Nipros HDF-700 7" Viewfinder with Studio Hood & Mount, 800 x 480 Resolution, 2 x BNC HD/SD-SDI Input

The HDF-700 7-inch TFT-LCD professional viewfinder/monitor is made by cameraman point of view, each function is crystallized to reach the best of usability. Clear Peaking, Advanced Zebra, Waveform Monitor & Vector Scope, 16 Ch. Embedded Audio Monitor, SDI Error Detection are advanced professional viewing functions of HDF-700. It is an easy to operate and highly durable viewfinder/monitor. HDF-700's Quick turn back to default settings, TC Tally and Return switch functions are some of unique features.

HD/SD-SDI
HD/SD-SDI camera and return signals can be viewed and transferred by loop through connector.

Return Control Switch
Most important function for multicamera system; Return signal can be switched by return button on Nipros AS-1 zoom controller. In case of PinP function is ON, return switch changes the camera and return signals' positions.

Black&White or Color Modes
Blue Only, Red Only, Green Only, Color Mode or Black&White modes.

Tally Indicator
Built-in tally indicator with green and red colors on back and front sides.

TC Tally Function
Tally lamp is ON when camera is recording. This function is available if only camera is on REC-RUN mode.

Advanced Features
• Clear Peaking
• Advanced Zebra
• Waveform Monitor & Vector Scope
• 16 Ch. Embedded Audio Monitor
• SDI Error Detection
• HD/SD-SDI
• Return Switch Control
• Built-in Tally Indicator
• Black&White or Color Modes
• HD/SD-SDI Return
• TC Tally
• V-Mount Plate
• Audio Level Meter

User-friendly Buttons
Quick adjustment and easy set up. Default or User settings can be selected by pushing the knobs.

2 Ch. Audio OUT
Embedded audio can be seperated and used by 2 channel XLR-3pin audio outputs.

Easy Attachment and V-Mount Battery
Quick attachment with Nipros QM-1. V-Mount battery operation for HDF-700V.

Camera I/F
Camera Interface connection allows cameraman to use all camera viewfinder's functions with Nipros professional viewfinders.
