Panasonic AJ-CX4000 4K HDR ENG Shoulder-Mount Camcorder
New Panasonic ENG camera AJ-CX4000
Panasonic AJ-CX4000: Picture 1 thumbnail
Panasonic AJ-CX4000: Picture 2 thumbnail
Panasonic AJ-CX4000: Picture 3 thumbnail
Panasonic AJ-CX4000: Picture 4 thumbnail
Panasonic AJ-CX4000: Picture 5 thumbnail
See all Panasonic items

Panasonic AJ-CX4000 4K HDR ENG Shoulder-Mount Camcorder

SKU: PCAJCX4000GJ MFR: AJ-CX4000GJ
Be the first to review this itemAsk a Question
$36,916.21
OR
$3077/mo suggested payments with 12‑month special financing. Learn how.
Earn VIP Reward Points

Key Features

  • Capture stunning 4K HDR footage with this professional camcorder's advanced MOS sensor.
  • Enjoy versatile recording with ExpressP2, microP2, and SDXC card slots for seamless workflow.
  • Achieve broadcast-quality audio with dual XLR inputs and comprehensive audio I/O options.
  • Stream live events with H.264/AVC, supporting multiple protocols like RTSP, RTMP, and RTMPS.
  • Utilize the 2/3-type bayonet lens mount for a wide range of professional lens options.
  • Rely on stable power with a 4-pin DC output, ensuring continuous operation during shoots.
See More Product Details
Ships from Manufacturer?

Final Sale - No Returns or Exchanges

Free Shipping

See Options

1
Add to ListGet Sale Alert

Need help? Ask our experts.

Overview
Compare
Accessories
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Panasonic AJ-CX4000 Specifications

Camera Unit

Camera Unit

Jump to...

  • Pickup Device

    MOS x1

  • Number of Pixels

    11.14 million pixels

  • Lens Mount

    2/3-type bayonet

  • Optical Filter

    CC filter: A: 3200 K, B: 4300 K, C: 5600 K, D: 6300 K
    ND filter: 1: CLEAR, 2: 1/4ND, 3: 1/16ND, 4: 1/64ND

  • Gain Setting

    -6 dB to 30 dB, can be set in 1 dB steps

  • Digital Super Gain (DS.GAIN)

    Selectable from 6 dB, 10 dB, 12 dB, 15 dB, 20 dB, 24 dB, (DS.GAIN) 28 dB, 34 dB

  • Super Gain (S.GAIN)

    Selectable from 30 dB, 36 dB, 42 dB

  • Shutter Speed

    [59.94 Hz] 1/100 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec., HALF
    [50.00 Hz] 1/60 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec., HALF

  • Synchro Scan Shutter

    [59.94 Hz]
    59.94i/59.94p mode: 1/60.0 sec. to 1/7200 sec.
    29.97p mode: 1/30.0 sec. to 1/7200 sec.
    23.98p mode: 1/24.0 sec. to 1/7200 sec.
    [50.00 Hz]
    50i/50p mode: 1/50.0 sec. to 1/7200 sec.
    25p mode: 1/25.0 sec. to 1/7200 sec.

  • Shutter Open Angle

    3.0 deg to 360.0 deg (can be set in 0.5 deg steps)

  • Sensitivity

    [NORMAL] mode
    F6 (2000 lx, 3200 K, 89.9% reflection, 59.94 Hz)
    F7 (2000 lx, 3200 K, 89.9% reflection, 50.00 Hz)
    [HIGH SENS.] mode
    F10 (2000 lx, 3200 K, 89.9% reflection, 59.94 Hz)
    F11 (2000 lx, 3200 K, 89.9% reflection, 50.00 Hz)

  • Minimum Illumination

    Approx. 0.005 lx (F1.4, +42 dB (S.GAIN), +34 dB (DS.GAIN))

  • Image S/N

    62 dB (standard)

  • Horizontal Resolution

    UHD: 2000 TV or higher (center)
    HD: 1000 TV or higher (center)

  • Digital Zoom

    x2, x3, x4

Memory Card Recorder

Jump to...

  • Recording Media

    ExpressP2 card
    MicroP2 card
    SDXC memory card (exceeding 32 GB to 128 GB)
    UHS-I/UHS-II, UHS Speed Class 3 compatible, video Speed Class V90 compatible

  • Recording Slot

    ExpressP2 card slot x1
    microP2/SDXC UHS-II memory card slot x2

  • Recording Pixels

    3840 x2160 (UHD), 1920 x1080 (FHD), 1440 x1080 (HD), 1280 x720 (HD)

  • System Frequency

    59.94 Hz/50.00 Hz

  • Recording Video Signal

    3840 x2160/59.94p, 50p, 29.97p, 25p, 23.98p
    1920 x1080/59.94p, 50p, 29.97p, 25p, 23.98p, 59.94i, 50i
    1440 x1080/59.94i, 50i
    1280 x720/59.94p, 50p

  • Two-slot Function

    Simultaneous recording, Relay recording

  • Special Recording

    Pre-recording, Interval recording

Digital Video

Jump to...

  • Number of Quantizing Bits

    P2: 4:2:2 10 bit/4:2:0 10 bit (AVC-Intra50)/4:2:0 8 bit (AVC-LongG12)
    MOV: 4:2:2 10 bit)/4:2:0 8 bit/4:2:0 10 bit (HEVC)

  • Video Compression

    P2: AVC-Intra 422/AVC-LongG50/AVC-LongG25/AVC-LongG12: MPEG-4 AVC/H.264 High Profile
    P2: AVC-Intra200/AVC-Intra100/AVC-Intra50:MPEG-4 AVC/H.264 Intra Profile
    MOV: H.264/MPEG-4 AVC High Profile, H.265/MPEG-H HEVC Main10 Profile

Digital Audio

Jump to...

  • Recording Audio Signal

    P2: 48 kHz/24 bit, 4 CH
    48 kHz/16 bit, 4 CH (only AVC-LongG12)

    MOV: 48 kHz/24 bit, 4 CH

  • Audio Recording Format

    P2: LPCM
    MOV: LPCM

  • Headroom

    18 dB/20 dB (Can be selected by menu)

Streaming

Jump to...

  • Video Compression

    H.264/MPEG-4 AVC Main Profile
    H.264/MPEG-4 AVC High Profile

  • Video Resolution

    1920 x1080 (FHD), 1280 x720 (HD), 640 x360, 320 x180

  • Streaming Method

    Unicast, Multicast

  • Frame Rate

    [59.94 Hz]: 24 fps, 30 fps, 60 fps
    [50.00 Hz]: 25 fps, 50 fps

  • Bit Rate

    24 Mbps, 20 Mbps, 16 Mbps, 14 Mbps, 8 Mbps, 6 Mbps, 4 Mbps, 3 Mbps, 2 Mbps, 1.5 Mbps, 1 Mbps, 0.7 Mbps

  • Audio Compression

    AAC-LC: 48 kHz/16 bit, 2 CH

  • Supported Protocol

    RTSP/RTP/RTMP/RTMPS

Video Output

Jump to...

  • SDI OUT1

    BNC x1
    12G-SDI: 0.8 V [p-p], 75 Ohm
    3G/HD-SDI: 0.8 V [p-p], 75 Ohm

    SDI remote control supported

    Output format (4:2:2 10 bit)
    3840 x2160: 59.94p, 50p, 29.97p, 25p, 23.98p
    1920 x1080: 59.94p, 50p, 59.94i, 50i, 29.97PsF, 25PsF, 23.98PsF, 1280 x720: 59.94p, 50p

  • SDI OUT2

    BNC x1
    3G/HD-SDI: 0.8 V [p-p], 75 Ohm
    SD-SDI: 0.8 V [p-p], 75 Ohm

    SDI remote control supported

    Output format (4:2:2 (10 bit) output)
    1920 x1080: 59.94p, 50p, 59.94i, 50i, 29.97PsF, 25PsF, 23.98PsF
    1280 x720: 59.94p, 50p, 720 x480: 59.94i, 720 x576: 50i

  • HDMI

    HDMI type A x1 (not compatible with VIERA Link)

    HDMI remote control supported

    Output format (4:2:2 (10-bit) output)
    3840 x2160: 59.94p, 50p, 29.97p, 25p, 23.98p

    1920 x1080: 59.94p, 50p, 59.94i, 50i, 29.97p, 25p, 23.98p

    1280 x720: 59.94p, 50p, 720 x480: 59.94p, 720 x576: 50p

Audio Input/Output

Jump to...

  • Audio IN

    XLR x2 (CH1/3, CH2/4), 3-pin

    LINE/MIC/MIC+48V selected by switch

    LINE: 4 dBu/0 dBu/-3 dBu selected by menu

    MIC: -40 dBu/-50 dBu/-60 dBu selected by menu

    MIC+48V: + 48 V/OFF compatible

  • MIC IN

    XLR x1, 5-pin

    +48 V ON/OFF selected by menu

    -40 dBu/-50 dBu/-60 dBu selected by menu

  • Wireless Slot

    25-pin, D-SUB, -40 dBu, 2ch supported

  • Audio OUT

    XLR x1, 5-pin
    4 dBu/0 dBu/-3 dBu selected by menu, equilibrium low impedance

  • SDI OUT

    LPCM 4 CH

  • HDMI

    LPCM 2 CH

  • PHONES

    0.13" (3.5mm) diameter stereo mini jack x2, output impedance 100 Ohm

  • Built-in Speaker

    0.78" (20mm) diameter, round x1

Other Input/Output

Jump to...

  • GENLOCK IN

    BNC x1, 1.0 V [p-p], 75 Ohm

  • TC IN/OUT

    BNC x1, Used as input/output terminal, switch by menu

    Input: 0.5 V - 8.0 V [p-p], 10 k Ohm

    Output: 2.0 V +/-0.5 V [p-p], low impedance

  • DC IN

    XLR x1, 4-pin, DC 12 V (11.0 V - 17.0 V)

  • DC OUT

    4-pin, DC 12 V (11.0 V - 17.0 V), maximum output current 1.5 A

  • Lens

    12-pin

  • VF

    20-pin

  • LAN

    RJ-45 XLRnet connector:
    1000BASE-T/100BASE-TX/10BASE-T

  • USB2.0 HOST

    Type A connector, 4-pin (5 V, 0.5 A), for attaching the wireless module (optional)

  • USB Device

    USB 3.1 GEN1 type C connector, with USB mass storage function, without USB bus-powered function

  • Light

    2-pin, DC12 V (DC 11.0 V - 17.0 V), maximum output current 4.5 A (up to 50 W equivalent)

Monitor/Viewfinder

Jump to...

  • LCD Monitor

    3.5" (88.9mm) LCD color monitor: Approx. 2.76 million pixels, touch panel supported

  • Display Window

    2.4" (60.96mm) black and white organic EL

General

Jump to...

  • Power

    DC: 12 V (11.0 V - 17.0 V)

  • Power Consumption

    32 W (body only, 2160-59.94p/HEVC LongGOP 100M standard recording status, LCD ON)
    72 W (with all the accessories connected and maximum power supplied from each output terminal)

  • Operating Temperature

    32 Degree to 104 Degree F (0 Degree to 40 Degree C)

  • Operating Humidity

    10% to 85% (relative humidity)

  • Storage Temperature

    -4 Degree to 140 Degree F (-20 Degree to 60 Degree C)

  • Dimensions (W x H x D)

    5.62 x 10.5 x 13.71" (143 x 267 x 348mm)

  • Weight

    Approx. 7.5 lb (3.4kg) (body only)

Other

Jump to...

  • UPC Code

    885170373143

3 Accessories for Panasonic AJ-CX4000 4K HDR ENG Shoulder-Mount Camcorder

  • All Accessories (3)
  • Monitor & Recorder (2)
  • Microphones & Audio (1)
Atomos Ninja Ultra 5.2" HDR Monitor-Recorder
Atomos Ninja Ultra 5.2" HDR Monitor-Recorder
$759.00
Atomos CONNECT Network, Wireless & SDI Expansion for NINJA V/V+
Atomos CONNECT Network, Wireless & SDI Expansion for NINJA V/V+
$299.00
Rode Wireless GO GEN 3 Compact Microphone System, Black
Rode Wireless GO GEN 3 Compact Microphone System, Black
$199.00

About Panasonic AJ-CX4000

Explore the world of professional videography with the AJ-CX4000 4K HDR ENG Shoulder-Mount Camcorder, a high-quality, durable, and innovative piece of equipment designed for professionals in the broadcasting industry. This advanced camcorder delivers impressive 4K HDR imaging, making it ideal for capturing news, sports, live events, TV shows, documentaries, and more.

The AJ-CX4000 is equipped with a large 11.14-megapixel MOS sensor, enabling it to achieve 2000 horizontal TV lines with oversampling. This ensures high-quality 4K pictures with low noise and a wide dynamic range. The camcorder also features dual native ISO technology for superb low light performance, and high sensitivity of F10 (59.94 Hz) / F11 (50 Hz) in High Sensitivity mode.

This versatile camcorder is designed with an interchangeable B4 lens support with LSSIEL technology, ensuring high-video quality. The AJ-CX4000 also features HLG (Hybrid Log-Gamma) for recording HDR (High Dynamic Range) video, providing a more vibrant and detailed image.

The AJ-CX4000 is not just a camcorder, but a complete video production tool. It offers advanced networking functions for reliable broadcast, livestreaming, and NDI-based video productions. The camcorder is also equipped with a built-in LAN terminal with a lock mechanism, enabling reliable network connectivity and IP remote control.

The AJ-CX4000 is designed to be lightweight and durable, making it easy to use for extended periods of time and in various shooting conditions. It also features an ergonomically optimized design for the camera operator, and an enhanced workflow for the editor, making it the ideal choice for the entire video production team.

Whether you're in the field delivering a live remote news broadcast, in a theater livestreaming a concert to YouTube Live, on a remote island recording footage for a reality TV show, or in a stadium capturing a sporting event for a documentary, the AJ-CX4000 4K HDR ENG Shoulder-Mount Camcorder is the perfect tool for all your video recording and production needs.

Panasonic AJ-CX4000 Features

  • 4K HDR video recording & support for SD / microP2 / expressP2 card recording
  • 4K/ UHD 60p 10-bit 4:2:2 output via 12G-SDI
  • B4 lens mount for interchangeable 2/3" lenses, features optical magnifying system
  • Direct livestreaming compatible with RTSP / RTMP / RTMPS
  • Ergonomically designed shoulder mount optimized for news, documentary and sports coverage

Warranty Information

This product has a limited warranty of 12 months.

Join VIP PRO

2 Day Delivery on thousands of items!

Request a Callback

Chat one-on-one with an expert

Sell or Trade your Gear

Get started in 3 easy steps

Product Documents

User Manual

Key Features

  • Capture stunning 4K HDR footage with this professional camcorder's advanced MOS sensor.
  • Enjoy versatile recording with ExpressP2, microP2, and SDXC card slots for seamless workflow.
  • Achieve broadcast-quality audio with dual XLR inputs and comprehensive audio I/O options.
  • Stream live events with H.264/AVC, supporting multiple protocols like RTSP, RTMP, and RTMPS.
  • Utilize the 2/3-type bayonet lens mount for a wide range of professional lens options.
  • Rely on stable power with a 4-pin DC output, ensuring continuous operation during shoots.

What's in the box:

  • AJ-CX4000 4K HDR Camcorder
  • Mount Cap
  • Shoulder Strap
  • Panasonic 1 Year Limited Warranty
