Panasonic AW-HE145 Full HD HDMI/3G-SDI/IP Integrated 20x PTZ Camera, Metallic Black

SKU: PCAWHE145KPJ MFR: AW-HE145KPJ
Earn VIP Reward Points

Key Features

  • Capture stunning Full HD video with the Panasonic PTZ camera's incredible 20x optical zoom.
  • Experience smooth pan and tilt operations, perfect for live events with this PTZ camera.
  • Stream directly via IP; this PTZ camera integrates easily with existing network infrastructure.
  • Achieve professional-grade video in low light with advanced noise reduction on this PTZ camera.
  • Control remotely via IP, RS-422, or HDMI for seamless integration of your PTZ camera system.
  • Benefit from flexible installation; mount this PTZ camera on ceilings or use it on desktops.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$229.99

3 Year

$274.99

4 Year

$369.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Panasonic AW-HE145 Specifications

  • Finish

    Metallic Black

  • Controller Supported

    AW-RP150, AW-RP60, AK-HRP1000GJ, AK-HRP1015GJ, AK-HRP250GJ

  • LENS

    Motorized Optical 20x zoom, F2.8 to F4.5 [f=8.8 mm (11/32 inches) to 176.0 mm (6-15/16 inches); 35 mm (1-3/8 inches) equivalent: 24.5 mm (31/32 inches) to 490.0 mm (19-9/32 inches)]

  • Minimum Illumination

    2 lx (F2.8, 59.94p, 50IRE, 42 dB, without accumulation)

  • Synchro scan

    59.94p/59.94i: 60.00 Hz to 7200 Hz
    29.97p: 30.00 Hz to 7200 Hz
    23.98p/24p: 24.00 Hz to 7200 Hz
    50p/50i: 50.00 Hz to 7200 Hz
    25p: 25.00 Hz to 7200 Hz

  • Zoom

    Optical zoom: 20x
    i.Zoom: FHD 32x
    Digital zoom: 10x

  • Horizontal Resolution

    1000 TV lines Typ (Centre area)

  • Gain Selection

    Auto, 0 dB to 36 dB
    Super Gain function equipped : +37 dB to 42 dB

  • White Balance

    ATW : 3200K, 5600K
    ATW Speed : Normal / Slow / Fast
    AWB : AWB-A / AWB-B
    VAR (selectable between 2000K and 15000K by designating a value)Optical FilterThrough, 1/4, 1/16, 1/64, IR through (IR through is used as "Night mode")

  • Output Format

    1080/59.94p, 1080/50p, 1080/29.97p, 1080/29.97PsF, 1080/25p, 1080/25PsF, 1080/23.98p, 1080/24p, 1080/23.98p, 1080/23.98PsF, 1080/59.94i, 1080/50i, 720/59.94p, 720/50p

  • Color separation optical system

    1MOS

  • Focus

    Switching between auto and manual

  • Focus Distance

    Entire zooming range: 1000 mm (3.3 ft)
    Wide end: 100 mm (0.33 ft)

  • Gamma

    HD / FILMLIKE1 / FILMLIKE2 / FILMLIKE3/ FILM REC / VIDEO REC / HLG

  • Scene File

    Scene1, Scene2, Scene3, Scene4

  • Electronic Shutter Speed

    59.94p/59.94i: 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
    29.97p: 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
    23.98p/24p: 1/24, 1/48, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000

  • Electronic Shutter Speed (Contd.)

    50p/50i: 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
    25p: 1/25, 1/50, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000

  • Imaging Sensors

    1-type Full-HD MOSx1

  • Chroma Amount Variability

    OFF, -99 % to 99 %

  • Frame mix

    0 dB, 6 dB, 12 dB, 18 dB, 24 dB

  • Conversion Lens

    Not supported

  • Angle of View Range

    Horizontal angle of view: 75.1 Degree (wide) to 4.0 Degree (tele)
    Vertical angle of view: 46.7 Degree (wide) to 2.3 Degree (tele)
    Diagonal angle of view: 82.8 Degree (wide) to 4.6 Degree (tele)

  • Standard Sensitivity

    F9, 2000 lx (When normal mode is selected)

  • Video Output

    HDMI: HDMI 2.0 standard4:2:2/10bit
    HDCP is not supported
    Viera Link is not supported

    3G-SDI OUT: SMPTE292 / 75 Ohm (BNC x 1)
    Level-A/Level-B supported

  • Synchronization System

    Internal/External synchronization (BBS/Tri-level sync)

  • Input Connector

    DC 12 V IN, G/L IN (BNC)
    BBS (Black Burst Sync), tri-level sync supported

  • Input/Output Connector

    LAN: LAN connector for IP control (RJ-45)

    RS-422: CONTROL IN RS-422A (RJ-45)

    MIC/LINE input: AAC compatible (compatible with IP only)
    Dia. 3.5 mm stereo mini jack
    Input impedance: Approx. 10 k Ohm (unbalanced)
    During MIC input

  • Input/Output Connector (Contd.)

    Supported mic: Stereo mic (plug-in power, on/off switching via menu)
    Supply voltage: 2.5 V +/- 0.5 V
    Mic input sensitivity: Approx. -40 dBV (0 dB=1 V/Pa, 1 kHz)
    During LINE input

    Input level: Approx. -10 dBV

  • Pan/Tilt Operation Speed

    Minimum speed 0.08 Degree /s
    Maximum speed 60 Degree /s or higher
    Maximum speed is 180 Degree /s in high-speed mode

  • Quietness

    NC35 or less

  • Tilting Range

    -30 Degree to 210 Degree

  • Panning range

    +/-175 Degree

  • Installation Method

    Stand-alone (Desktop) or suspended (Hanging)

  • Camera/pan-tilt head control

    IP connecting cable
    LAN cable: (category 5e or above, straight cable), max. 100 m (328 ft)

    AW protocol connecting cable
    LAN cable: (category 5e or above, straight cable), max. 1000 m (3280 ft)

  • Supported systems

    Windows:
    Microsoft(R) Windows(R) 10
    Windows(R) Internet Explorer(R) 11 (64-bit/32-bit)
    Microsoft Edge
    Google Chrome

    Mac:
    MacOS v11.0.1 / Safari 14.01
    MacOS v11.0.1 / Google Chrome
    MacOS V10.15 / Google Chrome
    MacOS V10.14 / Google Chrome

    iPhone / iPad
    iOS
    Google Chrome (operating and web browsers)

  • Image Streaming Mode

    JPEG (MJPEG), H.264, H.265

  • Image Transmission Setting

    JPEG
    Frame Rate: Maximum 30 fps, Image quality (Fine / Normal)

    H.264
    Transmission Type: Unicast port (AUTO), Unicast port (MANUAL), Multicast port
    Transmission Priority: Constant bit rate, Frame rate, Best effort
    Frame Rate: [60Hz] 60fps / 30fps / 15fps / 5fps, [50Hz] 50fps / 25fps / 12.5fps / 5fps

  • Image Transmission Setting (Contd.)

    Max Bit Rate: 24576kbps / 20480kbps / 16384kbps / 14336kbps / 12288kbps / 10240kbps / 8192kbps / 6144kbps / 4096kbp / 3072kbpss / 2048kbps / 1536kbps / 1024kbps / 768kbps / 512kbps

    H.265
    Transmission Type: Unicast port (AUTO), Unicast port (MANUAL), Multicast port
    Frame Rate: [60Hz] 60fps / 30fps, [50Hz] 50fps / 25fps

  • Image Transmission Setting (Contd...)

    Max Bit Rate 24576kbps / 20480kbps / 16384kbps / 14336kbps / 12288kbps / 10240kbps / 8192kbps / 6144kbps / 4096kbp / 3072kbpss / 2048kbps / 1536kbps / 1024kbps / 768kbps / 512kbps

    SRT H.264
    Transmission Type: UDP Unicast Only
    Frame Rate: [60Hz] 60fps / 30fps / 15fps / 5fps, [50Hz] 50fps / 25fps / 12.5fps / 5fps

  • Image Transmission Setting (Contd....)

    Max Bit Rate: 24576kbps / 20480kbps / 16384kbps / 14336kbps / 12288kbps / 10240kbps / 8192kbps / 6144kbps / 4096kbp / 3072kbpss / 2048kbps / 1536kbps / 1024kbps / 768kbps / 512kbps

    SRT H.265
    Transmission Type: UDP Unicast Only
    Frame Rate: [60Hz] 60fps / 30fps / 15fps / 5fps, [50Hz] 50fps / 25fps / 12.5fps / 5fps

  • Image Transmission Setting (Contd.....)

    Max Bit Rate: 24576kbps / 20480kbps / 16384kbps / 14336kbps / 12288kbps / 10240kbps / 8192kbps / 6144kbps / 4096kbp / 3072kbpss / 2048kbps / 1536kbps / 1024kbps / 768kbps / 512kbps

    RTMP/RTMPS
    Frame Rate: [60Hz] 60fps / 30fps / 15fps / 5fps, [50Hz] 50fps / 25fps / 12.5fps / 5fps, [24Hz] 24fps

  • Image Transmission Setting (Contd......)

    Max Bit Rate: 24576kbps / 20480kbps / 16384kbps / 14336kbps / 12288kbps / 10240kbps / 8192kbps / 6144kbps / 4096kbp / 3072kbpss / 2048kbps / 1536kbps / 1024kbps / 768kbps / 512kbps

  • Supported protocol

    IPv6: TCP / IP, UDP / IP, HTTP, HTTPS, DNS, NTP, DHCPv6, MLD, ICMP, ARP, RTSP/RTP
    IPv4: TCP / IP, UDP / IP, HTTP, HTTPS, RTSP/RTP, DHCP, DNS, DDNS, NTP, IGMP, ICMP, ARP, RTMP, RTMPS, SRT, MPEG2-TS over UDP

  • Audio Compression Type

    AAC-LC, 48 kHz / 16 bit / 2ch

  • Tally LED display color

    red / green

  • Storage Temperature

    -4 Degree F to 122 Degree F (-20 Degree C to 50 Degree C)

  • Current consumption

    4.0 A (XLR IN connector), 1.2 A (PoE++ power supply)

  • Power Requirements

    12 V DC (10.8 V to 13.2 V), DC 42 V to 57 V (Camera Input, PoE++ power supply)

  • Ambient Operating Temperature

    32 Degree F to 104 Degree F (0 Degree C to 40 Degree C)

  • Ambient Operating Humidity

    20 % to 90 % (no condensation)

  • Dimensions (W x H x D)

    8.37 x 10.5 x 8.62" (213 x 267 x 219mm) (excluding protrusions, direct ceiling mount bracket)

  • Weight

    Approx. 9.04 lbs (4.1kg) (excluding mount bracket)

About Panasonic AW-HE145

Panasonic AW-HE145 PTZ Camera.

The HD integrated camera AW-HE145 realizes high sensitivity of F9/2000lx with the mounted 1.0-type MOS sensor, and can shoot beautifully at stage events or church services with low light. The operation mechanism is the same design as the high-end model, so the operating performance of the pan/tilt and zoom is smooth and accurate, allowing you to shoot without stress. Furthermore, it is equipped with an optical 20x zoom and horizontal 75.1 Degree wide-angle lens to realize flexible video production.

Panasonic AW-HE145 PTZ Camera.

High Quality Full HD 60P Shooting.

Full-HD output and 59.94p shooting achieve extremely smooth video, even in live sports and other environments containing rapid movement.

SRT support for stable video transmission over public lines
SRT, a next-generation video transmission protocol with strong security suitable for unstable network environments, is supported.

High Quality Full HD 60P Shooting.

Multiple Interfaces Supported.

A wide range of outputs are supported: 3G-SDI, HDMI and IP.

Useful Software for Simplified Workflow
Compatible with a wide range of software, including the PTZ Control Centre and Auto Tracking Software. This software will simplify the workflow of the PTZ camera shooting and reduces the burden of operation and management.

Multiple Interfaces Supported.

Features.

  • High Sensitivity Achieved with the 1" Large-sized Sensor
  • Optical 20x Zoom/Horizontal 75.1 Degree Wide-angle Shooting
  • Pan/tilt Performance that Achieves Smooth and Accurate Operation
  • Enables high-quality video production even in dark environments
  • SRT support for stable video transmission

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Capture stunning Full HD video with the Panasonic PTZ camera's incredible 20x optical zoom.
  • Experience smooth pan and tilt operations, perfect for live events with this PTZ camera.
  • Stream directly via IP; this PTZ camera integrates easily with existing network infrastructure.
  • Achieve professional-grade video in low light with advanced noise reduction on this PTZ camera.
  • Control remotely via IP, RS-422, or HDMI for seamless integration of your PTZ camera system.
  • Benefit from flexible installation; mount this PTZ camera on ceilings or use it on desktops.

What's in the box:

  • Panasonic AW-HE145 FHD HDMI/3G-SDI/IP Integrated PTZ Camera (Metallic Black)
  • Panasonic 1 Year Limited Warranty
