Neumann KH 120 D Active Studio Monitor with Digital I/O and Delay

The Neumann KH 120 D Active Studio Monitor with Digital I/O and Delay is designed for use as a near-field loudspeaker or as a rear loudspeaker in larger multi-channel systems. It represents the latest in acoustic and electronic simulation and measurement technologies to ensure the most accurate sound reproduction possible. It has a Mathematically Modeled Dispersion waveguide (MMD), flexible acoustical controls, analog class-AB amplifiers, various input formats (analog and digital) and an extensive mounting hardware range. All of this provides the user with the maximum versatility over a wide variety of acoustic conditions, source equipment and physical locations. It is perfect for tracking, mixing and mastering in music, broadcast, project and post-production studios.

Powerful Titanium Fabric Dome
Low-distortion high-frequency reproduction

Elliptical Mathematically Modeled Dispersion (MMD) Waveguide
Smoother off-axis response, More forgiving of diverse acoustical environments

Composite Sandwich Cone
Damping of break-up modes

Long Throw Bass Driver
Low distortions at high sound levels

Two-color + Dimmable Neumann Logo
Displays operation status and activation of the extensive protection system

Robust Metal Grille
Protects against mechanical damage

Large Front Panel Ports
Reduced bass compression and easier to mount in tight spaces such as OB vans

Compact Aluminum Cabinet (Magnetically Shielded)
Minimizes resonances, better heat dissipation, long life

Wide Horizontal Dispersion
Freedom of movement across the mixing console

Narrow Vertical Dispersion
Reduces reflections off the mixing console

One-piece Front Panel with No Discontinuities
Reduced diffraction and smoother frequency response

Powerful Analog Amplifiers with Large Headroom
Improved transient response

Production Consistency
Any KH 120 is "pair-matched" to any other KH 120

4-position Bass, Low-Mid and Treble Acoustical Controls
More control in diverse acoustical environments

Wide Range Input Gain and Output Level Controls
Easier interfacing with signal sources

New Mounting Hardware Options
More flexibility in mounting cabinets in more diverse locations

Display Dimmer
For low lighting level conditions or behind the screen applications

Ground Lift
Reduced noise in electrically noisy environments and over-comes ground loops

Universal Switched-Mode Power Supply (100 to 240 V)
One version works in any country and robust to poor quality mains supply

Separate Woofer and Tweeter Electronic Peak Limiters and Thermal-Protection Circuitry
High reliability

Analog XLR Input
Compatible with any analog line signal

Digital BNC Input and Buffered BNC Output
For flexible and trouble-free digital interconnectivity (24 bit, 192 kHz, AES3 and S/P-DIF)

Lipsync Delay (0 to 10/12 Frames)
To align audio and video signals

Time-of-flight Delay (0 to 400 Ms)
To compensate for listening distance differences.
