This item is no longer available.
Designed to customize various memory card modules
• SXS/ XQD/ P2/ REDMAG/ AJA PAK/ CFast/ 2.5" SSD (or 2.5" HDD)
• AXSM/ Express P2/ RED MINI-MAG
Playback 2K, Preview 4K
5 inches TFT-LCD 800 x 480 touch screen + Internal speaker & Stereo audio out Jack, HDMI OUT to an external monitor. The NSB-25 plays back 2K or preview 4K clips on a 5" color TFT LCD monitor. You can also attach a bigger monitor through HDMI interface for a better viewing experience.
Simultaneously Backup up to THREE drives with a single operation (MCopy)
Create three copies with 2 internal hard drive modules and one external USB3.0 (or RAID) drive. Make a copy from the internal hard drive module to the second HDD module or to an external USB3.0 drive without a laptop (SYNC)
Log File
Generates a LOG file(CRC- protected) to safely keep track of usage by the user. The NSB-25 generates a LOG file (CRC-protected) to keep track of usage by the user and then saves it on each drive attached to it. The Log file provides information about XCopy, Sync, computer connectivity etc.
Easy to use with 5 inch touch screen
All functions can be operated by 3 buttons - Power, Enter, Back. The operating status is displayed on LCD.
Slot
Built in CF, SDHC/SDXC slot
Compact flash, SD/SDHC/SDXC
Bridge memory module slot
Interchangeable memory module for user's requirement - SXS, XQD, P2, AJA PACK, CFast, REDMAG, 2.5" SATA drives (Hard drive/SSD), AXSM, express P2 or RED MINI-MAG.
Bridge pellet slot
2 bridge pellets which can hold 2.5 inches SATA Hard drive (or SSD), user put the hard driver (or SSD) by oneself.
Power supply
NSB-25 is running and rechargeable with 6-25 voltages. The reverse power is protected and auto shut-off of overvoltage over 28V Up to 40V. D-tap cable (sold separately) is connected to 6approx.24V big battery for the stable power supply.
Rechargeable battery
The NSB-25 contains an internal Li-Poly battery that enables the NSB-25 to be used without the power adapter. The internal Li-Poly battery can be charged with AC power adaptor or USB3.0. With the full charge of battery, NSB-25 operates for 3 hours to backup with the 2ea of bridge pellets For the full charging, it takes approximately 6 hours using the AC power adapter and 12hours with the USB 3.0 cable.
Interface
Computer
It offers high speed of data transfer with the connection of USB 3.0 port to computer.
USB 3.0
It is connectable to USB external hard drive or RAID.
HDMI out
The video is played on the monitor with HDMI button in playing screen.
Audio
You can check the sound in playback
Interchangeable Memory card module
It is designed with the flexibility to create a backup from almost every memory card, with an interchangeable memory card module.
Supports memory card module
• SXS, XQD, P2, AJA PAK, CFast, REDMAG, 2.5 inches SSD(or hard drive)
• AXSM, express P2, RED MINI-MAG
Simultaneously Backup up to Three drives with a single operation (Mcopy)
After shooting footage,take the card out from your camera and then insert it into the card slot on NSB-25. You can easily and securely create up to three backups (2 hard drive modules and 1 external drive) simultaneously.
Removable Two Drive Module(Bridge pellet)
The NSB-25 ships with 2 removable drive modules(diskless). A module is easily swappable with another one to expand storage space. 2 bridge pellets which can hold 2.5 inches SATA Hard drive(or SSD), user put the hard driver (or SSD) by oneself.
High speed of data transfer with USB 3.0
It is connectable not only NSB-25 but bridge pellet to computer using of USB port.
Normal Playback
H.264 420, MPEG2 420, AVCHD, MPEG2 422 35M, XAVC 420
QUASI Playback
MPEG2 422 50M, PRORES 2K
Preview
AVC-Intra, XAVC 422, DNxHD, 4K footage
4K Pack (Sold separately)
Converts 4K files to H.264(.mov) file format. Playback transcoded files on a 5" color TFT LCD ora bigger monitor through HDMI interface.
Copy All Files to Another Drive (SYNC)
You can quickly and easily copy all files from an internal hard drive module (of the NSB-25) to another drive. Only those files that have changed since the last sync will be copied, to perform faster and save space.
Export Folders
You can select multiple folders and move them from an internal hard drive module to another drive. The selected folders must be located on the same drive.
Display Previous Backup Status
The NSB-25 automatically shuts down if it detects inactivity after the XCopy, MCopy or Verify process. When the device is switched back on again, it displays the previous backup status; either "Success" or "Failed". You can check details in the LOG file for that drive when the Success message is displayed.
Naming a Drive and Folder
When you backup from the card, a folder is automatically created. The folder is named according to the files most recent date (ex. 20140401.000). Folders are numbered in the order they are copied. For multiple users, the NSB-25 does not change the drive name during the Hard drive format. Set your preferred Drive name at the computer to differentiate your drives.
Show thumbnail during copy
You can set up to show thumbnail during copy. It may cause slow performance of backup according to codec.
Error checking before backup
In case of that the video data is damaged due to the dead of battery in the middle of shooting, error message is displayed. Nsb-25 recognize the intact files before the copy except of the invalid data.
Generating LOG file with calculation of CRC code
NSB-25 calculates the CRC(Cyclic Redundancy Check) code for each file during copying the memory card copy and stores it to the LOG file. Users can use Nexto DI CRC Checker program provided by NextoDI to check if the video file is changed from its original copy.
