NEC 55" UN551S Ultra Narrow Bezel S-IPS Display 3x3 Video Wall Bundle, 500 Nits

SKU: NCUN551STMX9

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

NEC 55" UN551S Ultra Narrow Bezel S-IPS Display 3x3 Video Wall Bundle, 500 Nits Specifications

Display

Display

Jump to...
  • Panel Technology

    S-IPS (P-DID)

  • Viewable Image Size

    55"

  • Native Resolution

    1920 x 1080

  • Pixel Pitch

    0.6 mm

  • Backlight Type

    LED Direct-lit

  • Pixels Per Inch

    47@ native resolution

  • Brightness (typical)

    500cd/m square

  • Brightness (maximum)

    700cd/m square

  • Contrast Ratio (typical)

    1200:1 (500,000:1 Dynamic)

  • Viewing Angle

    178 Degree Vertical, 178 Degree Horizontal (89U/89D/89L/89R) @ CR>10

  • Response Time(Gray to Gray)

    8ms

  • Refresh Rate

    60Hz

  • Aspect Ratio

    16:9

  • Active Screen Area

    47.6 x 26.8" (120.96 x 68.04 cm)

  • Orientation

    Landscape/Portrait

  • Displayable Colors

    More than 1.07 Billion

Synchronization Range

Jump to...
  • Horizontal (Analog/Digital)

    15.625 / 15.734 / 31.5-91.1 kHz

  • Vertical

    50.0-85.0 Hz (Analog), 24.0 - 85.0Hz (Digital)

Input Signal

Jump to...
  • Video

    Analog RGB 0.7 Vp-p/75 Ohms (Analog), TMDS (Digital)

  • Sync

    Separate sync: TTL Level (Positive/Negative)
    Composite Sync on Green: (0.3Vp-p negative)

Connectivity

Jump to...
  • PC Signal Compatibility

    Yes

  • Macintosh Compatibility

    Yes

  • Input Terminals

    Digital: DisplayPort, HDMI, DVI-D
    Analog: VGA 15-pin D-sub
    Audio: Audio Mini-Jack, DisplayPort Audio, HDMI Audio
    External Control: RS-232C, LAN, DDC/CI

  • Output Terminals

    Audio: Audio Mini-Jack, External Speaker Jack (2), HDMI Audio (through DP Out), DisplayPort Audio
    Digital: DisplayPort (DisplayPort, HDMI, DVI-D or Option Signals out of this port)
    External Control: LAN

Power Consumption (typical)

Jump to...
  • On

    180W

  • ECO Mode Standby

    <0.5W

Power Consumption

Jump to...
  • Input Current

    4.4A @ 100-120V (1.6A @ 220-240V)

VESA Hole Configuration

Jump to...
  • VESA Hole

    400 x 400 mm (4-hole)

Environmental Conditions

Jump to...
  • Operating Temperature

    41 - 104 Degree F (5 - 40 Degree C)

  • Operating Humidity

    20-80%

  • Operating Altitude

    13,780' (4200 m)

  • Storage Temperature

    -4 - 140 Degree F (-20 - 60 Degree C)

  • Storage Humidity

    10-90%

  • Storage Altitude

    40,000' (12,192 m)

Physical Specifications

Jump to...
  • Bezel Width (Left/Right, Top/Bottom)

    0.9 mm inactive border along all sides of display

  • Dimensions (W x H x D)

    With Stand: 47.7 x 28.6 x 15.7" (121.1 x 72.7 x 40.0 cm)
    Without Stand: 47.7 x 26.9 x 3.9" (121.1 x 68.2 x 9.88 cm)

  • Weight

    With Stand: 60.4 lb (27.4 kg) Per Display
    Without Stand: 57.3 lb (26.0 kg)

  • UPC Code

    805736066524

About NEC 55" UN551S Ultra Narrow Bezel S-IPS Display 3x3 Video Wall Bundle, 500 Nits

NEC's complete 55" 3x3 LCD TileMatrix Digital Video Wall Solution delivers an all-in-one, easy-to-configure and cost-effective solution that is ideal for dynamic digital signage, information display and command & control applications. Exclusive TileMatrix, TileComp and FrameComp technologies, combined with the new glass-to-edge design of the NEC UN551S and the full adjustment capabilities of the Peerless DS-VW775 mounting system, provide for a near seamless video wall without the need for additional third-party equipment. NEC provides everything besides the source to complete your video wall solution!

Features
• Bundled solution with everything required for a 3x3 video wall makes configuration and installation easy
• Pull-out mount allows for full-service capabilities and 6-axis adjustment for perfect alignment
• S-IPS panel technology allows for excellent off-angle viewing and less color shift compared to other technologies
• A mere 0.9mm inactive border allows for an even more homogenous image across the entire wall
• Auto ID feature reduces install time in the single press of a button
• Expanded daisy chain options with UHD passthrough via DisplayPort enables UHD resolution across the entire wall
• Display wall calibration kit, Overframe Bezel Kit and IR/Human sensor complete the solution
• Overnight onsite exchange warranty ensures minimum downtime for maximum impact
• Input Switching Speed minimizes downtime between source transitions
• Human Sensor Accessory ensures digital signage is directed at a targeted audience
• Near field communication capabilities for setup and service
• NaViSet Administrator 2: Free software solution that greatly eases administration and management of larger display device installations
• Video daisy chain limitations apply when High-bandwidth Digital Content Protection (HDCP) is utilized

NEC 55" UN551S Ultra Narrow Bezel S-IPS Display 3x3 Video Wall Bundle, 500 Nits Features

  • S-IPS Panel Technology
  • Direct LED Backlighting
  • Advanced thermal capabilities
  • UHD Daisy Chain Capabilities up to 100 displays
  • 10-bit color panel
  • Ethernet Control and Communication
  • RS-232 Control and Communication
  • Landscape/portrait capable
  • Carbon footprint meter
  • Plug and Play (DDC/CI, DDC2B)
  • Scheduler (with real-time clock)
  • Screen saver function
  • Ambient light sensor
  • Screen saver function
  • Optional human sensor
  • Intelligent Wireless Data (Near Field Communications)
  • OPS Expansion Slot
  • Interface Expansion Slot
  • 6-axis color adjustment
  • Metal rear cabinet
  • POP
  • Side-by-Side
  • Handles
  • Variable picture modes
  • Advanced video settings (Noise Reduction, Adaptive Contrast)
  • Input labeling
  • Backlight adjust
  • Aspect ratio control
  • 10-bit color over HDMI

Key Features

  • S-IPS Panel Technology
  • Direct LED Backlighting
  • Advanced thermal capabilities
  • UHD Daisy Chain Capabilities up to 100 displays
  • 10-bit color panel
  • Ethernet Control and Communication

What's in the box:

  • 55" UN551S Ultra Narrow Bezel S-IPS Display 3x3 Video Wall Bundle (500 Nits)
  • Power Cord
  • 3m DP Cable
  • LAN Cable
  • CD-ROM (User Manual)
  • Screws
  • Thumbscrews
  • Color Calibration Kit (KT-LFD-CC)
  • Overframe Bezel Kit
  • Peerless DS_VW775 Mounting System
  • SurgeX Power Conditioning
  • NEC 3 Year Limited Warranty
