NEC SB-07BC HDBaseT OPS Receiver Module for Display Solutions

SKU: NCSB07BC MFR: SB-07BC
Be the first to review this itemAsk a Question
$279.00
$299.00
Save: $20 (7%)
OR
$47/mo suggested payments with 6‑month special financing. Learn how.
Earn VIP Reward Points

Key Features

  • Extend your display's reach with HDBaseT connectivity for seamless video resolution.
  • Achieve optimal image quality with this OPS receiver module, supporting up to 4K2K at 30 Hz.
  • Enjoy versatile control options: RS232C, IR, and Ethernet for easy projector management.
  • Stream high-bandwidth content (10.2 Gbps) effortlessly with this NEC display solution.
  • Simplify installations; transmit audio, video, and control signals up to 328 feet.
  • Ensure compatibility with various NEC display models for a reliable home theater setup.
See More Product Details
Temporarily On Backorder?Expected Availability: 10/2025Request assistance or get notified
Free Shipping

See Options

1
Add to ListGet Sale Alert

Protect your gear with Adorama Protect.* Learn more

1 Year

$29.99

2 Year

$49.99

3 Year

$59.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

NEC SB-07BC Specifications

  • Compatibility

    E705, E805, E905, P402, P403, P462, P463, P552, P553, P702, P703, V322, V323, V323-2, V422, V423, V462, V463, V551, V552, V651, V652, V801, X401S, X462S, X463UN, X464UN, X464UNS, X464UNV, X464UNV-2, X551UN, X552S, X554UN, X554UN-2, X554UNS, X651UHD, X841UHD, X981UHD Display Solutions

  • Video Resolution

    480i, 576i, 480p, 576p, 1080i at 50/60 Hz, 720p at 50/60 Hz, 1080p at 24/25/50/60 Hz
    640 x 480 to 1920 x 1200 at 60 Hz, 4K2K at 24/25/30 Hz

  • Distance CAT5/6

    100m / 328.08'

  • Control

    RS232C, IR, Ethernet (10BaseT/100BaseT)

  • Audio Formats

    PCM 2 ch

  • Bandwidth

    10.2 Gbps

  • HDCP

    Yes

  • Interfaces frontside

    1 x RJ45 (LINK: HDBaseT) 1 x RJ45 (Ethernet)
    1 x IR in (3.5 mm jack)
    1 x IR out (3.5 mm jack)

  • Interfaces backside

    Internal OPS-interface (JAE 80-pin connector)

  • Power Consumption

    5W (max.)

  • Voltage / Current

    16 / 0.33 V/A

  • Operating Temperature

    0 to 40 deg. C / 32 to 104 deg. F

  • Storage Temperature

    -10 to 60 deg. C / 14 to 140 deg. F

  • Operating Humidity

    20% to 80%

  • Storage Humidity

    10% to 90%

  • Regulatory Approvals

    CE, RoHS, VCCI (class B), RCM, FCC

  • Dimensions (W x H x D)

    0.20 x 0.03 x 0.12mm / 0.01 x 0.00 x 0.00"

  • Weight

    0.6kg / 1.32lbs

About NEC SB-07BC

The SB-07BC HDBaseT OPS Receiver Module for Display Solutions is an innovative solution designed to facilitate the transmission of compressed HD multimedia content up to 100 meters using a single network cable. This advanced HDBaseT technology delivers uncompressed full HD digital video, high-quality audio, 100BaseT Ethernet, and control signals seamlessly through a single 100-meter LAN cable.

The HDBaseT transmitter, known as the KT-100TX1, expertly converts the input signal source and transmits high-quality signals via a network cable to the HDBaseT receiver, the SB-07BC unit. This receiver is strategically embedded into the display to ensure optimal performance and signal quality.

The SB-07BC HDBaseT OPS Receiver Module is compatible with NEC large format displays and projectors that feature OPS technology. Additionally, it works efficiently with the majority of third-party HDBaseT senders, making it a versatile addition to any multimedia setup.

Whether you're looking to enhance your home theater system or upgrade your professional audio-visual equipment, the SB-07BC HDBaseT OPS Receiver Module for Display Solutions offers a reliable, high-performance solution for transmitting HD multimedia content.

NEC SB-07BC Features

  • No more cable length limitations
  • One single cable only
  • Easy setup and operation
  • Wide range of applications
  • Compact and fully embedded
  • High flexibility

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Extend your display's reach with HDBaseT connectivity for seamless video resolution.
  • Achieve optimal image quality with this OPS receiver module, supporting up to 4K2K at 30 Hz.
  • Enjoy versatile control options: RS232C, IR, and Ethernet for easy projector management.
  • Stream high-bandwidth content (10.2 Gbps) effortlessly with this NEC display solution.
  • Simplify installations; transmit audio, video, and control signals up to 328 feet.
  • Ensure compatibility with various NEC display models for a reliable home theater setup.

What's in the box:

  • NEC SB-07BC HDBaseT OPS Receiver Module for Display Solutions
  • User Manual
  • External IR Sensor
  • NEC 3 Year Warranty
