Nikon Z5II Mirrorless Camera with NIKKOR Z 24-200mm f/4-6.3 VR Lens

Digital camera with support for interchangeable lenses

Nikon Z mount

24.5 million

23.9 x 35.9mm

FX

CMOS

25.28 million

Image sensor cleaning, Image Dust Off reference data (requires NX Studio)

Yes

FX-format:
(L)6048 x 4032
(M)4528 x 3024
(S)3024 x 2016

DX-format:
(L)3984 x 2656
(M)2976 x 1992
(S)1984 x 1328

1:1 (24 x 24):
(L)4032 x 4032
(M)3024 x 3024
(S)2016 x 2016

16:9 (36 x 20):
(L)6048 x 3400
(M)4528 x 2544
(S)3024 x 1696

NEF (RAW): 14 bit with lossless, high-efficiency, and high efficiency options; JPEG: JPEG-Baseline compliant with fine (approx. 1:4), normal (approx. 1:8), or basic (approx. 1:16) compression; size-priority and optimal-quality compression available

HEIF: Supports fine (approx. 1 : 4), normal (approx. 1:8), or basic (approx. 1:16) compression; size-priority and optimal-quality compression available; NEF (RAW)+JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats; NEF (RAW)+HEIF: Single photograph recorded in both NEF (RAW) and HEIF formats

SD (Secure Digital), SDHC, and SDXC memory cards (SDHC and SDXC memory cards are UHS-II compliant)

2 slots (SD and SD)

DCF 2.0, Exif 2.32, MPEG-A MIAF

0.5" (1.27cm) Approx. 3690k-dot (Quad VGA) OLED electronic viewfinder with color balance and auto and 18-level manual brightness controls

Approx.. 100% horizontal and 100% vertical

Approx.. 0.8x (50mm lens at infinity, -1.0 m -1)

21mm (-1.0 m-1; from rearmost surface of viewfinder eyepiece lens)

-4 - +2 m-1

Automatically switches between monitor and viewfinder displays

Yes

Z mount NIKKOR lenses, F mount NIKKOR lenses with mount adapter; restrictions may apply

Z mount NIKKOR lenses, F mount NIKKOR lenses with mount adapter; restrictions may apply

Electronically-controlled vertical-travel focal-plane mechanical shutter; electronic front-curtain shutter; electronic shutter

1/8000 - 30s (choose from step sizes of 1/3, 1/2, and 1 EV, extendable to 900 s in mode M), bulb, time. When using an electronic shutter, the shutter speed can be set up to 1/8000s.

1/8000 (mechanical shutter), 1/2000 (electronic shutter) sec.

900 seconds sec.

Up to: 1/200th sec.

Yes

Single frame, Continuous L, Continuous H, Continuous high-speed (extended), High-speed frame capture with Pre-Release Capture, Self-timer

Continuous L: Approx 1-7 fps, Continuous high-speed: [Mechanical shutter]) Approx. 9.4 fps. (when the shutter type is set to [Electronic front-curtain shutter]) Approx. 10 fps (when silent mode is set to [ON]). Continuous high-speed (extended): Approx. 14 fps, Approx. 15 fps (when silent mode is set to [ON])

High-speed frame capture + (C15): Approx. 15 fps, High-speed frame capture + (C30): Approx. 30 fps, Maximum frame advance rate as measured by in house tests Continuous high-speed and Continuous high-speed (extended) specs using an image quality setting other than NEF (RAW) or NEF (RAW) + JPG.

Continuous L: 1-7 fps, Continuous H: 1-8.1 fps (up to 16 fps with electronic shutter), Continuous H extended: 14 fps (up to 20 fps with electronic shutter), High-speed frame capture + (C15): Approx. 15 fps, High-speed frame capture + (C30): Approx. 30 fps, Maximum frame advance rate as measured by in house tests

30 frames per second (at Full Resolution)

2, 5, 10, 20 sec.; 1-9 exposures at intervals of 0.5, 1, 2, or 3 sec.
Timer duration electronically controlled

Yes

TTL metering using camera image sensor

Matrix metering, Center-weighted metering: Weight of 75% given to 12 mm or 8 mm circle in center of frame or weighting can be based on average of entire frame, Spot metering: Meters 4 mm circle centered on selected focus point, Highlight-weighted metering

-4 to +17 EV (ISO 100, f/2.0 lens, 20 Degree C/68 Degree F)

Auto, Programmed auto with flexible program (P), Shutter-priority auto (S), Aperture-priority auto (A), Manual (M)

-5 - +5 EV (choose from step sizes of 1/3 and 1/2 EV)

Yes

Luminosity locked at detected value

Auto, Standard, Neutral, Vivid, Monochrome, Flat Monochrome, Deep Tone Monochrome, Portrait, Rich Tone Portrait, Landscape, Flat; Creative Picture Controls: (Dream, Morning, Pop, Sunday, Somber, Dramatic, Silence, Bleached, Melancholic, Pure, Denim, Toy, Sepia, Blue, Red, Pink, Charcoal, Graphite, Binary, Carbon)

Selected Picture Control can be modified, Storage for custom Picture Controls, Note: Choice of Picture Controls is restricted to Standard, Monochrome, and Flat when HLG is selected for tone mode during still photography.

Add, average, lighten, darken

Yes

Yes

ISO 100 to 64000 in steps of 1/3 and 1 EV, Can also be set to approx. 0.3, 0.7, or 1 EV (ISO 50 equivalent) below ISO 100 or to approx. 0.3, 0.7, 1 or 1.7 EV (ISO 204800 equivalent) above ISO 64000; auto ISO sensitivity control available; Note: ISO sensitivity is limited to 400-64000 when HLG is selected for tone mode.

100

64000

50

204800

Yes

Yes

Can be selected from:
Auto, Extra high, High, Normal, Low, and Off

Yes

Yes

Yes

Yes

Hybrid phase-detection/contrast AF with AF assist

-10 - +19 EV. Measured in photo mode at ISO 100 and a temperature of 20 Degree C/68 Degree F using single-servo AF (AF-S) and a lens with a maximum aperture of f/1.2

Autofocus (AF), Single-servo AF (AF-S), Continuous-servo AF (AF-C), Full-time AF (AF-A) available only in photo mode), Full-time AF (AF-F) available only in video mode), Manual focus (M): Electronic rangefinder can be used

273 focus points (single-point AF), 299 focus points (auto-area AF), Number of focus points available in photo mode with FX selected for image area

Pinpoint, Single-point, Dynamic-area (S), Dynamic-area (M), Dynamic-area (L), Wide-area AF (S), Wide-area AF (L), Wide-area AF (C1), Wide-area AF (C2), Auto-area AF, 3D-tracking, Subject-tracking AF, Pinpoint (available in photo mode only); Single-point, dynamic-area (S, M, and L; available in photo mode only); wide-area (S, L, C1, and C2), and auto-area AF; 3D-tracking (available in photo mode only); Subject-tracking AF (video mode only)

Focus can be locked by pressing shutter-release button halfway (single-servo AF/AF-S) or by pressing the center of the sub-selector

AF-S, AF-C, AF-A (photo), AF-F (video), MF

299

5-axis image sensor shift, lens shift (available with VR lenses)

Yes

Yes

1/200th sec. sec.

Up to: Up to 1/8000 sec. sec.

TTL: i-TTL flash control; i-TTL balanced fill-flash is used with matrix, center-weighted, and highlight-weighted metering, standard i-TTL fill-flash with spot metering

Front-curtain sync, Rear-curtain sync, Red-eye reduction, Red-eye reduction with slow sync, Slow sync, Off

-3 to +1 EV (choose from step sizes of 1/3 and 1/2 EV)

Lights when optional flash unit is fully charged; flashes as underexposure warning after flash is fired at full output.

ISO 518 hot-shoe with sync and data contacts and safety lock

i-TTL flash control, optical Advanced Wireless Lighting, modeling illumination, FV lock, Color Information Communication, auto FP high-speed sync

No

Auto (3 types), Choose color temperature (2,500 K-10,000 K), Cloudy, Direct sunlight, Flash, Fluorescent (3 types), Incandescent, Natural light auto, Shade, Preset manual (up to 6 values can be stored), all with fine-tuning

Yes

TTL metering using camera image sensor

2 hours 5 minutes

NEV, MOV, MP4

N-RAW (12 bit), H.265/HEVC (8 bit/10 bit), H.264/AVC (8 bit)

Linear PCM (48 KHz, 24 bit, for videos recorded in NEV or MOV format), AAC (48 KHz, 16 bit, for videos recorded in MP4 format)

FX: 4032 x 2268: 30p/25p/24p. DX: 4032 x 2268: 3984 x 2240: 30p/25p/24p. 3984 x 2240: 120p/100p/60p/50p/30p/25p/24p. Note: Actual frame rates for 30p, 25p, and 24p are 29.97, 25, and 23.976 fps respectively.

Yes

Yes

Yes

Built-in stereo or external microphone can be used; sensitivity adjustable; attenuator, frequency response, and wind noise reduction functions

Mode M: Manual selection (ISO 100 to 51200; choose from step sizes of 1/6, 1/3 and 1 EV); with additional options available equivalent to approx. 0.3, 0.7, 1, or 2 EV (ISO 204800 equivalent) above ISO 51200; auto ISO sensitivity control (ISO 100 to Hi 2.0) available with selectable upper limit. Modes P, S, A: Auto ISO sensitivity control (ISO 100 to Hi 2.0) with selectable upper limit. AUTO mode: Auto ISO sensitivity control (ISO 100 to 51200).

Can be selected from:
Extra high, High, Normal, Low, and Off

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes (for RAW video)

Yes

Yes (available via I menu)

Yes

3840 x 2160 (4K UHD): 60p/50p/30p/25p/24p. 1920 x 1080: 120p/100p/60p/50p/30p/25p/24p. 1920 x 1080 (slow-motion): 30p x4 (slow-motion)/25p x4 (slow-motion)/24p x5 (slow-motion). Actual frame rates for 120p, 100p, 60p, 50p, 30p, 25p, and 24p are 119.88, 100, 59.94, 50, 29.97, 25, and 23.976 fps respectively

3.2" diagonal

2100 k dots

Vari-angle TFT touch-sensitive LCD

Yes

170 Degree viewing angle

Color balance. 15-level manual brightness controls.

Yes

Full-frame and thumbnail (up to 4, 9, or 72 pictures) playback with playback zoom, playback zoom cropping, histogram display, highlights, video playback, photo information, location data display, auto picture rotation, picture rating, voice memo input and playback, IPTC information embedding and display, Slide shows, Filtered playback, Skip to first shot in series, Series playback, Save consecutive frames, Motion blend

RAW processing, Trim, Resize, D-Lighting, Straighten, Distortion Control, Perspective Control, Monochrome, Overlay, Lighten, Darken, Motion Blend

Yes

Yes

USB: Type C SuperSpeed USB connector, HDMI: Type D HDMI connector, Audio Input: Stereo mini-pin jack (3.5 mm diameter; plug-in power supported), Audio Output: Stereo mini-pin jack (3.5 mm diameter) /MC-DC3 remote cord can be used. The connector function can be set to either auto switch or fixed to headphones.

Standards: IEEE 802.11b/g/n/a/ac U.S.A., Canada, and Mexico). IEEE 802.11b/g/n/a (other countries in the Americas). Operating frequency: U.S.A., Canada, and Mexico: 2412 to 2462 MHz (channel 11) and 5180 to 5825 MHz (5180 to 5580 MHz, 5660 to 5700 MHz, and 5745 to 5825 MHz).

Other countries in the Americas: 2412 to 2462 MHz (channel 11) and 5180 to 5805 MHz (5180 to 5320 MHz and 5745 to 5805 MHz). Maximum output power (EIRP): 2.4 GHz band: 1.6 dBm; 5 GHz band: 6.3 dBm. Authentication: Open system, WPA2-PSK, WPA3-SAE.

SnapBridge

Yes

Yes

Communication protocols: Bluetooth Specification Version 5.0. Operating frequency: Bluetooth: 2402-2480 MHz; Bluetooth Low Energy: 2402-2480 MHz. Maximum output power (EIRP): Bluetooth: -3.9 dBm; Bluetooth Low Energy: -5.4 dBm.

Yes

English, Spanish, French, Portuguese

Yes

Yes

84

Yes

Yes

English, Spanish, French, Portuguese

Yes

EN-EL15c

Photo Mode (Single Frame): Number of Shots
[Viewfinder only] selected for monitor mode with: [ON] selected for [Energy saving (photo mode)] in the setup menu: Approx. 380 shots - [Viewfinder only] selected for monitor mode with: [OFF] selected for [Energy saving (photo mode)] in the setup menu: Approx. 330 shots

[Monitor only] selected for monitor mode with: [ON] selected for [Energy saving (photo mode)] in the setup menu: Approx. 350 shots - [Monitor only] selected for monitor mode with: [OFF] selected for [Energy saving (photo mode)] in the setup menu: Approx. 350 shots

Video Mode: Length of Footage:
[Viewfinder only] selected for monitor mode: Approx. 85 minutes
[Monitor only] selected for monitor mode: Approx. 85 minutes

EH-8P AC charging adapter (available separately); requires UC-E25 USB cable (supplied with camera). EH-5d, EH-5c, and EH-5b AC adapters; requires EP-5B power connector (available separately).

MH-25A, MH-34

Required, included

Lithium ion

Non-universal

1

(1/4", ISO 1222)

Temperature: +14 Degree F to 104 Degree F (0 Degree C to 40 Degree C); Humidity: Less than 85% (no condensation)

5.3 x 4 x 2.9" (134 x 100.5 x 72mm)

24.7 oz (620g)

Nikon Z Mount

24 -200mm

8.3x

f/4

f/22

FX

61 Degree

8 Degree

84 Degree

12 Degree 20

0.28x

19

15

FX, DX

Yes

7

Yes

Yes

2

Yes

2

Yes

Yes

Yes

1.64' (0.5m) at 24mm zoom position, 1.78' (0.54m) at 35mm zoom position, 1.81' (0.55m) at 50mm zoom position, 1.91' (0.58m) at 70mm zoom position, 2.14' (0.65m) at 105mm zoom position, 2.24' (0.68m) at 135mm zoom position, 2.30' (0.7m) at 200mm zoom position

Autofocus, Manual

67mm

Screw-in

Approx. 3.1 x 4.5" (76.5 x 114mm)

Approx. 20.2 oz (570g)

018208016884
