Installation Projector, 5000 Lumens

SKU: NCNPP506QL

This item is no longer available.

Overview
Compare
Accessories
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

NEC P506QL Specifications

Display

Display

Jump to...
  • Aspect Ratio

    16x9

  • Native Resolution

    4K UHD 3840x2160

  • Maximum Resolution

    Up to 4K@60Hz (3840x2160) for HDMI

  • Contrast Ratio (typical)

    500,000:1

Synchronization Range

Jump to...
  • Horizontal (Analog/Digital)

    15.734KHz - 153kHz (RGB: Hz, 24 - 100KHz)

  • Vertical

    48 - 100, 120Hz

Signal Compatibility/Connectivity

Jump to...
  • SD/HD Video Signal Compatibility

    4K UHD, 1080p, 1080i, 720p, 576p, 576i, 480p, 480i

  • PC Signal Compatibility

    VGA, SVGA, XGA, WXGA, Quad-VGA, SXGA, SXGA+, WXGA+, UXGA, WSXGA+, HD, FHD

  • Macintosh Signal Compatibility

    Yes

  • External Control

    RS-232 (D-Sub 9pin), IR, RJ45

  • Input Terminals

    RGB1(analog): VGA 15-pin D-sub
    RGB1(digital): HDMI w/ HDCP (v2.0)
    RGB2(digital): HDMI w/ HDCP (v2.0)
    RGB3(digital): HDBaseT
    Audio 1: Stereo Mini Jack

  • Output Terminals

    Audio: Stero Mini Jack
    Audioout: Stereo Mini Jack

Power Consumption (Typical)

Jump to...
  • On

    580W / 330W / 2W / 0.5W

  • Input Current

    6A

  • Power Requirements

    100 - 240V AC, 50/60 Hz

Environmental Conditions

Jump to...
  • Operating Temperature

    41 - 104 Degree F (5 - 40 Degree C)

  • Operating Humidity

    20 to 80% Humidity (Non-Condensing)

  • Storage Temperature

    14 Degree - 122 Degree F (-10 Degree - 50 Degree C)

  • Storage Humidity

    20 to 90% Humidity (Non-Condensing)

Additional Features

Jump to...
  • Additional Features

    Manual Lens Shift
    HDBaseT
    Filter Free
    Crestron/AMX/PJLink Compatible
    Quick Start/Direct Off
    ECO Mode Technology
    2A USB Support
    Security Bar
    NaViSet Administrator Supported
    10W Speaker
    Wired LAN or RS232 for Control
    Tilt Free, Roll Free & Portrait

Optical

Jump to...
  • Display Technology

    DLP (0.47" DMD)

  • Light Output(Lumens)

    5000 lumens

  • Lamp Type

    Laser/Phosphor

  • Light Source Life

    20,000 hours

  • Screen Size

    Diagonal: 50 - 310" (1.27 - 7.87m)

  • Throw Ratio

    1.127 - 1.697:1

  • Projection Distance

    5.2 - 26.2' (1.6 - 8m)

  • Projector Angle

    25.46 Degree tele / 34.5 Degree wide

  • Lens

    Zoom: 1.5x
    Focus: Manual
    F number, fnumber: F=1.8-2.43 / f=12.1-18.1mm

  • Keystone Correction

    Vertical

Mechanical

Jump to...
  • Installation Orientation

    Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear

  • Fan Noise

    35dB (ECO mode Off), 32dB (ECO mode)

  • Regulations

    UL60950-1:2nd edition,2014, UL62368-1:2nd Edition, UL62368-1:3rd Edition, FDA, FCC Part15 Subpart B(ANSI C63.4:2014), Proposition65, TPCH, CAN/CSA C22.2 No.62368-1-14,2nd Edition,2014, ICES-003 Issue6(ANSI C63.4:2014)

Lens Adjustment Functions

Jump to...
  • Lens Adjustment Functions

    Manual focus, zoom, horizontal/vertical shift

Supported Screen Size

Jump to...
  • Supported Screen Size

    Maximum: 50 - 310" (1.27 - 7.87m)

Physical

Jump to...
  • Dimensions (WxHxD)

    18.9 x 6.8 x 15.7" (480 x 172 x 400mm)

  • Weight

    25.4 lbs (11.5kg)

  • UPC Code

    805736072761

1 Accessories for NEC P506QL 4K UHD DLP Laser Entry Installation Projector, 5000 Lumens

  • All Accessories (1)
  • Laptop Stand (1)

About NEC P506QL

Taking 4K projection into new frontiers the P506QL is bright enough for classrooms and conference rooms and impressive enough for museums and signage. This addition to NEC's P Series utilizes DLP technology and a maintenance free laser light source. A unique combination of power and performance at a cost that schools and businesses can afford.

Technologies

3D Ready
When combined with active shutter glasses (NP02GL), this projector uses DLP Link technology, developed by Texas Instruments, to create 3D images.

Crestron Roomview
Provides unified management, including the ability to switch the power on and off for multiple projectors connected to a network.

4K Resolution
Provides the ultimate in screen clarity.

Lens Shift
Vertical and horizontal lens shift enables flexible projector placement.

DLP Technology
High contrast images (10,000:1) from the latest Texas Instruments DLP engine featuring BrilliantColor technology with improved color accuracy

ECO Mode
Extends lamp life, lowers audible noise and reduces total cost of ownership.

Built-In Speakers
Enhance the visual experience with superior sound

NEC P506QL Features

  • Native 4K UHD (3840 x 2160) resolution produces stunning images with incredible detail
  • Laser light source reduces maintenance requirements and lowers TCO
  • Horizontal & Vertical lens shift enables flexible projector placement
  • Built-in HDBaseT provides simplified installations with a single cable for video, audio, and control signals
  • High resolution, minimal maintenance and a cost saving design mean these projectors are perfect for demanding applications in higher education, corporate, retail, museums and more
  • NaViSet Administrator 2: Free software solution that greatly eases administration and management of larger display device installations

Key Features

  • Native 4K UHD (3840 x 2160) resolution produces stunning images with incredible detail
  • Laser light source reduces maintenance requirements and lowers TCO
  • Horizontal & Vertical lens shift enables flexible projector placement

What's in the box:

  • P506QL 4K UHD DLP Laser Entry Installation Projector
  • Remote Control (RMT-PJ39)
  • Ceiling Mount (PA600CM)
  • NEC 5 Year Parts and Labor Limited Warranty Including InstaCare Next Business Day Exchange
