Review Summary
16x (10M/100M/1G) - 1000BASE-T
16x PoE+ (183W PoE budget)
Metal
Metal
Desktop, Rackmount, Wall-Mount
0 (fanless)
2,362,192 hours
Yes
4K
1MB
Store-and-forward
32Gbps
Vietnam
Ports 1-16
Ports 1-16
Up to 15.4W for 802.3af and 30W for 802.3at
183W
16x
External: Input 54V/3.7A
200W (worst case, all ports used, line-rate traffic)
2.68W (link-down standby)
Max: 680.58 BTU
Min: 9.14 BTU
Yes (IEEE 802.3az)
Yes
Yes
Yes
1:3:5:7:8:10:12:15 Weighted Fair Queue (WFQ)
Speed, Link, Activity, PoE
Power Status, PoE Max
IEEE 802.3 Ethernet
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.1p Class of Service
IEEE 802.3az Energy Efficient Ethernet (EEE)
IEEE 802.3i 10BASE-T Ethernet
IEEE 802.3x Flow Control
Operating: 32 to 104 Degree F (0 to 40 Degree C)
Storage: - 4 to 158 Degree F (-20 to 70 Degree C)
Operating: 90% maximum relative humidity (RH), non-condensing
Storage: 95% maximum relative humidity (RH), non-condensing
Operating: 10,000' (3,000m) maximum
Storage: 10,000' (3,000m) maximum
Commercial Class A for FCC part 15, CAN ICES, CE, RCM, KC, VCCI
CB, CE LVD, CSA, RCM, BSMI
11.26 x 4.02 x 1.06" (286 x 102 x 27mm)
1.94 lbs (880g)
606449133318
16 PoE+ ports with 183W total power budget, and includes NETGEAR FlexPoE allowing to reduce the power budget to 155W or even 76W (w/separately purchased power supply modules).
Plug & play
Simple setup with no software or configuration needed.
Power-over-ethernet
16 PoE+ ports with 183W total power budget, and includes NETGEAR FlexPoE allowing to reduce the power budget to 155W or even 76W (w/separately purchased power supply modules).
Flexible mounting
Mount on rack, desktop, or wall.
Small size, metal case, and silent operation
Durable quality, space saver, and quietness for peace of mind.
Sturdy metal case, desktop/rackmount form factor with quiet fans
Can be placed on desk or on mounted rack and will operate quietly with assured durability.
PoE+
Power-Over-Ethernet (PoE) and PoE+ options available for powering IP Security Cameras, VoIP phones, wireless access points, and other PoE-powered devices
These PoE+ Switches are not just flexible in terms of placement they are also flexible in terms of PoE power
Built-in PoE power selector switch that allow for optional / interchangeable power adapters (sold separately) that can be used to increase (or decrease) the PoE power available on the switch
The flexible mounting system gives you the flexibility to place them in a desktop environment, wall mount them, or even rack-mount (accessories included)
