Orion Images Premium Series RNK70NSF 70" Full HD Sunlight Readable Video Wall LED Monitor, 1920x1080, 20.0mm Flat Narrow Beze Width

ORION Images is a true manufacturer of LCD CCTV monitors. The ORION Images monitors are true Commercial Grade with FCC Class A Certification - Built to Run 24 x 7 x 365 continuously. Their monitors are designed, engineered and manufactured with CCTV PCB boards and circuitry making these the LCD solution for your security surveillance.

ORION Images RNK Sunlight Readable video wall monitors offer enhanced high brightness of 1000 Nit LCD color display for high ambient light applications. This 70 Inch LED RNK70NSF with 20.0mm Narrow Bezel Sunlight Readable video wall monitor is Perfect for tight mounting Video Wall. These Transflective enhanced anti-glare displays are readable under all lighting conditions including direct or indirect sunlight - the stronger the ambient light the brighter the image.

The advantage of Transflective technology is that there is no extra heat generation lower power consumption, contrast and brightness is naturally brighter to help preserve the life of the back light. These 70 Inch RNK70NSF Super Narrow Bezel Sunlight Readable Video Wall has Immediate Benefits for Digital Signage, Public Display, Shopping Mall, Corporation, factory, University & College, Government, Casino and more.

• 70 Inch Screen Size LED Full HD Sunlight Readable Video Wall
• 20.0mm Flat Narrow Bezel Perfect for tight mounting Video Wall
• 1920 x 1080p Full HD Resolution
• Video (BNC Type) 2 In / 2 Out, HDMI 1 In / 1 Out, DVI-D 1 In / 1 Out, VGA 1 In / 1 Out, Audio 3 In, RS232 1 In / 1 Out, PC Stereo 1 In, Speaker 1 Out
• View Dual Input Sources on 1 Monitor via PBP
• RS-232C In & Out for Controlling the Monitors
• Perfect for both Video Wall or Independent Mount Solutions
• RNK Sunlight Readable Video Wall has Immediate Benefits for Digital Signage, Bus station, Retail, Shopping Mall, Corporation, Transportation, Government, Casino and more
• Optional Video Wall Mount Solutions

Sunlight Readable video walls
ORION Images Transflective Sunlight Readable products enhance panel PC systems in terms of brightness, dimming range and viewing pleasure. Such characteristics are superior to regular LCD PC & Monitor. These products can be used for special mounting applications, especially in KIOSK, Gaming / Casino, Factory Automation, Information Terminal and Panel Wall.

Transflective LCD modules hold both transmissive and reflective properties; the method of image display depends upon the conditions of the ambient environment. The display uses a backlight with a transmissive property in dark environments and uses external light with a reflective property in bright environments.

Video Wall for Immediate benefits
• Digital Signage
• Shopping Mall
• University & College
• Corporations
• Transportation
• Factory Automation
• Government
• Information Terminal
• Public Display
• Casino

Control Management Features
• Extremely easy to use
• Control each display Separately or All at once
• Select 1 or multiple monitor viewing configurations
• Multi Vision options: example - 5x5 (boarder) from DVI and 3x3 (in the center)
• Schedule a sequence of multiple display content configurations
• File Management Save and store edited contents for easy replay access
• Select input source
• Menu lock out (IR or panel)
• Power control - On / Off
• Color setting (RGB) & Brightness
• Edge setting (horizontal & vertical gap)

Hardware Features
• Spread 1 image across multiple monitors using 1 video source
• Configure up to a 20 x 20
• Video Wall Processor built in
• 1080p Full HD High Resolution Native 1920 x 1080p
• Stylish Slim & Ultra Slim Bezel Design
• Remote Display Management
• Landscape and Portrait
• DVI-D In / Out
• HDMI In / Out
• RS-232C In / Out for pc / server control
• Control panel Lock (panel or IR)
• All metal chassis
• Auto power recovery
• Auto pixel shift
• PIP / PBP - Dual signal In
• VESA standard hole patterns

Dual Screen Display
Picture-in-Picture (PIP) mode allows an image from an AV source to be displayed as a picture with in the image from a PC source (or vice-versa). Picture-by-Picture (PBP) mode permits images from an AV and PC source to be displayed side by side for split-screen viewing.

Security Lock Out
Their commercial displays have features to protect the unit including Menu button lock out & IR Lock Out. Controls on the front of the monitor can be locked, while additional buttons for other functions are usually hidden to prevent unauthorized access.

Narrow Bezel
ORION Images super narrow bezel Sunlight Readable RNK70NSF 70 inch video wall's bezel width is 20.0mm bezel width. With narrow bezel monitors can be joined together to create multiplex screen.

Auto Pixel Shift
Minutely moves pixels diagonally to prevent after-image / static image burn in. Dual Screen Display

Auto Power Recovery
If power outage occurs, their monitors will automatically power back on to their previous settings.

Display Up to 10 x 10
ORION Images Multi Vision Video Wall can display across up to 400 monitors (in a vertical & horizontal 20 x 20 arrangement).

3D Comb Filter, De-interlacing, Noise Reduction
Combined: Sharpens the Edges, Reduces Noise, Enhances light with shade and minimizes ghosting.

Auto Sequential Source Switching
Adjustable dwell time for up to 7 sources.

All Metal Chassis
Designed with a unique durable housing for various environments including commercial & industrial.

Magnetic Key Controller
Detachable magnetic key controller with CAT5 cable which allow easy access and control of main button.
