Orion Images Premium Series RNK46UHF4K 46" 4K UHD Video Wall LED Monitor
See all Orion Images items

Orion Images Premium Series RNK46UHF4K 46" 4K UHD Video Wall LED Monitor, 1920x1080, 2.2mm/1.3mm Bezel Width

SKU: ORRNK46UHF4K

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Orion Images RNK46UHF4K Specifications

Display

Display

Jump to...

  • Screen Size

    46"

  • Bezel Width

    2.2mm / 1.3mm

  • Max. Resolution

    1920 x 1080 at 60Hz

  • Pixel Pitch

    0.53 x 0.53mm

  • Brightness

    700cd/square meter

  • Contrast Ratio

    '3500:1

  • Aspect Ratio

    '16:9

  • Viewing Angle (H/V)

    178 / 178 deg.

  • Display Color

    16.7 Million

  • Response Time

    < 8ms (Gray to Gray)

  • Video System

    NTSC / PAL

  • Frequency (H)

    60-75 KHz(H)

  • Frequency (V)

    55-75 Hz(V)

Interface Ports

Jump to...

  • Display Port In (ver. 1.2)

    1

  • HDMI In (ver. 1.4)

    1

  • DVI-D In

    1

  • RS-232 In / Out

    4/1

  • PC Stereo In

    1

  • Speaker Out

    1

  • VGA In (15 Pin D-Sub)

    1

Transmitter

Jump to...

  • Remote Control

    Yes

  • Magnetic Key Button Control

    Yes

Audio

Jump to...

  • Built-in Speakers

    Yes (5W x 2)

Features

Jump to...

  • Multi Display Function

    Yes (PIP / PBP)

  • Noise Reduction

    Yes

  • Image Rotation

    Yes (Landscape & Portrait)

  • Menu Rotation

    Yes (Landscape & Portrait)

  • Aspect Ratio

    Yes (Full, 4:3, 5:4, 1:1)

  • Dynamic Contrast

    Yes (ON / OFF)

  • Gamma Selection

    Yes (1.8, 2.0, 2.2, 2.4 and 2.6)

Mechanical

Jump to...

  • Material

    Electro-Galvanized Steel

  • Electrical Ratings

    AC 100-240 V (50/60Hz)

  • Power Consumption

    <210W

  • Operating Temperature

    0 to 40 deg. C / 32 to 104 deg. F

  • VESA Mount Size

    800 x 400mm

  • Dimensions

    Outline: 40.24 x 22.70 x 5.04" / 102.21 x 57.66 x 12.80cm

  • Weight

    29.9kg / 65.92lbs

About Orion Images RNK46UHF4K

ORION Images is a true manufacturer of LCD CCTV monitors. The ORION Images monitors are true Commercial Grade with FCC Class A Certification - Built to Run 24 x 7 x 365 continuously. Their monitors are designed, engineered and manufactured with CCTV PCB boards and circuitry making these the LCD solution for your security surveillance.

The 46 inch RNK 4K series of RNK46UHF4K LED displays is the perfect solution for ultra high definition video walls. With a total of 3840 x 2160 pixels (based on 2 x 2 configuration) and the ability to take a single video source and display it across the entire video wall it is an excellent choice for command & control centers, corporate AV and digital signage applications.

Orion Images RNK46UHF4K Features

  • 46 Inch High Contrast 1920 x 1080 Resolution Panel with LED Backlight
  • Anti-Reflection Front Coating
  • Full 60fps Frame Rate (Display port)
  • Multi-Input Interface: Diplay Port, HDMI, DVI-D, VGA
  • Image Rotation: Landscape and Portrait
  • Menu Rotation: Landscape and Portrait
  • Aspect Ratio: Full / 4:3 / 5:4 / 1:1
  • Dynamic Contrast: ON / OFF
  • Gamma Selection: 1.8 / 2.0 / 2.2 / 2.4 and 2.6
  • Super Resolution: ON / OFF
  • Wide Viewing Angle
  • Industrial Grade Metal Cabinet

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • 46 Inch High Contrast 1920 x 1080 Resolution Panel
  • Anti-Reflection Front Coating
  • Full 60fps Frame Rate (Display port)
  • Multi-Input Interface
  • Dynamic Contrast: ON / OFF
  • Gamma Selection: 1.8 / 2.0 / 2.2 / 2.4 and 2.6

What's in the box:

  • Orion Images Premium Series RNK46UHF4K 46 " 4K UHD Video Wall LED Monitor
  • Orion Images 3 Year Parts & Labor Warranty
