Review Summary
Half width: 1U rack mount
140 Gbps
104.16 Mpps
Switch idle standby, without any port connection: 61.2W - 208.6 BTU/hr
All ports connected full mesh traffic, without PoE: 82W - 279.5 BTU/hr
All ports connected full mesh traffic, with max PoE: 682W - 2324.93 BTU/hr
415,986 hours (47.5 years) @ 25 Degree C ambient (77 Degree F), 346,451 hours (39.5years) @ 45 Degree C ambient (113 Degree F)
119W Base, up to 551W
Thailand
8x ports PoE++ 100M; 1G; 2.5G
2x ports 10G; 25G (Ethernet Mode) (Stacking: 25G)
On/Off switch
1 external power adapter included: APS254W (C14) 3 DC connectors for max 3x APS254W
Fixed front-to-back
Ethernet: Out-of-band 1G port (Back)
Console: USB-C (Front)
Storage: 2x USB-A (Back)
Default mode:
551W:
Fan Duty: 32
Ambient: 25 Degree C
Case Temp (Top): 47.6 Degree C
Acoustic: 32.2dBA
Fan Duty: 100%
Case Temp (Top): 28.3 Degree C
Acoustic: 59.4dBA
16K MAC, 4K ARP / 512 NDP
140 Gbps Line-Rate
104.16 Mpps
Static: 256v4/64v6
RIP: 512
OSPF: 1,024
32MB
<5.50micros 2.5G, <0.70micros @ 10G fiber, <0.64micros@ 25G
4 GB
Quad-Core Cortex-A57 ARMv8 1.8Ghz 64-bit
512 IPv4, 256 IPv6
Up to 12K
2K IPv4, 2K IPv6
4K VLANs
DHCP Server: 2K leases, IPv4: 256 pools, IPv6: 16 pools
8x ports PoE++, 119W base up to 551W
2x ports Ethernet mode: 10G/25G; Stacking mode: 25G
2.5G ports: 8x; 25G ports: 2x
USB-C (front)
1x RJ45 10/100/1000BASE-T (back)
2x USB-A (back)
1
3 connectors for external APS254W power adapters
Front-to-back airflow
Ultra60 PoE++ Ports (802.3bt): 8x
Fan Duty: 100
Case Temp (Top): 28.3 Degree C
Acoustic: 59.4dBA
32 to 113 Degree F (0 to 45 Degree C)
90% maximum relative humidity, non-condensing
10,000' (3,000m) maximum
-4 to 158 Degree F (-20 to 70 Degree C)
95% maximum relative humidity, non-condensing
10,000' (3,000m) maximum
8.66 x 1.7 x 11.81" (220 x 43.2 x 300mm)
6.39 lbs (2.9kg)
606449172911
Power and Throughput
Edge to core flexible platform, from 1 Gigabit to 100 Gigabit, good for projects of all sizes.
Fast, Easy Configuration for AV Pros
A streamlined interface using certified profiles with settings for any AV or broadcast application assigned to ports with just a few clicks.
Focus on the Event Not the Fan Noise
Most models have quiet mode which greatly reduces fan noise.
Designed For AV Over IP Right out of the Box
With built-in NETGEAR IGMP Plus, there's little-to-no setup required for flawless audio and video delivery. Enable multicasting right out of the box.
Maximize Performance with Pro Wi-Fi Access Points
Enable powerful, reliable Wi-Fi at your location with Pro Wi-Fi access points, powered by PoE or an external power adapter.
Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.
Multicast in an Instant
NETGEAR IGMP Plus provides multicast functionality right out of the box for most AV over IP applications.
Sleek, Quiet Design
Less fan noise, and mounting ears included for rack mounting.
Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4350 switches.
