Duplex scanning
1-Line CIS (Contact Image Sensor)
100-600 dpi (1 dpi step)
200 dpi (Portrait):
Letter:
Simplex: 30 ppm; Duplex: 60 ipm
A4:
Simplex: 30 ppm; Duplex: 60 ipm
200 dpi (Portrait):
Letter:
Simplex: 20 ppm; Duplex: 40 ipm
A4:
Simplex: 20 ppm; Duplex: 40 ipm
Up to 50 sheets (80 g/m2, 20 lbs), 3 hard cards (ISO 7810 ID-1)
Zone OCR (a function of the Image Capture Plus software that adds characters from the document to the output file name), Separation sheet, Single Touch Scan, Skip key
Binary, Grayscale, Color, MultiStream (Color & Binary or Gray & Binary)
Dither, Error Diffusion
JPEG for color and grayscale
Minimum: 48 x 70mm / 1.89 x 2.76"
Maximum: 216 x 2540mm / 8.50 x 100.00"
216 x 2540mm / 8.50 x 100.00"
Single Feed: 0.04 to 0.2 mm(1.6 to 7.9 mils)
Continuous Feed: 0.04 to 0.2 mm(1.6 to 7.9 mils)
Business Card: Card: Up to approx. 0.76 mm (0.03 in.) in thickness + embossing (ISO standard 7810 ID-1 card scanning including embossed card)
20 to 209 g/m2 (5.4 to 55 lbs.)
Drivers & utilities, Image Capture Plus
Yes
Microsoft Windows 7 (32/64 bits), Microsoft Windows Vista (32/64 bits) SP2 or later, Microsoft Windows XP SP3 or later, Windows 8 (32/64 bits)
Yes
USB 2.0
AC 100 - 240 V, 50 Hz/60 Hz
Scanning: 17 W or less
Standby: 4.5 W or less
Sleep: 1.6 W or less
Power OFF: 0.3 W or less
10 to 35 deg. C / 50 to 95 deg. F, 20% to 80% RH
0 to 40 deg. C / 32 to 104 deg. F, 10% to 80% RH
303 x 177 x 137mm / 11.93 x 6.97 x 5.39" When the exit tray is closed and without the feed tray.
2.7kg / 5.95lbs
885170089655
High Speed Full Color Scanning
Excellent Performance Keeps Office Productivity High
This speeds up the job of turning even largamounts of daily forms and mountains of documents into data. Clean, crisp, clear scanned data is also ideal for electronic file conversion and management.
Duplex Scanning
Prevents Pages From Being Missed When Scanning
Double-sided scanning of documents from business-card size all the way to A4 can be done with a single scan. Plus, double-sided scanning is done at the same speed as single-sided scanning. This eliminates the work of pre-sorting and prevents pages from being missed when scanning.
Single Touch Scan
Simply Press a Button to Send Scanned Data
3 customizable preset keys simplify scan tasks. With the touch of a button, instantly start scanning documents and send them to a destination of your choice.
Touch Free Scanning
Quick Manual Paper Feeding
For smaller scan jobs, Touch Free Scanning is convenient for manual paper feeding - just insert documents directly into the scanner.
Mixed Paper and Hard Card Batch Scanning
Enable Hard Card Scanning with Paper Documents in a Single Batch
These scanners are designed to combine paper documents along with an embossed card, such as a driver's license, in a single batch. You can even scan a stack of hard cards, including embossed cards, continuously via the auto document feeder.
Double-Feed Prevention Roller System
Prevents Scanning Mis-Feeds
This double-feed prevention roller system is worked to achieve reliable scanning of large amounts of documents. It reduces double-sheet feeding by separating the documents from the second sheet onward.
Ultrasonic Double-Feed Detection
Prevent Scanning Errors
In addition to its double-feed prevention roller, the double-feed prevention system is enhanced by an ultrasonic sensor that detects the double feeding of originals during scanning. This innovative design prevents double feeding and has been proven effective even when the documents being scanned contain a mix of paper of different weights or thickness. Thanks to double-feed prevention, optimum reliability is assured even when scanning high volumes of documents.
Automatic Image Orientation
No More Worries About the Document's Direction
Even when documents are set in different directions, this function detects the direction of the scanned text in documents and automatically rotates it into the correct direction. This boosts work efficiency by eliminating the need to change the direction of each page in advance when scanning large quantities of documents with various sizes and directions.
Auto Erasure Security
A High Degree of Safety
Scanned data is automatically erased from the scanner memory as soon as scanning is completed. This basically eliminates the danger of information leaks and ensures the user of safe, secure scanning.
Power Saving
Reduces Power Consumption
LED Lighting - The scanning section uses LEDs for its light source to lower power consumption while scanning. Sleep Mode - Power consumption is suppressed to 1.6 watt maximum during sleep mode to save energy while the scanner is not being used. Power Auto Off Function - The power automatically turns off at a preset time to cut down on wasted electricity.
Space-Saving Installation
The scanner can be Installed Just About Anywhere
The retractable tray saves storage space when the scanner is not in use. Simply place the scanner on the counter and a desk and use when needed. The space-saving design helps to achieve an efficient usage environment.
2-Page Separation
Easily Get the Data You Need From Each Page
A 2-page spread can be scanned and automatically divided into two single sheets. This saves time and trouble because it makes complex editing operations unnecessary. Also, when used with the optional flatbed scanner, 2-Page Separation can be applied even to thick books or magazines.
