NewerTech MAXpower 4-Port USB 3.1 Gen1 Type-A PCI Express Controller Card

SKU: NTMXPCIE4U3

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

NewerTech MAXpower PCI Card Specifications

  • Chipset

    USB 3.1 Gen 1 (4): Fresco Logic FL-1100EX

  • Connector Type

    PCIe 2.0 (fits x4 or larger slot, runs at x1 speeds)

  • System Requirements

    Operating System:
    Mac: 10.8.5 and later
    PC: Windows 7 and later

    Hardware:
    Recommended: Any Mac or PC with PCIe 2.0 or higher slot (x4 or larger slot required)
    Minimum: Any Mac or PC with a PCIe 1.0 slot (x4 or larger slot required)
    Thunderbolt PCIe expansion chassis: supported

  • Driver

    Driver required for Windows 7 only Download here

  • Boot Support

    Requires a Thunderbolt PCIe expansion chassis that is connected to a Mid-2013 or later Mac host computer

  • Sleep / Hibernation Support

    If using a Mac, you may experience disk ejections when waking from Sleep mode. This is a known issue that occurs when using add-on PCIe cards with the Mac operating system. It is suggested that you manually eject USB devices prior to enabling Sleep mode on a Mac. This issue is not present with Windows

  • Hot Plug / Hot Swap Support

    Supported on any compatible Mac or PC

  • USB Hubs / Card Reader Support

    Supported on any compatible Mac or PC

  • USB Battery Charging

    Supports USB BC 1.2 specification
    Total power available: 24W (5V/4.8A)
    Each port provides 5V/1.2A

  • Maximum Performance

    Sequential Read/Write (compressible data)
    Read: 350 MB/s
    Write: 333 MB/s

  • Operating Temperature

    32 to 158 deg. F (0 to 70 deg. C)

  • Non-Operating Temperature

    -40 to 185 deg. F (-40 to 85 deg. C)

  • Dimensions (LxHxW)

    3.7 x 4.7 x 0.9" (9.40 x 11.94 x 2.29cm)

  • Weight

    0.2 lbs (0.09kg)

  • UPC Code

    811643016446

About NewerTech MAXpower PCI Card

The MAXPower USB 3.1 Gen1 - 4 Port PCIe card delivers ?an additional 4 high-power, high bandwidth USB Type-A ports for both Mac Pro and PC. They provide the maximum wattage and data throughput from all 4 ports. Now there's no need to look for an extra USB port.

• Add 4 USB 3.1 Type-A ports to any Mac & PC with an open PCIe slot
• Deliver maximum power available through all 4 ports
• Up to 5Gb/s throughput from all 4 ports
• Easy to install
• Adds four USB 3.1 Gen 1 Type-A ports (female) to expand your Mac Pro to handle all the USB devices you need.
• Works with ANY USB Type-A interfaced devices.
• USB 3.1 is backwards compatible with USB 3.0 and USB 2.0.: USB-B 3.1 cables are not compatible with USB-B 2.0 ports, Unless you use an adapter, USB-C ports or cables will not work with USB Type-A or USB Type-B ports or cables, Devices that require USB 3.1 transfer speeds of 10Gbps might not work with USB 3.0 or USB 2.0 or you might experience lower transfer speeds and impacted performance, Bus-powered USB devices that requires more power than what USB 2.0 can provide are not compatible with USB 2.0
• Up to 5Gb/s transfer bandwidth per port.
• Up to 10W per port for high power using USB devices (External storage).
• Plug and Play ready.
• Compatible with USB Type-A port equipped external storage solutions and optical drives.
• 3 Year NewerTech Product Limited Warranty

Power
Each of the four USB ports delivers up to 10 watts of power to fully charge and power USB devices.

Performance
Each of the four USB ports delivers up to 5Gb/s data transfer speed to maximize performance of all your USB devices.

What's in the box:

  • NewerTech MAXpower 4-Port USB 3.1 Gen1 Type-A PCI Express Controller Card
  • NewerTech 3 Year Limited Warranty
