Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the significance of the RAID 5 preconfiguration in the ThunderBay 4?

RAID 5 is a configuration that distributes data across multiple drives. This provides an extra layer of data protection, as it can recover data if one of the drives fails. The ThunderBay 4 comes preconfigured with RAID 5, offering a perfect blend of high-capacity storage and redundancy for added data protection.

What are the benefits of the ThunderBay 4's dual Thunderbolt 3 ports?

The dual Thunderbolt 3 ports in the ThunderBay 4 offer high-speed data transfer rates of up to 1527MB/s. This makes it an ideal solution for professionals who require fast and efficient data management.

Can the ThunderBay 4 support high-resolution displays?

Yes, the ThunderBay 4 features a dedicated DisplayPort 1.2 port that supports high-resolution displays, including 4K monitors, directly from the storage enclosure.

What is the capacity of the ThunderBay 4?

The ThunderBay 4 offers a total storage capacity of 4TB, divided across four 1TB hard drives. This makes it a spacious solution for professionals who need to store a large amount of data.

How does the ThunderBay 4 ensure the drives are kept cool?

The ThunderBay 4 features an ultra-quiet, heat-dissipating aluminum chassis. This design ensures that the drives are kept cool, even under intense operations.

Reviews about this item

Review Summary

2019-01-31T05:59:40

Rated 4 out of 5

Like the Drive, but a bit Noisy

This is my first RAID drive. Everything seems to work great, the software it comes with is great, given this is my first RAID. Now maybe I am just sensitive to noise, but with this drive sitting right under my desk next to me, I only run it when I have to. This thing puts out some noise, regardless of what the write up says about it, I think its noisy. I tried putting it in a large cabinet, but after an hour or so of running I think it was getting to warm and took it out. I would think there are probably some actual covers out there that would ventilate enough to safely keep this thing quieter? I am sure if I took the time to get it setup far away from my chair it would be better, but given the room I have, that would be a very large task to do. Depending on your setup and where you can put it, this may completely not be an issue for you? Well just my two cents worth on my very first RAID. Cheers

Chad D.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

OWC ThunderBay 4 RAID 5 Specifications

  • Software Requirements

    macOS 10.12 or later
    Windows 10 or later

  • Hardware Requirements

    Mac or PC featuring Thunderbolt 3 interface
    Mac or PC featuring Thunderbolt or Thunderbolt 2 interface

  • Interface (Chipset)

    (2) Thunderbolt 3 (Intel DSL6540)
    (1) DisplayPort

  • Max Transfer Rate

    Thunderbolt 3: 40 Gb/s (5000 MB/s)

  • JBOD / RAID Support

    JBOD: Utilize each of the four drives independently
    RAID: Use the included SoftRAID software RAID to setup the ThunderBay 4 for RAID 0, 1, 4, 5, and 10

  • Initial Configuration

    RAID 5

  • Standard Mechanism

    4x 1.0TB Toshiba DT01ACA Series Hard Disk Drives

  • Performance

    Read: Up to 1527MB/s

  • Kensington Lock Slot

    Yes

  • LED

    Yes (Power and disk activity)

  • Plug and Play

    Yes

  • Power supply

    AC input: 100 - 230V

  • Operating Temperature

    10 to 35 deg. C (50 to 95 deg. F)

  • Non-Operating Temperature

    -40 to 65 deg. C (-40 to 149 deg. F)

  • Dimensions (HxWxL)

    7 x 5.3 x 9.6" (17.78 x 13.46 x 24.38cm)

  • Weight

    5.7kg (12.57 lbs)

  • UPC Code

    812437029673

About OWC ThunderBay 4 RAID 5

Under the hood of the ThunderBay 4 lies a robust and high-performance 4TB (4x 1TB) 4-Drive HDD Storage Solution, designed to meet the needs of professionals and enthusiasts alike. With its dual Thunderbolt 3 ports delivering lightning-fast speeds up to 1527MB/s sustained performance, this storage powerhouse is engineered for efficiency and speed, making it an ideal choice for those who demand the best in data transfer rates.

Crafted with a new, alluring design, the ThunderBay 4 not only excels in power but also in its advanced features. It boasts a durable and ultra-quiet aluminum chassis that ensures your drives are kept cool, even under intense operations. The unit's intelligent drive monitoring system provides desktop and email notifications to keep you informed about the health of your drives.

The ThunderBay 4 is preconfigured with RAID 5, offering a perfect blend of high-capacity storage and redundancy for added data protection. It is user-configurable in RAID 0, 1, 4, 5, and 1+0, allowing you to tailor the performance and data security to your specific needs. This flexibility makes it a spacious and reliable solution for a variety of applications, including editing, content creation, and design.

With a dedicated DisplayPort 1.2 port, the ThunderBay 4 supports high-resolution displays, including 4K monitors, directly from the storage enclosure. This feature, coupled with the ability to daisy-chain up to six units, provides expansive storage capabilities and the potential for increased performance.

The ThunderBay 4 is meticulously tested with a rigorous multi-hour burn-in procedure, ensuring that each unit arrives ready for the most demanding tasks. This level of reliability is backed by OWC's award-winning U.S.-based support, giving you peace of mind with your investment.

Moreover, the ThunderBay 4's design includes vibration-dampening elements that minimize sonic resonance, and it stands firmly on rugged, non-skid feet that absorb vibrations. This attention to detail ensures that your data storage is not only spacious and advanced but also remarkably stable and reliable.

Included with the ThunderBay 4 is a certified OWC Thunderbolt 3 cable, ensuring a seamless connection right out of the box. With the ThunderBay 4, you're not just getting 4 drive bays; you're investing in a sophisticated storage solution that will elevate your data management to new heights.

OWC ThunderBay 4 RAID 5 Features

  • High-performance 4TB (4x 1TB) 4-Drive HDD Storage Solution with dual Thunderbolt 3 ports
  • Preconfigured with RAID 5 for optimal data security and user-configurable in RAID 0, 1, 4, 5, and 1+0
  • Supports high-resolution displays with dedicated DisplayPort 1.2 port
  • Ability to daisy-chain up to six units for expansive storage capabilities & increased performance
  • Ultra-quiet, heat-dissipating aluminum chassis with intelligent drive monitoring system
  • Comes with a certified OWC Thunderbolt 3 cable for a seamless connection

Key Features

  • High-performance 4TB (4x 1TB) 4-Drive HDD Storage Solution with dual Thunderbolt 3 ports
  • Supports high-resolution displays with dedicated DisplayPort 1.2 port
  • Ability to daisy-chain up to six units for expansive storage capabilities & increased performance
  • Ultra-quiet, heat-dissipating aluminum chassis with intelligent drive monitoring system
  • Comes with a certified OWC Thunderbolt 3 cable for a seamless connection

What's in the box:

  • OWC ThunderBay 4 4TB (4x 1.0TB)
  • 2.0m Thunderbolt 3 Cable
  • External Power Cable
  • 2x Security Keys
  • ThunderBay 4 Quick Start Guide
  • SoftRAID
  • SoftRAID Quick Start Guide
  • Utility Software Bundle for Mac and PC
  • Complimentary 1 Year Level 1 Data Recovery Service
  • OWC 3 Year Limited Warranty
