Orion SkyQuest XX12i 42-300x305 Dobsonian Telescope, Shroud & Case Set, 1500mm f/4.9 Focal Length, 0.38arc sec Resolving Power, 2" Crayford

SKU: ONXX12PSCS

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Orion SkyQuest XX12i Specifications

About Orion SkyQuest XX12i

The Orion XX12i Package includes the innovative XX12i Truss Tube Dobsonian, view optimizing Light Shroud, and Case Set to hold and transport the optical tube components safely. It's a deep-sky observer's dream scope, offering jumbo 12" Pyrex optics (f/4.9); a stylish, reduced-weight base outfitted with IntelliScope object location technology; and a sturdy truss tube design that disassembles in about a minute into compact, easily portable components.

EbonyStar laminate and non-stick PTFE azimuth bearing surfaces provide silky smooth azimuth motion. Equipped with dual-speed (11:1) 2" Crayford focuser, large 8" altitude bearings, full set of great accessories, a computerized database of 14,000 celestial objects.

The SkyQuest XX12i Truss Tube Dobsonian Shroud is made of a stretchy nylon blend material that fits like a glove over the truss poles of the XX12i, fastening with thick elastic bands on both ends. The water-resistant, opaque black fabric blocks stray light from entering the optical path, thus improving image contrast. It's also breathable, which minimizes unwanted vibration of the scope in breezy conditions. Use of the shroud will lessen the accumulation of dust and dirt on the mirrors during use, and will help prevent dew from forming on them.

The beauty of a big truss tube Dob is that it can be disassembled into conveniently sized components for easy transport. And transporting the SkyQuest XX12i will be much easier, and the components much better protected, with this set of cases designed just for the XX12i. The set includes three cases plus a secondary mirror cover. Each case is made of durable, waterproof, 600-denier polyester/nylon material with a urethane coating and a 100% nylon lining, and double stitched for extra strength. There are separate padded cases for the upper and lower optical tube sections as well as a case for the truss poles. The poles slip into separate compartments to prevent direct contact among them.

The truss case attaches to the lower optical tube case with a hook-and-loop fastener so the two can be carried together as one. The lower tube case also has a zippered pocket to hold accessories. All the cases have carrying handles. The soft nylon secondary mirror "sock" is included to keep the mirror free of dust when the scope is idle. Keep your SkyQuest XX12i Truss Tube Dob looking like new and get it to your observing site more easily and securely with this set of cases.

What's in the box:

  • Orion 12" f/4.9 Truss-Tube Dobsonian Reflector Telescope with Parabolic Pyrex Primary Optics
  • 9-Point Flotation Primary Mirror Cell with Spring Loaded Thumbscrew Collimation Adjustments
  • 70mm Minor-Axis Secondary Mirror on 4-Vaned (0.7mm Thick Vanes) Secondary Holder
  • Shroud
  • Case for Top Tube Section
  • Case for Bottom Tube Section
  • Case for Truss Pole Assemblies
  • Soft Cover for Secondary Mirror
  • Orion 1 Year Limited Warranty
  • (See Specs Section for More Included Items)
