Nexto DI NCB-20 Specifications

LCD
  • LCD

    2.4" Color TFT LCD: 320x240, 64K color

Memory Card Support

Jump to...
  • SD Model (supports UHS speed)

    SD / SDHC / SDXC 8 slot
    MicroSD 8 slot

Storage

Jump to...
  • External drive

    Two USB 3.0 host port for any USB 3.0 drive, max 32TB
    Supports Advanced Format storage, i.e., sector size bigger than 512 byte

File System

Jump to...
  • Memory card

    FAT32, exFAT, UDF, HFS+

  • USB External drive

    exFAT

  • Video Preview

    XAVC 4K, XAVC 2K, AVC Ultra 4K, AVC Ultra 2K, XF-AVC 4K, XF-AVC 2K, H.264 (.mov), AVCHD 2K, PRORES 4K, PRORES 2K, DNxHD 2K, MPEG 444/422/420, DVCPRO HD

  • Computer I/F

    USB 3.0 : 5Gbit/sec

  • OS Compatibility

    Windows XP / VISTA / 7 / 8 / 10 (Windows XP requires exFAT patch update)
    MAC OS 10.6.5 or later, Linux 2.4.18 or later

  • DC adapter

    Recommended : DC 12V/2A
    Operational range: DC +/-6 to 25V, external diameter 3.5dia., internal diameter 1.3dia.

  • USB Power Bank

    Supply power to the Computer (USB Power Bank) port with a USB3.0 micro-B cable or a USB2.0 micro-B cable (5 pin cable used for the smart phone charger)
    5V, 10,000mAH or more. 2.1A output. (Limited operation)

  • V mount Battery

    V mount batteries are supported on models with V mount plates

General

Jump to...
  • Dimensions

    156 x 80 x 34mm (6.14 x 3.15 x 1.34")

  • Weight

    200g (7.05 oz)

  • UPC Code

    8809680678040

About Nexto DI NCB-20

Multiple memory card reader and copier
Now you can safely back up your memory cards with single button operation even when you are using multiple cameras. NCB-20 makes your life easier and safer.

Backup multiple memory cards in a batch!
The NCB-20 can copy and verify your footage without computer. Each time you put in the memory card, the NCB-20 parse the folder structure then compare it with the stored backup folders and suggest [Copy] or [Verify] depends on the result of the comparison.

Automatic Labeling
Link between camera and backup folder via auto-labeling. To facilitate the management of backup data, the NCB-20 uses the group number to name the folder and label each memory card with the pre-assigned slot name. By assigning each camera man to a specific memory card slot, editors can easily find the origin of footage.

Ensure 100% data safety with Multi-copy [M-copy]
Copy to two USB drives simultaneously to achieve 100% data safety. The NCB-20 simultaneously copies memory cards to two external USB drives at the same time. This M-copy technology minimizes copying time with parallel processing. Two backups to different drives ensure 100% data safety.

Multi-slot USB card reader
No need to carry a separate USB card reader. The NCB-20 can be connected to a computer via USB3 and used as a USB card reader. It is the only USB card reader that supports multiple identical memory cards.

Card Eraser
Erase multiple cards in a batch! You can delete multiple cards with one button click by using [Delete Card] function of the NCB-20. A handy feature for managing multiple memory cards.

Versatile power options
The NCB-20 is designed to support a variety of power options to meet on-site power environments such as V mount battery, D-tap and USB power bank. Operates from 6 to 25V and protects up to 40V.

NCB-20 Software Package

Preview Package
The NCB-20 has 2.4" color LCD which allows you to monitor backed up FULL HD/4K video on the fly. In other words, you can immediately check that your video was backed up safe.

What's in the box:

  • Nexto DI NCB-20 Memory Card Reader and Copier
  • V-Mount Battery Plate
  • USB 3.0 Cable
  • AC Adapter
  • Nexto DI 2 Year Limited Warranty (1 Month on Accessories)
