Optoma EVBMN-M110 HDBaseT HDMI Over CAT5 Extender with IR, Serial and Ethernet
See all Optoma items

Optoma EVBMN-M110 HDBaseT HDMI Over CAT5 Extender with IR, Serial and Ethernet, Full HD 1080p at 60Hz Video Resolution, 328' Extension Distance

SKU: OUEVBMNM110

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the video quality supported by the Optoma EVBMN-M110 HDBaseT HDMI Extender?

The Optoma EVBMN-M110 HDBaseT HDMI Extender supports full, uncompressed HD 1080p video transmission.

What is the maximum extension distance of the Optoma EVBMN-M110 HDBaseT HDMI Extender?

The Optoma EVBMN-M110 HDBaseT HDMI Extender can extend up to 328 feet.

How many Ethernet connections does the Optoma EVBMN-M110 HDBaseT HDMI Extender support?

The Optoma EVBMN-M110 HDBaseT HDMI Extender supports up to three Ethernet connections.

Does the Optoma EVBMN-M110 HDBaseT HDMI Extender require special calibration?

No, the Optoma EVBMN-M110 HDBaseT HDMI Extender does not require any special calibration. It's designed for easy setup and user-friendly operation.

What are some ideal use cases for the Optoma EVBMN-M110 HDBaseT HDMI Extender?

The Optoma EVBMN-M110 HDBaseT HDMI Extender is perfect for large-scale installations in conference rooms, auditoriums, houses of worship, digital signage applications, shopping malls, hotels, and airports.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Optoma EVBMN-M110 Specifications

  • Video Resolution

    Full HD 1080p at 60Hz

  • Extension Distance

    328' / 99.98m

  • Transmitter: Input

    HDMI

  • Transmitter: Output

    RJ45

  • Transmitter: IR Extension

    1x IR Transceiver, 38 KHz

  • Transmitter: Serial Port

    DCE, DB9-Female

  • Transmitter: Ethernet Port

    3x RJ45, 10/100 Mbps

  • Transmitter: Power Supply

    12V DC (Phantom Power)

  • Transmitter: Enclosure

    Metal

  • Transmitter: Weight

    14.8 oz (0.40 kg)

  • Transmitter: Dimensions

    5.5" x 3.3" x 1.33" (140 x 84 x 33 mm)

  • Receiver: Input

    RJ45

  • Receiver: Output

    HDMI

  • Receiver: IR Extension

    1x IR Receiver, 38 KHz

  • Receiver: Serial Port

    DTE, DB9-Male

  • Receiver: Ethernet Port

    3x RJ45, 10/100 Mbps

  • Receiver: Power Supply

    12V DC (Phantom Power)

  • Receiver: Enclosure

    Metal

  • Dimensions

    Receiver and Transmitter: 5.5 x 3.3 x 1.33" / 13.97 x 8.38 x 3.38cm

  • Weight

    Receiver and Transmitter: 14.8oz / 419.57g

  • UPC Code

    796435090654

About Optoma EVBMN-M110

The Optoma EVBMN-M110 HDBaseT transmitter / receiver pair sends full, uncompressed HD 1080p video, audio, IR, bidirectional RS-232 control and up to 3 Ethernet connections over a single CAT5e/6 cable to a projector over 328' away. The Optoma EVBMN-M110 HDBaseT transmitter / receiver pair greatly reduces projector installation cost by eliminating the need for expensive cable runs. Compact in size, easy to setup, and requires no special calibration. Ideal for use in conference rooms, auditoriums, houses of worship and digital signage applications, shopping malls, hotels, airports.

Optoma EVBMN-M110 Features

  • Greatly reduces projector installation cost. Use low cost, easy to run CAT5e/6 cable
  • Transmits full, uncompressed HD 1080p video, audio and control over single cable
  • Simultaneously carries HDMI, bidirectional IR, RS-232 and up to 3 LAN lines to a projector up to 328 ft. away
  • Supports HDMI 1.4a, Full 3D HD, HDCP compliant
  • Supports phantom power single power adapter at either end powers both, receiver and transmitter units

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Greatly reduces projector installation cost
  • Use low cost easy to run CAT5e/6 cable
  • Transmits full, uncompressed HD 1080p video, audio & control over single cable
  • Simultaneously carries HDMI bidirectional IR RS-232 & up to 3 LAN lines to a projector up to 328 ft
  • Away
  • Supports HDMI 1.4a, Full 3D HD, HDCP compliant

What's in the box:

  • Optoma EVBMN-M110 HDBaseT HDMI Over CAT5 Extender with IR & Serial and Ethernet
  • Power Adapter Set
  • 2 x Foot Pad Set
  • IR External Sensor Kit
  • CAT5 Cable
  • 2 x Grounding Wire
  • Optoma 1 Year Limited Warranty
