NEC X754HB 75" MultiSync Commercial Full HD LED Monitor, 1920x1080

SKU: NCX754HB

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

NEC X754HB Specifications

  • Panel Technology

    SPVA

  • Viewable Image Size

    75"

  • Native Resolution

    1920 x 1080

  • Pixel Pitch

    0.86mm

  • Backlight Type

    LED Direct-lit

  • Pixels Per Inch

    29.37

  • Brightness (typical)

    2000cd/m2

  • Brightness (maximum)

    2500cd/m2

  • Contrast Ratio (typical)

    3000:1

  • Viewing Angle

    178 deg. Vert., 178 deg. Hor. (89U/89D/89L/89R) at CR>10

  • Response Time(Gray to Gray)

    6ms

  • Refresh Rate

    60Hz

  • Aspect Ratio

    16:9

  • Active Screen Area

    65.0 x 36.5 in. / 1650.24 x 928.26 mm

  • Orientation

    Landscape/Portrait

  • Displayable Colors

    More than 16.7 million

  • Horizontal (Analog/Digital)

    15.625 / 15.734 / 31.5-91.1 kHz

  • Vertical

    50.0-85.0 Hz (Analog), 24.0 - 85.0Hz (Digital)

  • Video

    Analog RGB 0.7 Vp-p/75 Ohms (Analog), TMDS (Digital)

  • Sync

    Separate sync: TTL Level (Positive/Negative),Composite Sync on Green: (0.3Vp-p negative)

  • PC Signal Compatibility

    Yes

  • Macintosh Compatibility

    Yes

  • Input Terminals: Digital

    DisplayPort, HDMI, DVI-D

  • Input Terminals: Analog

    VGA 15-pin D-sub

  • Input Terminals: Audio

    Audio Mini-Jack, DisplayPort Audio, HDMI Audio

  • Input Terminals: External Control

    RS-232C, LAN, DDC/CI

  • Output Terminals: Audio

    Audio Mini-Jack, External Speaker Jack (2), HDMI Audio (through DP Out), DisplayPort Audio

  • Output Terminals: Digital

    DisplayPort (DisplayPort, HDMI, DVI-D or Option Signals out of this port)

  • Output Terminals: External Control

    LAN

  • Power Consumption(typical): On

    540W

  • Power Consumption: ECO Mode Standby

    <2.5W(typical)

  • Input Current

    9.7A at 100-120V / 3.4A at 220-240V

  • Bezel Width (Left/Right, Top/Bottom)

    0.8 in. / 0.8 in., 0.8 in. / 0.08 in. ; 19.5mm/19.5mm , 19.5mm/19.5mm

  • VESA Hole Configuration

    400 x 400 mm ( 4 -hole)

  • Operating Temperature

    32 to 104 deg. F / 0 to 40 deg. C

  • Operating Humidity

    20-80%

  • Operating Altitude

    16404' / 5000m

  • Storage Temperature

    -4 to 140 deg. F / -20 to 60 deg. C

  • Storage Humidity

    20-80%

  • Storage Altitude

    40000' / 12,192m

  • Dimensions (W x H x D)

    With Stand: 66.7 x 39.7 x 23.9" / 1694.18 x 1008.38 x 607.06mm
    Without Stand: 66.7 x 38.3 x 5.9" / 1694.18 x 972.82 x 149.86mm

  • Weight

    With Stand: 137.8lbs / 62.51kg
    Without Stand: 127.7lbs / 57.92kg

About NEC X754HB

The LED backlit 75" NEC X754HB offers superior brightness, extended runtimes and advanced engineering necessary for digital signage and messaging in high ambient light applications. This is the ideal display for window-facing retail signage where the sun may directly affect the fidelity of picture quality for a normal television or dimmer display. It can also be used for quick serve restaurant menu board applications when coupled with a weatherproof type of enclosure. Direct LED backlighting combined with an integrated ambient light sensor allows for adaptable panel brightness depending on environmental conditions. This means that if the display senses higher lux during brighter hours of the day, the display will show a brighter image. At night when the ambient light is much less, the display will dim down, saving overall power consumption. Special quarter lambda polarizer is integrated onto the panel of this display that allows for the display to be seen in any type of orientation even when a customer is wearing polarized sunglasses. This display is the ideal solution for installations where high brightness is a necessity.

NEC X754HB Features

  • 2500cd/m2 max brightness combined with full HD resolution will capture the attention of the audience in bright environments
  • Industrial-strength, premium-grade panel with additional thermal protection, internal temperature sensors with self-diagnostics and fan-based technology, allows for 24/7 operation
  • Built-in expansion slot supports the Open Pluggable Specification (OPS)
  • Real-time clock has the ability to set schedules for on/off times 24/7
  • NaViSet Administrator 2: Free software solution that greatly eases administration and management of larger display device installations
  • Near field communication capabilities for setup and service

What's in the box:

  • NEC X754HB 75 " MultiSync Commercial Full HD LED Monitor
  • Power Cord
  • 1.8m DVI-D Cable
  • Wireless Remote Control
  • Batteries
  • CD-ROM (User Manual)
  • Option Board Slot Cover
  • Screws
  • Thumbscrews
  • 3x Screws with Washer
  • NEC 3 Year Backlight
  • Parts and Labor Limited Warranty
