44% Off

Panasonic PT-EX510LU XGA 3LCD Multimedia Projector, 1024x768, 5300 Lumens, Lens Not Included

SKU: PCPTEX510LU MFR: PT-EX510LU
Earn VIP Reward Points

Key Features

  • Experience vivid presentations with 5300 lumens brightness, perfect for well-lit rooms.
  • Enjoy XGA resolution (1024x768) for clear images and sharp text in your presentations.
  • Choose your ideal lens (lens not included) for flexible setup in any meeting space.
  • Achieve accurate colors with 3LCD technology, ensuring engaging visuals for your audience.
  • Rely on a long-lasting lamp life up to 4,500 hours in Eco mode, reducing maintenance costs.
  • Connect easily with HDMI, DVI-D, and RGB inputs for compatibility with various devices.
See More Product Details
Temporarily On Backorder?Expected Availability: 10/2025Request assistance or get notified
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$119.99

3 Year

$179.99

4 Year

$199.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Accessories
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Panasonic PT-EX510LU Specifications

  • Power supply

    100-240 V AC, 50/60 Hz

  • Power consumption

    485 W (0.3 W when STANDBY MODE set to ECO, 4 W when STANDBY MODE set to NORMAL (34 W when STANDBY MODE of AUDIO SETTING set to ON))

  • Panel size

    20.0 mm (0.79 in) diagonal (4:3 aspect ratio)

  • Display method

    Transparent LCD panel (x 3, R/G/B)

  • Drive method

    Active matrix

  • Pixels

    786,432 (1,024 x 768) x 3, total of 2,359,296 pixels

  • Lens

    Optional powered zoom/focus lenses and fixed-focus lens

  • Lamp

    1x 335W UHM lamp, lamp replacement cycle (lamp power: Normal/Eco): 4,000 hours/4,500 hours

  • Screen size (diagonal)

    1.02-10.16 m (40-400 in), 4:3 aspect ratio

  • Brightness

    5,300 lm (lamp power: Auto/Normal, Dynamic mode, Standard lens)

  • Center-to-corner uniformity

    90%

  • Contrast

    2,000:1 (full on/full off, lamp power: Auto)

  • Resolution

    1,024 x 768 pixels

  • Scanning frequency: DVI-D/HDMI

    (DisplayPort/DIGITAL LINK): Dot clock: 25-162MHz (VGA: 640 x 480 pixels to WUXGA: 1,920 x 1,200 pixels, VESA CVT-RB compliant with HDCP)
    DisplayPort and DIGITAL LINK not included on PT-EX510/EX510L.

  • Scanning frequency: RGB

    fH: 15-91 kHz, fV: 24-120 Hz, dot clock: up to 162 MHz

  • Scanning frequency: YPBPR(YCBCR)

    fH: 15.73 kHz, fV: 59.94 Hz [480i (525i)]
    fH: 15.63 kHz, fV: 50 Hz [576i (625i)]
    fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]
    fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i]
    fH: 28.13 kHz, fV: 25 Hz [1080 (1125)/25p]
    fH: 27.00 kHz, fV: 48 Hz [1080 (1125)/24sF]
    fH: 67.50 kHz, fV: 60 Hz [1080 (1125)/60p]
    fH: 31.47 kHz, fV: 59.94 Hz [480p (525p)]
    fH: 31.25 kHz, fV: 50 Hz [576p (625p)]

  • Scanning frequency: YPBPR(YCBCR) 1

    fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]
    fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]
    fH: 27.00 kHz, fV: 24 Hz [1080 (1125)/24p]
    fH: 33.75 kHz, fV: 30 Hz [1080 (1125)/30p]
    fH: 56.25 kHz, fV: 50 Hz [1080 (1125)/50p]

  • Scanning frequency: Video/YC

    fH: 15.73 kHz, fV: 59.94 Hz [NTSC/NTSC4.43/PAL-M/PAL60]
    fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]

  • Optical axis shift: Vertical

    +/-50 % from center of screen (powered)

  • Optical axis shift: Horizontal

    +/-10 % from center of screen (powered)

  • Keystone correction range

    Vertical +/-40 deg., horizontal +/-30 deg.

  • Installation

    Ceiling/floor, front/rear

  • Built-in speaker

    3.7 cm round shape x 1, output power 10.0 W (monaural)

  • Terminals: DVI-D IN

    1x DVI-D 24-pin (DVI 1.0 compliant, compatible with HDCP, compatible with single link only)

  • Terminals: HDMI IN

    1x HDMI 19-pin (Deep Color, compatible with HDCP)
    Audio signal: Linear PCM (Sampling frequency: 48 kHz/44.1 kHz/32 kHz)

  • Terminals: RGB 1 IN

    1x D-Sub HD 15-pin (female)

  • Terminals: RGB 2 IN

    5x BNC (1x RGB or YPBPR/YCBCR) shared with VIDEO IN (S-video/composite video)

  • Terminals: VIDEO IN

    1x Pin jack (composite video)

  • Terminals: MONITOR OUT

    1x D-sub HD 15-pin (female) (1x RGB) (compatible with RGB or YPBPR/YCBCR)

  • Terminals: AUDIO IN

    2x Pin jack (1x L/R), 2x M3 (2x L-R)

  • Terminals: AUDIO OUT

    1x M3 (1x L-R) for output (variable)

  • Terminals: SERIAL IN

    1x D-sub 9-pin (female) for external control (RS-232C compliant)

  • Terminals: REMOTE 1 IN

    1x M3 for wired remote control

  • Terminals: REMOTE 2 IN

    1x D-sub 9-pin (female) for external control (parallel)

  • Terminals: LAN / DIGITAL LINK

    1x RJ-45 (for network connection, 10Base-T, 100Base-TX, compliant with PJLink)

  • Operation noise

    35 dB (lamp power: NORMAL), 29 dB (lamp power: ECO)

  • Mechanical shutter

    (AV mute)

  • Cabinet materials

    Molded plastic (PC + ABS)

  • Operating temperature

    0 to 45 deg. C / 32 to 113 deg. F

  • Operating humidity

    10-80 % (no condensation)

  • Software Bundle

    Logo Transfer Software
    Multi Projector Monitoring
    Control Software

  • Dimensions (W x H x D)

    Without lens: 530 x 177 x 385mm / 20.87 x 6.97 x 15.16"

  • Weight

    Without lens: 9.8kg / 21.61lbs (Approx.)

33 Accessories for Panasonic PT-EX510LU XGA 3LCD Multimedia Projector, 1024x768, 5300 Lumens, Lens Not Included

  • All Accessories (33)
  • Brackets & Mounts (2)
  • Lenses (2)
  • Subwoofers (1)
  • Amplifiers (1)
  • Speakers (9)
  • Laptop Stand (1)
  • Screens (6)
  • Cables & Adapters (6)
  • Lamps & Bulbs (1)
  • Adapters & Mounts (1)
  • Bags & Cases (1)
  • Cameras (2)

About Panasonic PT-EX510LU

You can elevate your multimedia presentations with the PT-EX510LU XGA 3LCD Multimedia Projector, a high-quality and powerful projection solution designed for lecture theatres, conference rooms, classrooms, and home theaters. This projector boasts a bright output of 5300 lumens, ensuring vivid, clear images and sharp, legible texts even in well-lit environments.

The projector's native XGA resolution of 1024x768 pixels delivers rich, detailed images, enhanced by a high contrast ratio of 2000:1. This is further boosted by the Iris feature, which adjusts brightness according to the surrounding environment, ensuring dazzling highlights and deep blacks.

The PT-EX510LU projector also offers a color adjustment function, allowing for easy correction of slight variations in color reproduction when setting up multiple units for simultaneous projection. Its Daylight View Basic Technology uses an ambient light sensor to adjust halftone color and brightness, ensuring clearer, brighter images that suit the surroundings.

For versatile presentations, this projector offers a Side-by-Side and P-in-P mode, allowing two different image sources to be displayed on a single screen. The sub-window can be positioned anywhere on the screen for more flexible and effective image presentations.

This reliable and durable projector is designed for long-term use, with a lamp replacement cycle of up to 4500 hours and an Eco Filter that can extend for up to 17,000 hours. Its dust-resistant cabinet, equipped with extensive optical shielding and sealing, keeps images brighter for longer.

Maintenance is made easy with the PT-EX510LU projector, as the filter can be replaced from the side and the lamp from the top, even when the projector is installed on the ceiling. Eco-friendly features, such as low standby power consumption and Eco Management functions, reduce power consumption and environmental impact, making this projector a responsible choice for your multimedia needs.

Panasonic PT-EX510LU Features

  • High-quality XGA 3LCD Multimedia Projector for bright, clear images in any setting
  • Powerful 5300 lumens output for vivid presentations even in well-lit environments
  • XGA resolution (1024x768) and high contrast ratio (2000:1) for detailed, rich visuals
  • Side-by-Side and P-in-P modes for flexible, simultaneous display of two image sources
  • Long-life Eco Filter and lamp with easy replacement for low maintenance and durability
  • Eco-friendly features including low standby power consumption and Eco Management functions for reduced environmental impact

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Experience vivid presentations with 5300 lumens brightness, perfect for well-lit rooms.
  • Enjoy XGA resolution (1024x768) for clear images and sharp text in your presentations.
  • Choose your ideal lens (lens not included) for flexible setup in any meeting space.
  • Achieve accurate colors with 3LCD technology, ensuring engaging visuals for your audience.
  • Rely on a long-lasting lamp life up to 4,500 hours in Eco mode, reducing maintenance costs.
  • Connect easily with HDMI, DVI-D, and RGB inputs for compatibility with various devices.

What's in the box:

  • Panasonic PT-EX510LU XGA 3LCD Multimedia Projector
  • Power Cord (Including Power Cord Holder)
  • Wireless/Wired Remote Control Unit
  • 2x Battery for Remote Control (AAA/R03/LR03 Type)
  • Software CD-ROM
  • Panasonic 1 Year Warranty (90 Days on Lamp)
