Netgear ProSAFE 8-Port 10/100 Desktop Switch with 4-Port Power Over Ethernet
See all Netgear items

Netgear ProSAFE 8-Port 10/100 Desktop Switch with 4-Port Power Over Ethernet

SKU: NEFS108PNA
(1)

This item is no longer available.

Recommended Alternatives

Netgear : Picture 1 regular
Netgear ProSafe 5-Port Gigabit Ethernet Desktop Switch
$54.78$39.99
Netgear GS108: Picture 1 regular
Netgear ProSafe GS108 8-Port Ethernet Switch
$49.99
Netgear GS108PP: Picture 1 regular
Netgear GS108PP 8-Port Gigabit Ethernet PoE+ Unmanaged Switch
$139.99
Netgear GS108Tv3: Picture 1 regular
Netgear GS108Tv3 8-Port Gigabit Ethernet Smart Managed Pro Switch
$79.99
See More Recommendations
Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the purpose of the Auto Uplink technology in the NETGEAR ProSAFE FS108 8-Port 10/100 Desktop Switch?

The Auto Uplink technology in the NETGEAR ProSAFE FS108 automatically determines whether a straight-through or cross-over connection is needed, ensuring optimal network setup and connectivity.

Can this switch integrate with 10BASE-T devices?

Yes, the NETGEAR ProSAFE FS108 is designed to effortlessly integrate 10BASE-T devices within higher bandwidth environments, delivering full wire speeds on all ports of either 10 Mbps or 100 Mbps.

Does the NETGEAR ProSAFE FS108 operate silently?

Yes, the ProSAFE FS108 is engineered without the need for internal fans, ensuring it operates silently. This makes it suitable for environments where noise reduction is crucial, such as conference rooms, classrooms, or small offices.

What is the bandwidth support for each port on the NETGEAR ProSAFE FS108?

Each port on the NETGEAR ProSAFE FS108 supports up to 200Mbps in dedicated bandwidth. This ensures that traffic is forwarded flawlessly with automatic flow control.

Is the NETGEAR ProSAFE FS108 easy to install?

Yes, the ProSAFE FS108 offers a plug-and-play design, meaning you just need to connect your Ethernet cables and power cord to start using it. The switch also comes with a wall mount kit for easy installation.

Reviews about this item

Review Summary

2012-07-30T20:00:00

Rated 5 out of 5

Great economical POE switch

I purchased this device to get 4 POE webcams online. Plugged them in and they have not failed and been readily available since installed a year ago. No power-cycling the switch for "hung" devices like I have with another name brand device.

Webcams

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Netgear 10/100 Desktop Switch Specifications

  • Network Ports

    8 auto speed-sensing UTP ports

  • Standards Compliance

    IEEE 802.3 10BASE-T Ethernet
    IEEE 802.3u 100BASE-TX Fast Ethernet
    IEEE 802.3x Full-duplex Flow Control Performance Specifications

  • Forwarding modes

    Store-and-forward

  • Bandwidth

    1.6 Gbps

  • Network latency

    Less than 20 micros for 64-byte frames in store and forward mode for100 Mbps to 100 Mbps transmission

  • Buffer memory

    96 B

  • Address database size

    1000

  • Addressing

    48-bit MAC address

  • Mean Time Between Failure (MTBF)

    168,300 hours (-19 years)

  • Temperature

    Operating: 32 to 104 Degree F (0 to 40 Degree C)
    Storage: 14 to 158 Degree F (-10 to 70 Degree C)

  • Humidity

    Operating: 90% maximum relative humidity, non-condensing
    Storage: 95% maximum relative humidity, non-condensing

  • Altitude

    Operating: 10000' (3000 m) maximum
    Storage: 10000' (3000 m) maximum

  • Safety Agency Approvals

    UL listed (UL 1950)/cUL
    IEC950/EN60950

  • Status LEDs

    Power
    Link, speed, and activity indicators built into each RJ-45 port

  • Electromagnetic Emissions

    CE mark, commercial
    FCC part 15 Class A
    EN55 022 (CISPR22), Class A
    VCCI Class A
    C-Tick

  • AC Power

    7.5 W (7.5VDC, 1A)

  • Dimensions

    6.2 x 4.1 x 1.1" (158 x 103 x 27mm)

  • Weight

    1.1 lbs (0.49kg)

  • UPC Code

    606449037814

About Netgear 10/100 Desktop Switch

FEATURED REVIEWS

Great economical POE switch

By Webcams

I purchased this device to get 4 POE webcams online. Plugged them in and they have not failed and been readily available since installed a year ago. No power-cycling the switch for "hung" devices like I have with another name brand device.

While the NETGEAR ProSAFE FS108 8-Port 10/100 Desktop Switch is part of the highly regarded FS100 series, it stands out for its unique combination of reliability, high-speed performance, and Power Over Ethernet (POE) capabilities. This compact, sturdy metal-cased switch offers seamless LAN connectivity for up to 8 users at auto-sensing speeds of 10/100 Mbps.

With its plug-and-play design, there's no need for software configuration. Simply connect your Ethernet cables and power cord, and the switch is ready to deliver high-speed, reliable network performance. The ProSAFE FS108 is engineered with Auto Uplink technology, which automatically determines whether a straight-through or cross-over connection is needed, ensuring optimal network setup.

This switch is designed to integrate 10BASE-T devices effortlessly within higher bandwidth environments, delivering full wire speeds on all ports of either 10 Mbps or 100 Mbps. Each port supports up to 200Mbps in dedicated bandwidth, and traffic is forwarded flawlessly with automatic flow control.

The ProSAFE FS108 is not only powerful but also compact and quiet. Its fanless design ensures silent operation, making it an ideal choice for environments where noise reduction is crucial, such as conference rooms, classrooms, study groups, or small offices.

The switch is easy to position even when space is at a premium, and it can be placed on any flat surface or mounted on the wall using the included kit. Its simplicity extends to its use as well. Once the hardware is connected, the switch operates automatically, with auto negotiation managing the speed and duplex, and Auto Uplink taking care of the MDI/MDI-X connection. This eliminates the need for toggle switches or special crossover cables.

In summary, the NETGEAR ProSAFE FS108 8-Port 10/100 Desktop Switch with 4-Port Power Over Ethernet is a high-quality, convenient, and user-friendly solution for your networking needs, offering solid performance at an affordable price.

Netgear 10/100 Desktop Switch Features

  • High-speed, reliable performance with 8 auto-sensing 10/100 Mbps ports
  • Power Over Ethernet (POE) capabilities for seamless integration of POE devices
  • Auto Uplink technology for optimal network setup and connectivity
  • Compact, fanless design for quiet operation in noise-sensitive environments
  • Easy installation with plug-and-play setup and included wall mount kit
  • Supports up to 200Mbps dedicated bandwidth per port for flawless traffic forwarding

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • High-speed, reliable performance with 8 auto-sensing 10/100 Mbps ports
  • Power Over Ethernet (POE) capabilities for seamless integration of POE devices
  • Auto Uplink technology for optimal network setup and connectivity
  • Compact, fanless design for quiet operation in noise-sensitive environments
  • Easy installation with plug-and-play setup and included wall mount kit
  • Supports up to 200Mbps dedicated bandwidth per port for flawless traffic forwarding

What's in the box:

  • ProSAFE 8-Port 10/100 Desktop Switch with 4-Port Power Over Ethernet
  • Wall-Mount Hardware
  • AC Adapter
  • Quick Installation Guide
  • Netgear 2 Year Limited Warranty
