Panasonic 2.2-6mm f/1.3-T360 DC Auto Iris 1/3" Megapixel Lens, Manual Focus
See all Panasonic items

Panasonic 2.2-6mm f/1.3-T360 DC Auto Iris 1/3" Megapixel Lens, Manual Focus, 2.7x Optical Zoom

SKU: PCPLAMP2206

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Panasonic 2.2-6mm f/1.3-T360 Specifications

  • Format

    1/3" CS

  • Focal Length

    2.2 to 6 mm

  • Optical Zoom

    2.7x

  • Focus Control

    Manual

  • Zoom Control

    Manual

  • Iris

    f/1.3 to T360 (equivalent to f/360)

  • Iris Control

    Auto (DC type)

  • Back Focus Distance

    7.70 mm in air

  • Exit Pupil Position

    452 mm (from image plane)

  • Object Dimensions at M.O.D. (H x V)

    4:3 Aspect Ratio:
    Wide: 42.32 x 25.12" / 107.49 x 63.80cm
    Tele: 10.47 x 7.72" / 26.59 x 19.61cm

    16:9 Aspect Ratio:
    Wide: 52.13 x 18.86" / 132.41 x 47.90cm
    Tele: 11.54 x 6.22" / 29.31 x 15.80cm

  • Angle of View (H x V)

    4:3 Aspect Ratio:
    Wide: 120 x 91 deg.36'
    Tele: 46 deg.26' x 34 deg.59'

    16:9 Aspect Ratio:
    Wide: 129 deg.43' x 75 deg.23'
    Tele: 50 deg.30' x 28 deg.38'

  • Focusing Range

    From Front of the Lens: 1.0' (0.3 m) to infinity

  • Coil Resistance

    Drive Coil: 190Ohms
    Damping Coil: 500Ohms

  • Current Consumption

    23mA maximum at 4 VDC

  • Weight

    1.9oz / 53.86g

About Panasonic 2.2-6mm f/1.3-T360

The Panasonic PLAMP2206 is a 1/3" Megapixel lens with 2.8-8mm focal length. It features an Auto Iris and CS mount.

Panasonic 2.2-6mm f/1.3-T360 Features

  • Auto Iris
  • 2.2-6mm Focal Length
  • CS Mount

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Auto Iris
  • CS Mount

What's in the box:

  • Panasonic 2.2-6mm f/1.3-T360 DC Auto Iris 1/3" Megapixel Lens
  • Panasonic 1 Year Warranty
