Review Summary
Black
15.4" (39.11cm)
1920x1200
10 bits
1500 nits
1650:1
2K (2048x1080): 23.98/24/25/29.97/30/50/59.94/60P, 23.98/24/25/29.97/30Psf
HD (1920x1080): 23.98/24/25/29.97/30/50/59.94/60P, 50/59.94/60I
HD (1280x720): 50/59.94/60P
4K (4096x2160): 23.98/24/25/29.97/30P
UHD (3840x2160): 23.98/24/25/29.97/30P
2K (2048x1080): 23.98/24/25/50
HD (1920x1080): 23.98/24/25/29.97/30/50/59.94/60P, 50/59.94/60I
HD (1280x720): 50/59.94/60P
2x SDI In
2x SDI Out
1x HDMI In
1x USB Type-A: 3D-LUT upload, firmware upgrade
1x USB Type-C: internal color calibration via x-rite i1 display pro
3.5mm mini Jack: ear phone
100-240V (50/60Hz) AC / 11-17V/3A (XLR Pin4)
10 User 3D LUTs
Standard Log: 2.2, 2.4, HLG, PQ; ARRI Log C; BMD Film, 4K Film, 4.6K Film; Canon C Log, C Log2, C Log3; Fuji F-LOG; Nikon N-LOG; Panasonic V-LOG; RED Log3G12, Log3G10, RedLogfilm; Sony S-Log, S-Log 2, S-Log 3; DCI 2.6
Aspect, Safe, Center, Crosshatch, Anamorphic
False Color, Zebra, Waveform, Vector, Histogram
Focus Assist, Peaking
DE-LOG, MULTI-SCOPES, Display Rotate, Audio Meter (Only SDI), Time Code (Only SDI)
22W
Optional, not included
Lithium ion
Non-universal
1
China
14.52 x 10.43 x 2.99" (36.89 x 26.49 x 7.59cm)
8.4 lbs (3.8kg)
769293552633
The IPS Black Technology
With more than 60% increase on contrast ratio compare to normal IPS, this newest technology provides superior contrast, crisp image with rich black details, improve the color accuracy in off-axis view angle.
Brightness Enhancement Film
With this film, 1500 nits brightness is realized. More light can be transmitted through the LCD, increasing on-axis illuminance by up to 60% for a slab backlight.
Anti-Reflective Coating
AR coating offers superior visibility and reduces reflection further by bending light through objects.
True 10-Bits Color Depth
Great color depth displays pictures with lovely color and tone rendition for your client.
Differentiate Your Creation with Color
Up to 10 USER 3D LUTs can be loaded. Monitoring the shooting with your special color profile.
Precise Color & Tone Reproduction
22-bit image engine and tetrahedral 3D-LUT interpolation support HLG/PQ HDR, and various camera logs. Achieve the perfect visual effect in nearly any environment.
Built-in Color Calibration Technology
Integrated calibration for excellent color reproduction, keeping the color true to life.
Rotary Encoder
Combines push, four directional, and rotation control into a single knob, making the Ul navigation and adjustments faster.
