NEC UN492S-TMX4P 49" Ultra Narrow Bezel S-IPS Full HD LED-Backlit 2x2 Video Wall Bundle, 500/700 cd/sq.m

SKU: NCU492STMX4P MFR: UN492S-TMX4P
Earn VIP Reward Points

Key Features

  • Create stunning 2x2 video walls with four 49" NEC commercial displays for immersive visuals.
  • Experience Full HD resolution and vibrant colors with this LED-backlit commercial monitor bundle.
  • Ultra-narrow bezel design minimizes distractions for seamless video wall presentations and digital signage.
  • Enjoy versatile connectivity options, including HDMI, DisplayPort, and DVI, for your video sources.
  • Rely on S-IPS panel technology for wide viewing angles and consistent image quality in any environment.
  • This video wall bundle offers reliable performance backed by NEC's 3-year limited warranty.
See More Product Details
Temporarily On Backorder?Expected Availability: 10/2025Request assistance or get notified
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$499.99

3 Year

$649.99

5 Year

$949.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

NEC UN492S-TMX4P Specifications

LCD Module

LCD Module

Jump to...
  • Panel Technology

    S-IPS

  • Viewable Image Size

    49" (124.4cm)

  • Native Resolution

    1920 x 1080

  • Brightness

    500 cd/sq. m (typical)
    700 cd/sq. m (maximum)

  • Contrast Ratio (typical)

    3500:1

  • Viewing Angle (typical)

    178 Degree/178 Degree

  • Aspect Ratio

    16:9

  • Displayable Colors

    Over 1.07 billion

  • Orientation

    Landscape/Portrait

  • Panel Haze

    0.25

Connectivity

Jump to...
  • Input Terminals

    Digital: HDMI x2 (1.4/2.0), DisplayPort x2 (1.1/1.2), DVI-D
    Analog: VGA 15-pin D-sub, RCA Composite
    Audio: Audio Mini Jack x2, DisplayPort Audio, HDMI Audio
    External Control: RS-232C, LAN (100Mb), 3.5mm Mini-Jack (IR Remote)
    USB: microSD (Media Player), USB 2.0 (Media Player, USB (Service)), USB Type-B (Upstream), USB x2 (Both for Compute Module, 1 x 5V/2A Powered)

  • Output Terminals

    Digital: Display-Port (Outputs DisplayPort1 and OPTION (DP)), HDMI (Outputs HDMI1, DVI and OPTION TMDS))
    Audio: 3.5mm Mini-Jack, External Speaker Jack x2
    External Control: LAN (100Mb)

Power Consumption

Jump to...
  • Power Consumption

    95W/125W/275W (Typical/Max Brightness/Absolute Max)

  • Network Standby

    2W

  • Standby

    0.5W

  • Current Rating

    3.2A @ 100V, 1.3A @ 240V

Environmental Conditions

Jump to...
  • Operating Temperature

    32 Degree to 122 Degree F (0 Degree to 50 Degree C)

  • Operating Humidity

    0-90%

  • Operating Altitude

    9843' (3000m)

Optional Accessories

Jump to...
  • Optional Accessories

    Overframe Bezel Kit (KT-49UN-OF), Display Wall Calibrator Kit (KT-LFD-CC2), IR/Ambient Light/Human Sensor and Remote Accessory (KT-RC3), OPS PC's (OPS-APIS-PS, OPS-PCAEQ-PS2, OPS-PCAEQ-PS), Internal HD-SDI Input Card (SB-01HC), Internal 3G/HD/SD-SDI Input Card (SB-04HC), Thin Side/Rear Mounted Speaker (SP-TF1), Optional Tabletop Stand (ST-322)

Physical

Jump to...
  • Bezel Width

    0.04"/0.04", 0.04"/0.04" (L/R, T/B)

  • VESA Hole Configuration

    300 x 300mm (4-hole, M6)

  • Dimensions (W x H x D)

    Without Stand: 42.4 x 23.9 x 3.9" (1075.7 x 605.9 x 99mm)

  • Weight

    Without Stand: 53.6 lbs (24.3kg)

  • UPC Code

    805736071429

About NEC UN492S-TMX4P

Bring your digital signage, information display, and command & control applications to life with the NEC UN492S-TMX4P 49" Ultra Narrow Bezel S-IPS Full HD LED-Backlit 2x2 Video Wall Bundle. This all-in-one, easy-to-configure solution delivers a stunning 98" display, making it a cost-effective choice for dynamic visual presentations.

The ultra-narrow bezel design of the NEC UN492S, coupled with the full adjustment capabilities of the Peerless DS-VW775 mount, allows for a near seamless video wall experience. This is further enhanced by NEC's exclusive TileMatrix, TileComp, and TileCut technologies, eliminating the need for additional third-party equipment.

Experience crystal clear imagery with the NEC 49" UN492S and UN492VS. These displays feature advanced S-IPS panel technology, offering exceptional off-angle viewing, superior color reproduction, and high-quality image display. The direct LED backlighting not only reduces power consumption but also ensures edge-to-edge brightness uniformity.

The UN492S-TMX4P 49" Ultra Narrow Bezel S-IPS Full HD LED-Backlit 2x2 Video Wall Bundle is perfect for digital signage, command and control, entrance lobbies, and broadcast applications. It supports up to 10 x 10 video wall applications, thanks to the integrated TileMatrix technology.

The groundbreaking SpectraView Engine technology integrated into each display offers advanced color control, ensuring ultimate uniformity and consistency across the entire wall. The displays support up to UHD (3840 x 2160) resolution through the internal daisy chain functionality, allowing for ultra-high-definition resolution across the entire video wall.

The SPVA panel technology minimizes the bezel to bezel distance to a mere 1.8mm, maintaining high native contrast ratio and superb image quality. The displays also feature TileComp technology, which compensates for the content that would be behind these bezels, resulting in truer and more realistic imagery.

The UN492S-TMX4P 49" Ultra Narrow Bezel S-IPS Full HD LED-Backlit 2x2 Video Wall Bundle also features advanced heat management, ensuring reliability and longevity. The integrated cooling fans automatically turn on when high internal temperatures are detected, ensuring heat dissipation for a more uniform overall wall temperature.

The Frame Comp functionality allows for better content synchronization when content is moving across the video wall. The optional human (motion) sensor accessory (KT-RC3) allows for dynamic control of brightness, audio, and source inputs, saving operating costs.

The NEC Display Wall Calibrator software ensures color uniformity and fidelity across multiple screens, creating a perfectly matched image in tiled environments. The high haze panel scatters ambient lighting, ensuring content is always viewable and onlookers have perfect screen readability in any situation.

The NEC UN492S-TMX4P 49" Ultra Narrow Bezel S-IPS Full HD LED-Backlit 2x2 Video Wall Bundle is a comprehensive solution for your video wall needs, offering unparalleled color control, uniformity, accuracy, and stability.

NEC UN492S-TMX4P Features

  • 3D LUT
  • AMX Support
  • Auto ID/Auto TileMatrix
  • Automated Email Alert Function
  • CEC Support through HDMI
  • Crestron Roomview Support
  • DICOM Simulation
  • Display Browser Control
  • Display Wall Calibrator Compatible
  • FrameComp Technology
  • High Haze Panel
  • Intelligent Wireless Data (NFC)
  • Key Guide
  • NaViSet Administrator 2 Compatible
  • OSD Rotation for Portrait Orientation
  • OPS Compatible
  • PJ Link Support
  • Point Zoom Function
  • Power USB Port (5V/2A)
  • Programmable LUT
  • Raspberry Pi Compute Module Compatible
  • Real Time Clock
  • SpectraView Engine Support for Advanced Calibration Techniques
  • SNMP Support
  • 24-Hour Scheduler Function
  • UHD Support through HDMI/Display-Port

Key Features

  • Create stunning 2x2 video walls with four 49" NEC commercial displays for immersive visuals.
  • Experience Full HD resolution and vibrant colors with this LED-backlit commercial monitor bundle.
  • Ultra-narrow bezel design minimizes distractions for seamless video wall presentations and digital signage.
  • Enjoy versatile connectivity options, including HDMI, DisplayPort, and DVI, for your video sources.
  • Rely on S-IPS panel technology for wide viewing angles and consistent image quality in any environment.
  • This video wall bundle offers reliable performance backed by NEC's 3-year limited warranty.

What's in the box:

  • 4x UN492S 49 " Ultra Narrow Bezel S-IPS Full HD LED-Backlit Display
  • 4x Pull-Out Mount
  • 4x Power Cord (9.8')
  • 4x Display-Port Cable (6.5')
  • 4x HDMI Cable (6.5')
  • 4x LAN Cable
  • 4x SD Card Cover
  • 4x Clamp for Power Cable
  • NEC 3 Year Limited Warranty
