NewTek TriCaster Mini X HDMI

8x IP video inputs via NDI, resolution-independent

4x HDMI video connections supporting video input in any combination of standard formats, resolutions, and frame rates
2160p: 29.97, 25
1080p: 59.94, 50, 29.97, 25
1080i: 59.94, 50
720p: 59.94, 50, 29.97, 25
SD: 59.94, 50, 25

Support for up to 8 simultaneous Pan-Tilt-Zoom (PTZ) robotic cameras via serial and network protocols, including RS232, RS422, and IP, with integrated controls and preset system

Native support for up to 2 simultaneous Skype video call inputs via Skype TX software integration, including tally and Talk Back communication

IP video output via NDI, optionally configurable for:
4x independent video mix outputs
1x 4K UHD video mix output

2x streaming video output, independently configurable, with simultaneous stream archive

4x mini display port with output adapters
3x of the outputs support multiviewers using standard display resolutions

4x M/E buses supporting video re-entry
1x Mix/Effect channel per bus with support for up to 2 sources
2x KEY layers per bus

2x DSK channels

5x Media Players (2x DDR, 2x GFX, 1x Sound)
15x Media Buffers (10x Live Link or Animation Buffers, 5x Graphics Buffers)

Integrated LiveMatte chroma and luma keying technology on all source channels and M/E buses
8x input keyers
2x media player keyers
4x M/E keyers
15x buffer keyers

Integrated LiveSet technology with 30+ live virtual sets and box effects included

Integrated DataLink technology enabling real-time, automated data input from internal and external sources, including webpages, spreadsheets, scoreboards, databases, RSS feeds, watch files, XML, CSV, ASCII and more

Record, store, edit and automate commands and user-configured operation sequences
Attach to control panel buttons, keyboard shortcuts, hotspots, MIDI and X-keys buttons or GPI triggers
Attach to internal events and state changes, including audio, media playback, tally and specific switcher actions
Supports control via web-based interface

4x recording channels from either NDI inputs or Mix outputs
Records and retains alpha channel data
4x QuickTime archival video recorders (Native NDI Codec for recording)

Capacity varies by format, resolution and file specification Supports recording to external storage via USB 3.0

Grab full-resolution, deinterlaced still images from external video sources and outputs

Export video and image files to social media, FTP, local or external volumes, and network servers, with optional transcoding

Integrated multi-channel audio mixer with support for stereo audio, and DSP's

2x embedded digital audio inputs through HDMI conversion
1x 1/4" (6.35 mm) balanced mic
2x 1/4" (6.35 mm) balanced line

2x embedded digital audio outputs through HDMI conversion
2x 1/4" (6.35 mm) balanced line
1x 1/4" (6.35 mm) stereo headphones jack

Native support for network audio input and output via NDI
Embedded audio supported for all NDI input and output video signals
Integrated support for Dante networking protocol from Audinate

Import, store, and play back multimedia files, with optional transcoding, including:
Video: AVI, DV, DVCPro, DVCProHD, FLV, F4V, H.263, H.264, MOV, MKV, MJPEG, MPEG, MP4, WMV, WebM, and more
Image: PSD, PNG, TGA, BMP, JPEG, JPEG-XR, JPEG2000, EXR, RAW, TIF, WebP, and more
Audio: AIFF, MP3, WAV, and more

Floating Point YCbCr +A 4:4:4:4 Audio: Floating Point, 96 kHz

Processing Latency: -1.0-1.5 frames
Practical Throughput Latency: 4 frames

Support for network tally via NDI

Support for standard MIDI protocol enabling third-party device control

2x 1 Gigabit NIC

4.23 x 9.08 x 7.89" (10.74 x 23.1 x 20.1cm) (Including adjustable handle and cable retention bracket)

8.4 lbs (3.8kg)
