What is the data transfer speed of the ThunderBay 4 32TB 4-Drive HDD Storage Solution?

The ThunderBay 4 32TB 4-Drive HDD Storage Solution offers lightning-fast data transfer speeds of up to 1527MB/s thanks to its dual Thunderbolt 3 ports.

Is the ThunderBay 4 compatible with both 2.5" and 3.5" drives?

Yes, the ThunderBay 4 is natively compatible with both 2.5" and 3.5" drives, eliminating the need for adapters.

What RAID configuration does the ThunderBay 4 come preconfigured with?

The ThunderBay 4 comes preconfigured with RAID 5, offering an optimal balance of performance and data redundancy.

Can I daisy-chain multiple ThunderBay 4 units for expanded storage?

Yes, you can daisy-chain up to six ThunderBay 4 units for massive storage capabilities and increased performance.

Does the ThunderBay 4 include any form of drive monitoring?

Yes, the ThunderBay 4 features intelligent drive monitoring with desktop and email notifications, ensuring you're always informed about the status of your drives.

Reviews about this item

Review Summary

2019-01-31T05:59:40

Rated 4 out of 5

Like the Drive, but a bit Noisy

This is my first RAID drive. Everything seems to work great, the software it comes with is great, given this is my first RAID. Now maybe I am just sensitive to noise, but with this drive sitting right under my desk next to me, I only run it when I have to. This thing puts out some noise, regardless of what the write up says about it, I think its noisy. I tried putting it in a large cabinet, but after an hour or so of running I think it was getting to warm and took it out. I would think there are probably some actual covers out there that would ventilate enough to safely keep this thing quieter? I am sure if I took the time to get it setup far away from my chair it would be better, but given the room I have, that would be a very large task to do. Depending on your setup and where you can put it, this may completely not be an issue for you? Well just my two cents worth on my very first RAID. Cheers

Chad D.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

OWC ThunderBay 4 RAID 5 Specifications

  • Software Requirements

    macOS 10.12 or later
    Windows 10 or later

  • Hardware Requirements

    Mac or PC featuring Thunderbolt 3 interface
    Mac or PC featuring Thunderbolt or Thunderbolt 2 interface

  • Interface (Chipset)

    (2) Thunderbolt 3 (Intel DSL6540)
    (1) DisplayPort

  • Max Transfer Rate

    Thunderbolt 3: 40 Gb/s (5000 MB/s)

  • JBOD / RAID Support

    JBOD: Utilize each of the four drives independently
    RAID: Use the included SoftRAID software RAID to setup the ThunderBay 4 for RAID 0, 1, 4, 5, and 10

  • Initial Configuration

    RAID 5

  • Standard Mechanism

    4x 8.0TB HGST Deskstar NAS Hard Disk Drives

  • Performance

    Read: Up to 1527MB/s

  • Kensington Lock Slot

    Yes

  • LED

    Yes (Power and disk activity)

  • Plug and Play

    Yes

  • Power supply

    AC input: 100 - 230V

  • Operating Temperature

    10 to 35 deg. C (50 to 95 deg. F)

  • Non-Operating Temperature

    -40 to 65 deg. C (-40 to 149 deg. F)

  • Dimensions (HxWxL)

    7 x 5.3 x 9.6" (17.78 x 13.46 x 24.38cm)

  • Weight

    5.7kg (12.57 lbs)

  • UPC Code

    812437029734

About OWC ThunderBay 4 RAID 5

A powerhouse of storage and performance, the ThunderBay 4 32TB 4-Drive HDD Storage Solution is designed to meet the needs of data-intensive users. This high-performance, reliable, and advanced storage solution is equipped with dual Thunderbolt 3 ports, offering lightning-fast data transfer speeds of up to 1527MB/s.

This spacious and durable storage solution is natively compatible with both 2.5" and 3.5" drives, eliminating the need for adapters. The redesigned chassis not only enhances its aesthetic appeal but also ensures quieter operation and better heat dissipation, thanks to its ultra-quiet, heat-dissipating aluminum structure.

The ThunderBay 4 comes preconfigured with RAID 5, offering an optimal balance of performance and data redundancy. This configuration allows for faster RAID 5 performance and exponentially quicker rebuild times compared to similar hardware RAID arrays.

Designed with a dedicated DisplayPort 1.2 port, the ThunderBay 4 supports multi-stream compressed 4K video and other bandwidth-demanding operations. Its four drive bays can be used independently or in your preferred RAID configuration, making it a highly flexible external storage solution.

The ThunderBay 4 also features intelligent drive monitoring with desktop and email notifications, ensuring you're always informed about the status of your drives. Each unit undergoes a rigorous multi-hour "burn-in" performance certification procedure before shipping, ensuring it arrives ready for demanding use.

With the ability to daisy-chain up to six ThunderBay 4s, you can achieve massive storage capabilities and increased performance. The drive isolating design reduces sonic resonance and is complemented by oversized, rugged, vibration-absorbing, non-skid feet.

The ThunderBay 4 also comes with a 2.0-meter certified OWC Thunderbolt 3 cable, ensuring seamless connectivity right out of the box. Whether you're editing, experimenting, creating, or designing, the ThunderBay 4 32TB 4-Drive HDD Storage Solution is engineered to take your workflow to new heights.

OWC ThunderBay 4 RAID 5 Features

  • High-capacity 32TB 4-Drive HDD storage solution with dual Thunderbolt 3 ports
  • Preconfigured with RAID 5 for optimal performance and data redundancy
  • Compatible with both 2.5" and 3.5" drives, no adapter required
  • Redesigned, ultra-quiet chassis with heat-dissipating aluminum structure
  • Intelligent drive monitoring with desktop and email notifications
  • Supports daisy-chaining up to six units for expanded storage and performance

Key Features

  • High-capacity 32TB 4-Drive HDD storage solution with dual Thunderbolt 3 ports
  • Preconfigured with RAID 5 for optimal performance and data redundancy
  • Compatible with both 2.5" and 3.5" drives, no adapter required
  • Redesigned, ultra-quiet chassis with heat-dissipating aluminum structure
  • Intelligent drive monitoring with desktop and email notifications
  • Supports daisy-chaining up to six units for expanded storage and performance

What's in the box:

  • OWC ThunderBay 4 32.0TB (4x 8.0TB)
  • 2.0m Thunderbolt 3 Cable
  • External Power Cable
  • 2x Security Keys
  • ThunderBay 4 Quick Start Guide
  • SoftRAID
  • SoftRAID Quick Start Guide
  • Utility Software Bundle for Mac and PC
  • Complimentary 1 Year Level 1 Data Recovery Service
  • OWC 3 Year Limited Warranty
