Newcon Optik LRM 3500M Specifications

Optics
  • Magnification

    6.5x

  • Objective lens diameter

    30mm

  • Field of view

    7/124 Degree /mil

  • Eye relief

    20mm

  • Diopter adjustment range

    +/-5

Rangefinder

Jump to...
  • Eye safety

    Class 1, eye-safe

  • Wavelength

    1550nm

  • Measuring distance range

    10 - 6,000m

  • Specified measuring distance range

    10 - 3,500m

  • Inclinometer range

    +/-1420mils

  • Distance measurement accuracy

    +/-1m

  • Distance units

    m/yds

  • Azimuth measurement accuracy

    17.5mils

  • Inclination measurement accuracy

    8.8mils

  • Compass & inclinometer units

    Degree /mils

  • Power-on time

    < 1sec

  • First/last target logic

    Yes

  • Target discrimination

    50m

  • Scan mode

    Yes

  • Last 10 readings recall

    Yes

  • Distance between objects

    Yes

  • Horizontal distance between objects

    Yes

  • Azimuth difference between objects

    Yes

  • Inclination difference b/w two objects

    Yes

  • Height difference between objects

    Yes

  • Etched reticle step

    1mils

  • Etched reticle range horizontal/vertical

    120/60mils

  • User GPS coordinates

    Yes

  • Target GPS coordinates

    Yes

  • GPS coordinates format

    Dec Degs Micro

Mechanics, Electronics & Environmental

Jump to...
  • Display type

    Customized Matrix Red OLED

  • Data output ports

    USB, Bluetooth

  • Power supply

    Non-magnetic 2x CR123 Lithium batteries

  • Battery life (# of measurements)

    5000

  • Low battery indicator

    Yes

  • Tripod mountable

    Yes

  • 3-axis digital compass

    Yes

  • Compass calibration & validation

    Yes

  • Operating temperature range

    -35 to +65 Degree C

  • Storage temperature range

    40 to +85 Degree C

  • Waterproofing

    MIL-STD-810G (1m/30min)

  • Mechanical & optical compatibility

    NVS14 and PVS14 night vision devices

General

Jump to...
  • Battery Info

    Required, included

  • Battery Material

    -

  • Battery Quantity

    1

  • Battery Type

    -

  • Dimensions

    4.65 x 4.21 x 2.13" (118 x 107 x 54mm) with no sleeve

  • Weight

    16.2 oz (460g) without batteries

About Newcon Optik LRM 3500M

The LRM 3500M-35BT is the world's most advanced miniaturized laser rangefinder monocular. Weighing just 460 grams, the LRM 3500M-35BT is capable of measuring distance to targets out to 6 kilometers, but what truly sets this device apart from the rest is its built-in GPS receiver allowing for user and target coordinate measurement, digital magnetic compass, inclinometer, bright LED display, Bluetooth capability, Kestrel ballistic calculator and fully ruggedized design. The LRM 3500M-35BT is the ideal tool for professionals who depend on the accuracy and ruggedness of their equipment to get the job done.

Newcon Optik LRM 3500M Features

  • 6,000 m range
  • Distance, Azimuth and Elevation measurements
  • Measurements between two objects
  • Rugged and compact design
  • Android/Bluetooth Compatible

Key Features

  • 6,000 m range
  • Distance, Azimuth and Elevation measurements
  • Measurements between two objects
  • Rugged and compact design
  • Android/Bluetooth Compatible

What's in the box:

  • 6.5x30mm LRM 3500M 35BT Laser Rangefinder Monocular
  • Carrying Case
  • Wrist Strap
  • User Manual
  • Cleaning Cloth
  • Rubber Sleeve (Black)
  • USB/PC Cable
  • V CR123 Battery
  • Newcon Optik 1 Year Limited Warranty
