Panasonic AW-UB50 24.2MP 4K Ultra HD NDI|HX2 Multi Purpose Box Camera, Black

SKU: PCAWUB50P MFR: AW-UB50P
Earn VIP Reward Points

Key Features

  • Capture stunning detail with the Panasonic camera's 24.2MP full-frame MOS sensor.
  • Achieve cinematic looks using the camera's 5.9K recording for professional video projects.
  • Enjoy flexible lens options with the L-Mount for diverse creative expressions.
  • Experience superior low light performance with Dual Native ISO for clean footage.
  • Streamline your workflow with NDI|HX2 for seamless integration into live production.
  • Easily manage audio with XLR inputs, offering phantom power for pro-grade microphones.
See More Product Details
Special Order?Estimated to Ship: 10/06/2025
Free Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Panasonic AW-UB50 Specifications

General

General

Jump to...
  • Color

    Black

  • Power Requirements

    When using Lithium-ion battery pack: 7.28V
    When using included AC adapter: 12V /3A

  • PoE

    PoE+
    IEEE802.3at compliant

  • Power Consumption

    When recording: 8.1W (When the interchangeable lens S-R24105 is attached)
    When playing back: 6.9W (When the interchangeable lens S-R24105 is attached)

  • Operating Temperature

    14 Degree F to 104 Degree F (-10 Degree C to 40 Degree C)

  • Operating Humidity

    10 % to 80 %

  • Storage Temperature

    -4 Degree F to 140 Degree F (-20 Degree C to 60 Degree C)

  • Storage Humidity

    0 % to 90 %

Camera Unit

Jump to...
  • Imaging Sensor

    1x 35mm full-size (35.6 x 23.8mm) MOS

  • Effective Pixels

    Approx. 24.2 megapixels

  • Latitude

    V-Log: 14+ stops

  • Lens Mount

    L-mount

  • Focus

    Focus mode: AF / MF
    AF mode:
    Motion picture: Auto Detection (Face, Eye, Body, Animal) / Tracking / 225-Area / Zone (Oval) / 1-Area
    Still image: Auto Detection (Face, Eye, Body, Animal) / 225-Area / 1-Area
    (Tethered photo shooting with LUMIX Tether for Multicam software)

  • ISO Sensitivity

    Standard Output Sensitivity:
    Auto / 100 to 51200 (When (Extended ISO) is set: Auto / 50 to 204800)
    Auto / 0 dB to 54 dB (When (Extended Gain Setting) is set: Auto / -6 dB to 66 dB)

  • Dual Native ISO (Normal)

    (Auto) Base sensitivity:
    ISO 100/640 (dB display values are based on ISO 100)
    Auto / 100 to 51200 (When (Extended ISO) is set: Auto / 50 to 204800)
    Auto / 0 dB to 54 dB (When (Extended Gain Setting) is set: Auto / -6 dB to 66 dB)

    (Low) Base sensitivity:
    ISO 100
    Auto / 100 to 800 (When (Extended ISO) is set: Auto / 50 to 800)
    Auto / 0 dB to 18 dB (When (Extended Gain Setting) is set: Auto / -6 dB to 18 dB)

  • Dual Native ISO (Normal) (Contd.)

    (High) Base sensitivity:
    ISO 640
    Auto / 640 to 51200 (When (Extended ISO) is set: Auto / 320 to 204800)
    Auto / 0 dB to 38 dB (When (Extended Gain Setting) is set: Auto / -6 dB to 50 dB)

  • Dual Native ISO (PTZ Camera)

    (Auto) Base sensitivity:
    ISO 250/1600 (dB display values are based on ISO250)
    Auto / 250 to 51200 (When (Extended ISO) is set: Auto / 125 to 204800)
    Auto / 0 dB to 46 dB (When (Extended Gain Setting) is set: Auto / -6 dB to 58 dB)

    (Low) Base sensitivity:
    ISO 250
    Auto / 250 to 2000 (When (Extended ISO) is set: Auto / 125 to 2000)
    Auto / 0 dB to 18 dB (When (Extended Gain Setting) is set: Auto / -6 dB to 42 dB)

  • Dual Native ISO (PTZ Camera) (Contd.)

    (High) Base sensitivity:
    ISO 1600
    Auto / 1600 to 51200 (When (Extended ISO) is set: Auto / 800 to 204800)
    Auto / 0 dB to 30 dB (When (Extended Gain Setting) is set: Auto / -6 dB to 42 dB)

  • Dual Native ISO (V-Log)

    (Auto) Base sensitivity:
    ISO 640/4000 (dB display values are based on ISO640)
    Auto / 640 to 51200 (When (Extended ISO) is set: Auto / 320 to 51200)
    Auto / 0 dB to 38 dB (When (Extended Gain Setting) is set: Auto / -6 dB to 38 dB)

    (Low) Base sensitivity:
    ISO640
    Auto / 640 to 5000 (When (Extended ISO) is set: Auto / 320 to 5000)
    Auto / 0 dB to 18 dB (When (Extended Gain Setting) is set: Auto / -6 dB to 18 dB)

  • Dual Native ISO (V-Log) (Contd.)

    (High) Base sensitivity:
    ISO4000
    Auto / 4000 to 51200 (When (Extended ISO) is set: Auto / 2000 to 51200)
    Auto / 0 dB to 22 dB (When (Extended Gain Setting) is set: Auto / -6 dB to 22 dB)

  • Dual Native ISO (HLG)

    (Auto) Base sensitivity:
    ISO 400/2500 (dB display values are based on ISO 400)
    Auto / 400 to 51200 (When (Extended ISO) is set: Auto / 400 to 204800)
    Auto / 0 dB to 42 dB (When (Extended Gain Setting) is set: Auto / 0 dB to 54 dB)

    (Low) Base sensitivity:
    ISO 400
    Auto / 400 to 3200
    Auto / 0 dB to 18 dB

  • Dual Native ISO (HLG) (Contd.)

    (High) Base sensitivity:
    ISO 2500
    Auto / 2500 to 51200 (When (Extended ISO) is set: Auto / 2500 to 204800)
    Auto / 0 dB to 26 dB (When (Extended Gain Setting) is set: Auto / 0 dB to 38 dB)

  • Dual Native ISO (Cinelike D2/V2)

    (Auto) Base sensitivity:
    ISO 200/1250 (dB display values are based on ISO 200)
    Auto / 200 to 51200 (When (Extended ISO) is set: Auto / 100 to 204800)
    Auto / 0 dB to 48 dB (When (Extended Gain Setting) is set: Auto / -6 dB to 60 dB)

    (Low) Base sensitivity:
    ISO 200
    Auto / 200 to 1600 (When (Extended ISO) is set: Auto / 100 to 1600)
    Auto / 0 dB to 18 dB (When (Extended Gain Setting) is set: Auto / -6 dB to 18 dB)

  • Dual Native ISO (Cinelike D2/V2)(Contd.)

    (High) Base sensitivity:
    ISO 1250
    Auto / 1250 to 51200 (When (Extended ISO) is set: Auto / 640 to 204800)
    Auto / 0 dB to 32 dB (When (Extended Gain Setting) is set: Auto / -6 dB to 44 dB)

  • Creative Video Mode

    Custom Mode C1 to C12

  • Exposure Compensation

    Motion picture: 1/3 EV step +/-3 EV
    Still image: 1/3 EV step +/-5 EV

  • Light metering system/mode

    1728-zone metering / multi-metering / center-weighted metering / spot metering / highlight-weighted metering (only for video)

  • Shutter Speed

    Still: 1/8,000 - 1 (Tethered photo shooting with LUMIX Tether for Multicam software)
    Movie: 1/16,000 - 1/2

  • White Balance

    AWB / AWBc / AWBw / Daylight / Cloudy / Shade / Incandescent lights / White Set 1, 2, 3, 4 / Color temperature 1, 2, 3, 4

  • Still Picture Recording

    Recording file format: JPEG (DCF, Exif 2.31)
    File size: 6000 x 4000 (L) / 4272 x 2848 (M) / 3024 x 2016 (S)

  • Recording (MOV) (59.94Hz)

    Image Area of Video (Full):
    5952x3968 (3:2 6K), 23.98p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    5376x3584 (3:2 5.4K), 29.97p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    5888x3312 (16:9 5.9K), 29.97p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    5888x3312 (16:9 5.9K), 23.98p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM

  • Recording (MOV) (59.94Hz) (Contd.)

    4096x2160 (C4K), 29.97p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    4096x2160 (C4K), 23.98p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3840x2160 (4K), 29.97p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV) (59.94Hz) (Contd..)

    3840x2160 (4K), 23.98p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 119.88p, 150Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    1920x1080 (FHD), 59.94p, 200Mbps (422/10bit ALL-I) / 100Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 59.94i, 100Mbps (422/10bit ALL-I) / 50Mbps (422/10bit LongGOP), H.264/MPEG-4 AVC,LPCM

  • Recording (MOV) (59.94Hz) (Contd...)

    1920x1080 (FHD), 47.95p, 100Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    1920x1080 (FHD), 29.97p, 200Mbps (422/10bit ALL-I) / 100Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 23.98p, 200Mbps (422/10bit ALL-I) / 100Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV) (59.94Hz) (Contd....)

    Image Area of Video (Pixel/Pixel):
    4096x2160 (C4K), 59.94p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    4096x2160 (C4K), 59.94p, 150Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    4096x2160 (C4K), 47.95p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    4096x2160 (C4K), 29.97p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV) (59.94Hz) (Contd.....)

    4096x2160 (C4K), 23.98p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3840x2160 (4K), 59.94p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    3840x2160 (4K), 59.94p, 150Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3840x2160 (4K), 47.95p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM

  • Recording (MOV) (59.94Hz) (Contd......)

    3840x2160 (4K), 29.97p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3840x2160 (4K), 23.98p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3328x2496 (4:3 (Anamorphic 4K), 47.95p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM

  • Recording (MOV) (59.94Hz)(Contd.......)

    3328x2496 (4:3 (Anamorphic 4K), 29.97p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3328x2496 (4:3 (Anamorphic 4K), 23.98p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV)(59.94Hz)(Contd........)

    1920x1080 (FHD), 119.88p, 150Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    1920x1080 (FHD), 59.94p, 200Mbps (422/10bit ALL-I) / 100Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 59.94i, 100Mbps (422/10bit ALL-I) / 50Mbps (422/10bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV)(59.94Hz)(Contd.........)

    1920x1080 (FHD), 47.95p, 100Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    1920x1080 (FHD), 29.97p, 200Mbps (422/10bit ALL-I) / 100Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 23.98p, 200Mbps (422/10bit ALL-I) / 100Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV) (50.00Hz)

    Image Area of Video (Full):
    5376x3584 (3:2 5.4K), 25.00p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    5888x3312 (16:9 5.9K), 25.00p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    4096x2160 (C4K), 25.00p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV) (50.00Hz) (Contd.)

    3840x2160 (4K), 25.00p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 100.00p, 150Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    1920x1080 (FHD), 50.00p, 200Mbps (422/10bit ALL-I) / 100Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 50.00i, 100Mbps (422/10bit ALL-I) / 50Mbps (422/10bit LongGOP), H.264/MPEG-4 AVC,LPCM

  • Recording (MOV) (50.00Hz) (Contd..)

    1920x1080 (FHD), 25.00p, 200Mbps (422/10bit ALL-I) / 100Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

    Image Area of Video (Pixel/Pixel):
    4096x2160 (C4K), 50.00p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    4096x2160 (C4K), 50.00p, 150Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV) (50.00Hz) (Contd...)

    4096x2160 (C4K), 25.00p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3840x2160 (4K), 50.00p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    3840x2160 (4K), 50.00p, 150Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3840x2160 (4K), 25.00p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV) (50.00Hz) (Contd....)

    3328x2496 (4:3 (Anamorphic 4K), 50.00p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    3328x2496 (4:3 (Anamorphic 4K), 50.00p, 150Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3328x2496 (4:3 (Anamorphic 4K), 25.00p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 100.00p, 150Mbps (420/10bit LongGOP), H.265/HEVC, LPCM

  • Recording (MOV) (50.00Hz) (Contd.....)

    1920x1080 (FHD), 50.00p, 200Mbps (422/10bit ALL-I) / 100Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 50.00i, 100Mbps (422/10bit ALL-I) / 50Mbps (422/10bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 25.00p, 200Mbps (422/10bit ALL-I) / 100Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV) (24.00Hz)

    Image Area of Video (Full):
    5952x3968 (3:2 6K), 24.00p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    5888x3312 (16:9 5.9K), 24.00p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    4096x2160 (C4K), 24.00p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV) (24.00Hz) (Contd.)

    3840x2160 (4K), 24.00p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 48.00p, 100Mbps (420/10bi LongGOP), H.265/HEVC, LPCM
    1920x1080 (FHD), 24.00p, 200Mbps (422/10bit ALL-I) / 100Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV) (24.00Hz) (Contd..)

    Image Area of Video (Pixel/Pixel):
    4096x2160 (C4K), 48.00p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    4096x2160 (C4K), 24.00p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3840x2160 (4K), 48.00p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM

  • Recording (MOV) (24.00Hz) (Contd...)

    3840x2160 (4K), 24.00p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3328x2496 (4:3 (Anamorphic 4K), 48.00p, 200Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    3328x2496 (4:3 (Anamorphic 4K), 24.00p, 400Mbps (422/10bit ALL-I) / 150Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV) (24.00Hz) (Contd....)

    1920x1080 (FHD), 48.00p, 100Mbps (420/10bit LongGOP), H.265/HEVC, LPCM
    1920x1080 (FHD), 24.00p, 200Mbps (422/10bit ALL-I) / 100Mbps (422/10bit LongGOP) / 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MP4) (59.94Hz)

    Image Area of Video (Full):
    3840x2160 (4K), 29.97p, 72Mbps (420/10bit LongGOP), H.265/HEVC, AAC
    3840x2160 (4K), 23.98p, 72Mbps (420/10bit LongGOP), H.265/HEVC, AAC
    3840x2160 (4K), 29.97p, 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC
    3840x2160 (4K), 23.98p, 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC

  • Recording (MP4) (59.94Hz) (Contd.)

    1920x1080 (FHD), 59.94p, 28Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC
    1920x1080 (FHD), 29.97p, 20Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC
    1920x1080 (FHD), 23.98p, 24Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC

  • Recording (MP4) (59.94Hz) (Contd..)

    Image Area of Video (Pixel/Pixel):
    3840x2160 (4K), 59.94p, 100Mbps (420/10bit LongGOP), H.265/HEVC, AAC
    3840x2160 (4K), 29.97p, 72Mbps (420/10bit LongGOP), H.265/HEVC, AAC
    3840x2160 (4K), 23.98p, 72Mbps (420/10bit LongGOP), H.265/HEVC, AAC
    3840x2160 (4K), 29.97p, 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC
    3840x2160 (4K), 23.98p, 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC

  • Recording (MP4) (59.94Hz) (Contd...)

    1920x1080 (FHD), 59.94p, 28Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC
    1920x1080 (FHD), 29.97p, 20Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC
    1920x1080 (FHD), 23.98p, 24Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC

  • Recording (MP4) (50.00Hz)

    Image Area of Video (Full):
    3840x2160 (4K), 25.00p, 72Mbps (420/10bit LongGOP), H.265/HEVC, AAC
    3840x2160 (4K), 25.00p, 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC
    1920x1080 (FHD), 50.00p, 28Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC
    1920x1080 (FHD), 25.00p, 20Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC

  • Recording (MP4) (50.00Hz) (Contd.)

    Image Area of Video (S35mm/Pixel/Pixel):
    3840x2160 (4K), 50.00p, 100Mbps (420/10bit LongGOP), H.265/HEVC, AAC
    3840x2160 (4K), 25.00p, 72Mbps (420/10bit LongGOP), H.265/HEVC, AAC
    3840x2160 (4K), 25.00p, 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC
    1920x1080 (FHD), 50.00p, 28Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC
    1920x1080 (FHD), 25.00p, 20Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, AAC

  • Recording (MOV,VFR) (59.94Hz)

    Image Area of Video (Full):
    1920x1080 (FHD), 59.94p (Maximum output of sensor is 180fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 29.97p (Maximum output of sensor is 180fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 23.98p (Maximum output of sensor is 180fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV,VFR) (59.94Hz) (Contd.)

    Image Area of Video (S35mm):
    4096x2160 (C4K), 29.97p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    4096x2160 (C4K), 23.98p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3840x2160 (4K), 29.97p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV,VFR) (59.94Hz) (Contd..)

    3840x2160 (4K), 23.98p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3328x2496 (4:3 Anamorphic 4K), 29.97p (Maximum output of sensor is 50fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3328x2496 (4:3 Anamorphic 4K), 23.98p (Maximum output of sensor is 48fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV,VFR) (59.94Hz)(Contd...)

    1920x1080 (FHD), 59.94p (Maximum output of sensor is 180fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 29.97p (Maximum output of sensor is 180fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 23.98p (Maximum output of sensor is 180fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording(MOV,VFR)(59.94Hz)(Contd.....)

    Image Area of Video (Pixel/Pixel):
    4096x2160 (C4K), 29.97p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    4096x2160 (C4K), 23.98p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3840x2160 (4K), 29.97p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording(MOV,VFR)(59.94)(Contd......)

    3840x2160 (4K), 23.98p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3328x2496 (4:3 Anamorphic 4K), 29.97p (Maximum output of sensor is 50fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3328x2496 (4:3 (Anamorphic 4K), 23.98p (Maximum output of sensor is 48fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording(MOV,VFR)(59.94)(Contd.......)

    1920x1080 (FHD), 29.97p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 23.98p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV, VFR) (50.00Hz)

    Image Area of Video (Full):
    1920x1080 (FHD), 50.00p (Maximum output of sensor is 180fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 25.00p (Maximum output of sensor is 180fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV, VFR) (50.00Hz) (Contd.)

    Image Area of Video (S35mm):
    4096x2160 (C4K), 25.00p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3840x2160 (4K), 25.00p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3328x2496 (4:3 Anamorphic 4K), 25.00p (Maximum output of sensor is 50fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV,VFR) (50.00Hz) (Contd..)

    1920x1080 (FHD), 50.00p (Maximum output of sensor is 180fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 25.00p (Maximum output of sensor is 180fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

    Image Area of Video (Pixel/Pixel):
    4096x2160 (C4K), 25.00p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV,VFR)(50.00Hz) (Contd...)

    3840x2160 (4K), 25.00p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3328x2496 (4:3 Anamorphic 4K), 25.00p (Maximum output of sensor is 50fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 25.00p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV, VFR) (24.00Hz)

    Image Area of Video (Full):
    1920x1080 (FHD), 24.00p (Maximum output of sensor is 180fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

    Image Area of Video (S35mm):
    4096x2160 (C4K), 24.00p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3840x2160 (4K), 24.00p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV, VFR) (24.00Hz) (Contd.)

    3328x2496 (4:3 Anamorphic 4K), 24.00p (Maximum output of sensor is 48fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 24.00p (Maximum output of sensor is 180fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

    Image Area of Video (Pixel/Pixel):
    4096x2160 (C4K), 24.00p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Recording (MOV, VFR) (24.00Hz)(Contd..)

    3840x2160 (4K), 24.00p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    3328x2496 (4:3 (Anamorphic 4K), 24.00p (Maximum output of sensor is 48fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM
    1920x1080 (FHD), 24.00p (Maximum output of sensor is 60fps), 100Mbps (420/8bit LongGOP), H.264/MPEG-4 AVC, LPCM

  • Picture Adjustment

    Contrast / Highlight / Shadow / Saturation / Color Tone / Sharpness / Noise Reduction / Dual Native ISO Setting / ISO / WB

  • Photo Style

    PTZ camera (AW-UE160) / Standard / Vivid / Natural / Flat / Landscape / Portrait / Cinelike D2 / Cinelike V2 / Like709 / V-LOG / 2100-like (HLG) / My Photo Style 1-10

Input Connector

Jump to...
  • DC In

    DC 12V (11.4 to 12.6V), EIAJ Type4, PoE+ (IEEE802.3at compliant)

  • External Microphone

    3.5 mm for external microphone / external audio device
    Mic (Plug-in Power) / Mic / Line is selectable

  • Audio In

    2x XLR (3-pin) (Input 1, Input 2)
    Line / Mic / Mic +48V is selectable

  • Genlock In

    1x BNC

Output Connector

Jump to...
  • HDMI

    HDMI Type A

  • SDI Out

    1x BNC, 0.8V(p-p), 75 Ohm, 3G-SDI

  • Headphone

    3.5mm

Input/Output Connector

Jump to...
  • TC In/Out

    1x BNC

  • USB

    USB Type-C (USB3.1 Gen 1)

  • LAN

    Remote Control: LAN Terminal (RJ-45)
    Power Supply: PoE+ (IEEE802.3at compliant)

  • Remote In

    2.5mm

Memory Card Recorder

Jump to...
  • Recording Media

    SD Memory Card, SDHC Memory Card, and SDXC Memory Card for dual-slot recording

Streaming

Jump to...
  • Compatible Protocol

    RTP / RTSP

  • Streaming Image Quality

    System frequency (59.94Hz) (NTSC):
    H.264:
    3840x2160 (4K), 59.94p, 50Mbps
    3840x2160 (4K), 59.94p, 25Mbps
    3840x2160 (4K), 29.97p, 25Mbps
    3840x2160 (4K), 29.97p, 12.5Mbps
    1920x1080 (FHD), 59.94p, 16Mbps
    1920x1080 (FHD), 59.94p, 8Mbps
    1920x1080 (FHD), 29.97p, 6Mbps
    1920x1080 (FHD), 29.97p, 3Mbps
    1280x720 (HD), 59.94p, 6Mbps
    1280x720 (HD), 29.97p, 4Mbps

  • Streaming Image Quality (Contd.)

    H.265:
    3840x2160 (4K), 59.94p, 50Mbps
    3840x2160 (4K), 59.94p, 25Mbps
    3840x2160 (4K), 29.97p, 25Mbps
    3840x2160 (4K), 29.97p, 12.5Mbps
    1920x1080 (FHD), 59.94p, 20Mbps
    1920x1080 (FHD), 59.94p, 16Mbps
    1920x1080 (FHD), 29.97p, 12Mbps
    1920x1080 (FHD), 29.97p, 6Mbps

  • Streaming Image Quality (Contd..)

    System frequency (50.00Hz) (PAL):
    H.264:
    3840x2160 (4K), 50.00p, 50Mbps
    3840x2160 (4K), 50.00p, 25Mbps
    3840x2160 (4K), 25.00p, 25Mbps
    3840x2160 (4K), 25.00p, 12.5Mbps
    1920x1080 (FHD), 50.00p, 16Mbps
    1920x1080 (FHD), 50.00p, 8Mbps
    1920x1080 (FHD), 25.00p, 6Mbps
    1920x1080 (FHD), 25.00p, 3Mbps
    1280x720 (HD), 50.00p, 6Mbps
    1280x720 (HD), 25.00p, 4Mbps

  • Streaming Image Quality (Contd...)

    H.265:
    3840x2160 (4K), 50.00p, 50Mbps
    3840x2160 (4K), 50.00p, 25Mbps
    3840x2160 (4K), 25.00p, 25Mbps
    3840x2160 (4K), 25.00p, 12.5Mbps
    1920x1080 (FHD), 50.00p, 20Mbps
    1920x1080 (FHD), 50.00p, 16Mbps
    1920x1080 (FHD), 25.00p, 12Mbps
    1920x1080 (FHD), 25.00p, 6Mbps

Battery

Jump to...
  • Battery Info

    Optional, not included

  • Battery Material

    Lithium ion

  • Battery Type

    Non-universal

  • Battery Quantity

    1

Physical

Jump to...
  • Dimensions

    Excluding protrusions: 3.66 x 3.66 x 3.1" (93 x 93 x 78.8mm)

  • Weight

    Body only: 1.29 lbs (585g)

  • UPC Code

    885170440296

Models
Panasonic AW-UB50 24.2MP 4K Ultra HD NDI|HX2 Multi Purpose Box Camera, Black
$4,200.00

$4,260.98

Save:$60.98

Special Order

Generally ships in 7-14 days, subject to availability

Panasonic AG-CX20 4K Ultra HD Compact Professional Camcorder, Black
$3,050.00

$3,378.15

Save:$328.15 (10%)

Special Order

Generally ships in 7-14 days, subject to availability

Panasonic AG-CX350 4K Camcorder

SKU: PCAGCX350

MFR: AG-CX350PJ

$5,269.91

Special Order

Generally ships in 7-14 days, subject to availability

Special FeaturesGenlockable, XLR Mic InputsTime Code I/O, XLR Mic Input, Zoom24P, 25P, Mic Input, Time Code I/O, Touchscreen LCD, XLR Mic Input, Zoom
Resolution4K 60p4K 60p4K 60p
Kit Style-BaseBase
Configuration-Camcorder OnlyCamcorder Only
Sensor TypeCMOSCMOSCMOS
Sensor SizeFull Frame 35mm1/2.5"1"
Lens Included-Body Only20x Zoom
Recording MediaSecure Digital (SD)microP2, Secure Digital (SD)Secure Digital (SD)

About Panasonic AW-UB50

The AW-UB50 is box-style cameras with large sensors housed in a compact body, offering excellent resolution and expression capabilities.

The AW-UB50 adopts a common IP control protocol that enables seamless integration with our remote camera systems for efficient operation.

High-quality Video Expression

High-sensitivity Large-format Sensor
The AW-UB50 is equipped with a 24.2-megapixel effective full-size MOS sensor. It achieves high sensitivity by optimizing dynamic range and signal-to-noise ratio for exceptional resolution, tonal gradation, color reproduction, and low noise.

Log Shooting
Offers V-Log shooting for wide dynamic range, enabling rich tones and flexible grading with excellent highlight tolerance for fine, rich tonal gradations of dark and highlight areas. (AW-UB50: 14+ stops). In addition, when editing video from the AW-UE160W/K 4K integrated camera, V-Log helps to ensure a consistent look for highly efficient editing.

Dual Native ISO
Comes with Dual Native ISO for high-sensitivity video even in low-light environments, allowing shooting with compact lighting equipment or natural light without significantly compromising video quality. This also reduces the need for extensive post-production work, such as noise reduction. In ISO Auto mode, ISO sensitivity is displayed in real time to visualize noise levels while shooting.

Efficient Video Creation
Color profiles compatible with the AW-UE160W/K 4K integrated camera enable color matching when using multiple PTZ cameras.

Versatile Interchangeable Lens
The AW-UB50 has dedicated interchangeable lenses. In addition to the high optical performance developed through LUMIX, they deliver excellent image quality. They cater to a wide range of needs, such as capturing dramatic expression changes or zooming in on decisive scenes.

Excellent Expandability

Multiple I/O Terminals
The AW-UB50 flexibly adapts to diverse scenarios thanks to standard connections for professional equipment, including 3G-SDI OUT, TC In/Out, GENLOCK In, HDMI Type A, LAN, USB Type-C, 3.5mm Mic, and headphones. LAN is PoE+ compliant for power supply, allowing video transmission, control, and power supply over a single LAN cable, significantly reducing wiring complexity in the field.

Two SD Card Slots
The two built-in SD card slots support data management with the best recording method, either sequential (relay) recording or backup recording, depending on the shooting environment and conditions.

Multiple IP Transmission Standards
Compatible with the NDI HX2 IP standard for sharing high-definition video data with networked equipment, making it easy to build IP-based systems incorporating other NDI-compatible devices.

Expand shooting situations according to the combinations you choose
Supports a common IP control protocol for seamless integration with Panasonic PTZ cameras, allowing operation from the remote operation panel (ROP). In the future, it will support a wide variety of scenarios by linking with remote camera controllers and live switchers.

System with Panasonic PTZ cameras and other professional equipment
The system can be controlled centrally with the Panasonic remote operation panel (ROP). It allows unified operation of parameters such as focus and exposure. This not only streamlines operation but also significantly reduces system setup time and management workload.

Application examples such as a box-style camera + PTZ Camera
We would like to introduce various application scenarios that can be expanded through the combination of remote cameras and other Panasonic cameras.

Indoor sports
By taking advantage of the compact housing, the system can express a wide range of tension, dynamism, and the human drama of sports.

Supports a wide range of shooting styles with flexible expandability
The minimal body, designed specifically for video production, features a wide variety of I/O interfaces, making the camera versatile for diverse applications including multi-camera setups, streaming, and traditional production styles using tripods and gimbals.

Software Platform Support
The Media Production Suite software platform can be used to create multi-camera systems that include PTZ cameras. It can automatically detect and list of all Panasonic PTZ cameras connected to the same network as the PC. It can also be used to check camera information (IP address, version number, etc.) and to configure camera network settings, enhancing the efficiency of multi-PTZ camera operations.

LUMIX Tether
Software for batch start/stop, etc. in system with AW-UB50.

Panasonic AW-UB50 Features

  • Compact, lightweight
  • Interchangeable lens type
  • Remote camera integration
  • Unified IP control protocol compatible with Panasonic PTZ camera systems
  • 24.2M full-frame MOS sensor for emotional and cinematic video
  • Wide dynamic range with V-Log 14+ stops
  • Compatible with Media Production Suite for multi-camera setups with PTZ cameras
  • support for IP transmission standards including NDI HX2, RTMPS, and SRT

Warranty Information

This product has a limited warranty of 12 months.

Product Documents

User Manual

Key Features

  • Capture stunning detail with the Panasonic camera's 24.2MP full-frame MOS sensor.
  • Achieve cinematic looks using the camera's 5.9K recording for professional video projects.
  • Enjoy flexible lens options with the L-Mount for diverse creative expressions.
  • Experience superior low light performance with Dual Native ISO for clean footage.
  • Streamline your workflow with NDI|HX2 for seamless integration into live production.
  • Easily manage audio with XLR inputs, offering phantom power for pro-grade microphones.

What's in the box:

  • Panasonic AW-UB50 24.2MP 4K Ultra HD NDI|HX2 Multi Purpose Box Camera (Black)
  • AC Adapter
  • Panasonic 1 Year Limited Warranty
